- Page 1 GST-RP16 Conventional Repeater Panel Installation and Operation Manual (Issue 1.03, Jan 2014)
-
Page 2: Table Of Contents
GST-RP16 Conventional Repeater Panel Installation and Operation Manual CONTENTS General ........................ 1 Features ....................... 1 Technical Specifications ..................1 Structure and Operation Principle ................ 1 Mounting and Commission .................. 2 Operations ......................3 Troubleshooting ....................3 VIII Cautions ....................... 4... -
Page 3: I General
When the conventional FACP receives fire signal, it will alarm and send the signal to GST-RP16. Then the GST-RP16 will indicate the alarm zone and sound to notice the people there to act accordingly. -
Page 4: Mounting And Commission
V Mounting and Commission Mounting GST-RP16 is wall-mounted. Drill two 5 holes on the wall as shown in Fig. 3, push two 5 plastic expansion sleeves into the holes, then fix the back of GST-RP16 with expansion bolts and connect wires. -
Page 5: Operations
Wiring: 227 IEC 05 cables for signal input and power supply, cross section is 1.0mm Commission: GST-RP16 carries out self-test when power is on and all LEDs are lit. The buzzer alarms fire. After self-test, Power ON LED is lit, other LEDs are off, and the buzzer doesn t sound. -
Page 6: Cautions
VIII Cautions Before powering up, check all cable problems, such as short circuit, open circuit and wrong connections etc. GST-RP16 is a precise electronic product and must be maintained by specific personnel. Make record on duty. We take the responsibility of repairing the repeater. If any problem occurs, please contact us in time.
