F. Functions for external accessories
MOD Description
MOD 13 Magnetic lock function
MOD 20 Activation of infrared transmission system
MOD 21 Test of draw-in protection
MOD 22 Activation of radio transmission systems 1 and 4
MOD 24 Capacitor switching
MOD 25 Yard light function
MOD 26 Activation of radio transmission systems 2 and 4
MOD 28 Relay ON
MOD 29 Relay OFF
Remarks
Activation of an electromechanical locking system. The relay closes the contact
before every OPENING run and remains active until the door is closed again. In
standby, with the door closed, the relay contact is opened.
A delay in starting the door operator can be set with the parameters "DELAY UP"
and "PREWARNING".
Before every DOWN command, the infrared transmission system is activated for the
duration of the closing run.
This activation results in a 0.5 second delay in starting.
The relay generates a test signal when the CLOSED end position is reached and
expects, as a reaction to the test signal, that the stop circuit is actuated.
The relay generates a test signal when the OPEN end position is reached and
expects, as a reaction to the test signal, that the closing edge safety device input is
actuated.
Whenever a door movement command is given, the relay closes for approximately 1
second. With the aid of this relay, an additional starting capacitor that is required for
AC applications is switched on, to ensure safe starting of the motor.
For operators of the STAW range with increased duty cycle.
At every OPEN command, the relay is closed for 2 minutes and can therefore be used
to control a light.
Before every CLOSE command, the radio transmission system is activated by an
impulse. The duration of the activation must be set on the transmission system.
This activation results in a 0.5 second delay in starting.
The relay is switched on with a 1 second time lag once the mains voltage is switched
on and remains on continuously provided that the mains power supply is not
interrupted.
The relay is generally switched off; the contact is always open.
