Functional Safety Manual
SIL Safety Manual for
Pulsar Model R96
Pulse urst Radar
Level Transmitter
This manual complements and is intended to be used with
the Pulsar
®
Model R96 Installation and Operating manual
( ulletin 58-602 dated January 2015 or later).
Application
The PULSAR Model R96 (HART
transmitter can be applied in most metal and concrete
process or storage vessels. The PULSAR Model R96 can
be used in liquids or slurries to meet the safety system
requirements of IEC 61508/IEC 61511-1.
Benefits
The Magnetrol
Model R96 (HART) transmitter pro-
®
vides the following benefits to your operation:
• Protection up to SIL2 (Safe Failure Fraction = 92.7%)
as independently assessed (hardware assessment) by
exida as per IEC 61508/ IEC 61511-1.
• Antenna designs to +400 °F (+200 °C),
750 psig (51.7 bar)
• IS, XP and Non-Incendive approvals
• Quick connect / disconnect antenna coupling
• Performance not process dependent (changing specific
gravity and dielectric have no effect).
Software v1.x
) Pulse Burst level
®

Advertisement

Table of Contents
loading

Related Manuals for Magnetrol Pulsar R96

Summary of Contents for Magnetrol Pulsar R96

  • Page 1 The PULSAR Model R96 can be used in liquids or slurries to meet the safety system requirements of IEC 61508/IEC 61511-1. Benefits The Magnetrol Model R96 (HART) transmitter pro- ® vides the following benefits to your operation: •...

  • Page 2: Table Of Contents

    Pulsar Model R96 Pulse Burst Radar Level Transmitter ® SIL 2 Capable Table of Contents 1.0 Introduction ..............3 5.6.1 General............7 1.1 Product Description ..........3 5.6.2 Configuration..........7 1.2 Theory of Operation..........3 5.6.3 Write Protecting / Locking ......7 1.3 Determining Safety Integrity Level......3 5.6.4 Write Enabling / Unlocking ......8 2.0 Level Measuring System ..........4 5.7 Site Acceptance Testing ..........8...

  • Page 3: Introduction

    Introduction Product Description The Pulsar Model R96 Pulse Burst Radar Level ® Transmitter is a loop-powered, 24 VDC level transmitter, based on Pulse Burst Radar technology. For Safety Table 1 Instrumented Systems usage it is assumed that the 4–20 mA Pulsar ®...

  • Page 4: Level Measuring System

    Unit The only unsafe mode is when the unit is reading an incor- rect level within the 4-20mA range (> ±2% deviation). MAGNETROL defines a safe failure as one in which the ® Pulsar Model R96 4-20 mA current is driven out of range (i.e., less than 3.8...

  • Page 5: Overvoltage

    2.2.2 Overvoltage The MAGNETROL Model R96 has over-voltage protec- tion per CE requirements. When considering Hi-pot, Fast Transients and Surge, this protection is to 1000 volts. Therefore, there should be no unsafe failure modes up to 1 KV. Overvoltage Category II is a local level, covering appliances, portable equipment, etc., with smaller transient overvoltages...

  • Page 6: Environmental

    See Section 2.3. of Installation and Operating Manual 58-602 for more detailed application information and limitations. 5.1.2 Environmental See Section 3.6 of Installation and Operating Manual 58-602 for environmental limitations. Skill Level of Personnel Personnel following the procedures of this safety manual should have technical expertise equal to or greater than that of a qualified Instrument Technician.

  • Page 7: Configuration

    Logic Solver. Configuration 5.6.1 General The MAGNETROL PULSAR Model R96 can be config- ured via the local display, or via HART compatible hand- held terminal or personal computer. 5.6.2 Configuration Ensure the parameters have been properly configured for the application.

  • Page 8: Write Enabling / Unlocking

    Output current will be driven to 3.6 or 22 mA (customer selectable) upon detection of a Diagnostic Failure. 5.9.2 Troubleshooting Report all failures to MAGNETROL. Refer to Section 3.3 of the PULSAR Model R96 Installation and Operating Manual Bulletin 58-602 for troubleshooting device errors.

  • Page 9: Recurrent Function Tests

    Recurrent Function Tests Proof Testing 6.1.1 Introduction Following are the procedures utilized to detect Dangerous Undetected (DU) failures. The procedure will detect approximately 98.1% of possible DU failures in the Model R96-511*-***. 6.1.2 Interval To maintain the Safety Integrity Level of a Safety Instrumented System, it is imperative that the entire system be tested at regular time intervals (referred to as TI in the appropriate standards).

  • Page 10: Proof Test Procedure

    6.1.4 Proof Test Procedure A suggested proof test is described below. This test will detect approximately 85% of possible DU failures in Model R96-511*-*** of the PULSAR Model R96 Pulse Burst Radar Level Transmitter. 1. Bypass the safety PLC or take other appropriate action to avoid a false trip.

  • Page 11: Ppendices

    Appendices SIL Declaration of Conformity Functional safety according to IEC 61508/IEC 61511 Magnetrol International, Incorporated 705 Enterprise Street, Aurora, Illinois 60504 declares as the manufacturer, that the level transmitter: Pulse Burst Radar (4-20 m ) Model R96-511x-xxx is suitable for the use in safety instrumented systems accord-...

  • Page 12: Fmeda Report- Management Summary

    FMEDA Report: Exida Management Summary 58-650 Pulsar ® Model R96 SIL Functional Safety Manual...
  • Page 13 58-650 Pulsar ® Model R96 SIL Functional Safety Manual...

  • Page 14: Specific Model R96 Values

    Specific Model R96 Values Specific Model R96 PULSAR Product Model R96-511x-xxx SIL 2 92.7% PFD avg 8.47E-04 Proof Test Interval Annually (refer to table below for other periods) Proof Test Interval PFD avg. (months) (SIL 2) 5.47E-04 6.97E-04 8.47E-04 9.98E-04 1.15E-03 1.30E-03 1.45E-03...

  • Page 15: Pfd Graph

    PFD Graph (t) PULSAR Model R96 9.00E-03 8.00E-03 7.00E-03 6.00E-03 5.00E-03 4.00E-03 3.00E-03 2.00E-03 1.00E-03 0.00E+00 Years Report: Lifetime of Critical Components Although a constant failure rate is assumed by the proba- bilistic estimation method, this only applies provided that the useful lifetime of components is not exceeded.
  • Page 16 61511-1 Mod) – Informative” Disclaimer The SIL values in this document are based on an FMEDA analysis using exida’s SILVER Tool. MAGNETROL accepts no liability whatsoever for the use of these numbers of for the correctness of the standards on which the general calculation methods are based.
