Pro-Line System CS300 Operating Instructions Manual page 9

5.6 Connection of closing edge safety device
Terminal block X4
Opto-electronic closing edge safety device
10
9
ws
8
gr
7
br
6
5
4
3
-
2
+
1
ws: white
gr: green
br: brown
Terminal block X4
Electrical closing edge safety device (8.2 kΩ)
10
9
8
7
6
5
8k2
4
3
2
1
for external switching devices
1
(connection to terminals 1 and 2)
- OPTO closing edge
safety device
- 24 V DC / 250 mA
1
- Closing edge safety
device 8.2 kΩ
- 24 V DC / 250 mA
1
Terminal block X4
Pneumatic closing edge safety device (pressure sensor test)
10
9
8
7
6
5
4
3
-
2
+
1
5.7 Photocell connection
(effective in down direction)
Terminal block X4
Photocell NC
10
9
8
7
6
5
4
- Drive-through photocell
3
2
GND
+
1
Terminal block X4
Three-wire NPN photocell
10
9
8
7
6
5
Sig
4 NPN
- Three-wire NPN photocell
3
GND
2
+
1
CS 300 Gate Controls / Rev.D 5.6 – 9
Pro-Line
SYSTEM
- Pneumatic closing
edge safety device
- 24 V DC / 250 mA
1
EN
