GST-IFP4M
Fire Alarm Control Panel
Company Confidential, for Internal Use Only

Advertisement

loading
Need help?

Need help?

Do you have a question about the IFP4M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GST IFP4M

Summary of Contents for GST IFP4M

  • Page 1 GST-IFP4M Fire Alarm Control Panel Company Confidential, for Internal Use Only...
  • Page 2 Solution for Market Segments To be Released To be Released GST-IFP4M GST-IFP2M GST-IFP10M Integration Functionality Market Addressable Addressable Addressable Devices per system 363,000 121,000 605,000 Devices per panel 1452 2420 Detectors per panel 1452 2420 Zones per panel 1000 1000...
  • Page 3 GST-IFP4M System Overview Max # of expansion Max # of loops / Max # of network Max # detectors / slots / panel cabinet node / system system 363,000...
  • Page 4 GST-IFP4M Panel Key Features • English & configurable language (optional Arabic) • 7.0” 800x480 color capacitive touch screen • Redundant CPU* • CAN, TCP/IP*, Fiber networking • USB port for F/W upgrade • Built-in printer, optional external USB printer • Remote diagnosis via Ethernet* •...
  • Page 5 GST-IFP4M Main Components Main Components Reference Default Description MP-400 CPU Mounting Board MP-401 1 (up to 2) CPU Card / optional Redundant CPU Card NC-400 NAC Card PR-400 Panel Printer LC-401 Single Loop Card MP-400 MP-401 NC-400 PR-400 LC-402 Dual Loop Card...
  • Page 6 Benefits User Friendly Features Flexibility • User defined button • Touch Screen • Multi-language • Graphical Programming • Optional external USB Printer • Built-in printer • Support cards hot plug • Help information per window • Real time detector compensation level report •...

  • Page 7: Fire Alarm Control Panel

    Fire Alarm Control Panel Loop length under typical loop devices configuration Sample Sample Sample Sample configuration 1 configuration 2 configuration 3 configuration 4 Number of smoke detectors Number of heat detectors Number of MCPs Number of input modules Number of output modules Number of loop isolators Total Devices per loop 14AWG/2.0mm2...
  • Page 8 Fire Alarm Control Panel On Board Repeater circuit, connect up to 64 points RS485 – 1000meters GSTGMC-up to 8 users www.gst.com.cn...
  • Page 9 CAN Networking Max. 250 panels, IFP4M and Annunciator networking CAN Network Card CAN Network Card CAN Network Card (P-9966A) (P-9966A) (P-9966A) Distance between panel nodes: 3 km (max) CAN Network Card Built-in CAN Network Card CAN Network Card CAN Network Card...
  • Page 10 Fiber Networking Max. 250 panels, IFP4M and Annunciator networking Fiber Network Card Fiber Network Card Fiber Network Card (P-9983) (P-9983) (P-9983) Distance between panel nodes: 20 km (max) Fiber Network Card Built-in Fiber Network Card Fiber Network Card Fiber Network Card...
  • Page 11 Network Annunciator GST-MNA2C: CAN Class A GST-MNA2F: Fiber-Optic Class A • 800*480, 7.0 “ colour TFT LCD • Touch Screen • Achieve remote control of systems (Reset, Silence, ACK etc.) • Sortable history capacity of 10,000 alarm, 10,000 supervisory and 100,000 others.
  • Page 12 UL Field Devices...
  • Page 13 Detector Combined Detector Optical Detector Heat Detector DI-M9101 DI-M9102 DI-M9103 • Aesthetics: Low profile detector • Reliable: Advanced digital communication & Drift compensation • Easy to install: Electronic addressing using handheld tool • Easy to test and commission: Magnetic switch for quick alarm testing •...

  • Page 14: Manual Call Point

    Manual Call Point Digital Manual Call Point • Semi-flush or surface mounting DI-M9204 • Standard UL 38 • Re-settable (non-breaking glass) • LED indicator • Electronic addressing • Easy installation and test • Back box for surface mount • Ingress Protection Rating: IP 43 D-92FC D-92WPB...
  • Page 15 Notification Devices Sounder Strobe Sounder Strobe DC-M9413W/R DC-M9414W/R DC-M9415W/R • Wall mounted • Configurable sound level and candela rating • Synchronized through external module / NAC • Available in red or white...
  • Page 16 Notification Devices Ceiling Mount Ceiling Mount Signal Synchronization Sounder Strobe (White) Sounder Strobe (Red) Module DC-M9416W DC-M9416R DC-M9410 • Candela setting (15,30,75 and 90cd) output • High sounder level output: 88.8-93.6dB • Enhanced synchronization circuit to comply with the latest requirements of UL 1971 Signaling Devices for the Hearing Impaired. •...
  • Page 17 Modules Single Input / Digital Zone Input module Single Riser Loop Isolator Output Monitor DI-M9300 DI-M9305 DC-M9503 DI-M9301 DI-M9319 • Aesthetics: Compact I/O module • Easy to install: Electronic addressing using handheld tool DIN or surface mounting • Easy to test and commission: Integrated LED status indicator...

  • Page 18: Voice Alarm System

    Voice Alarm System...
  • Page 19 GST Voice Alarm System • True multiplex multi channel audio integrated fire phone • Integrated 2 Channel Digital Message repeater • Live Microphone Page to any zone • Built in Standard Alarm and Alert Signals, up to 4 Minute Message...
  • Page 20 GST Voice Alarm System...
  • Page 21 Q & A...
