Pro-Line System CS300 Operating Instructions Manual page 22

Pro-Line
SYSTEM
Overview of functions
Function Description
PR.INPUT Programmable input. Connection to terminal block X4 (9 + 10)
MOD1: PART UP button 1
When the button is pressed, the door opens as far as the intermediate
OPEN position (PART UP).
The door does not close automatically from the PART UP position.
MOD2: PART UP 1 switch
Closed: All OPEN commands lead to the PART UP position.
Open:
The door closes automatically from both positions.
MOD3: PART UP 2 switch
Closed: All OPEN commands lead to the PART UP position.
Open:
The door closes automatically from the PART UP position only.
MOD4: PART UP 3 switch
Closed: All OPEN commands lead to the PART UP position.
Open:
The door closes automatically from the PART UP position only.
MOD5: PART UP 2 button
When the button is pressed, the door opens as far as the intermediate OPEN
(PART UP) position. The door closes automatically from the PART UP
position only.
MOD6: "Automatic closing" activation
Closed:
Open:
MOD7: External clock input
The door opens once the contact closes and remains in the OPEN
position until the contact opens. The door then closes automatically. This
function can be aborted by pressing the CLOSE button. The door CLOSES.
MOD8: Selector switch: Keeping the door open / alarm
Closed:
Open:
MOD9: Continuously CLOSED signal 1
Closed:
Open:
MOD10: Continuously CLOSED signal 2
As MOD9, but after the closing edge safety device has triggered 3 times
and after a reversing movement of 750 ms, the door remains in the
position it was in.
MOD11: Selector switch: Keeping the door open / alarm
Closed:
Open:
P/E BAR Function of the photocell (X4 / 1-4) during the closing run.
CLOSE MOD1: Stops the system when actuated
MOD2: Stop and reversal of the door system when triggered
P/E BAR Function of the photocell (X4 / 1-4) during the opening run.
OPEN MOD1: Photocell not activated
MOD2: When the photocell is activated during the CLOSED end position and the
S-POINT2 position, the door system stops. The red traffic light is ON. The
S-POINT2 is automatically set to CLOSED end position + 600 inc.
22 – CS 300 Gate Controls / Rev.D 5.6
All OPEN commands lead to the OPEN position.
All OPEN commands lead to the OPEN position.
All OPEN commands lead to the OPEN position.
Automatic closing deactivated
Automatic closing activated
The door moves to the PART UP position and remains
there as long as the contact is closed.
Normal operation
Door CLOSES with active safety devices and remains
in the CLOSED position until the contact opens. OPEN
commands are ignored. If the closing edge safety edge
(SKS) is triggered 3 times during the closing run, the
door remains in the OPEN position.
Normal operation
The door moves to the OPEN position and remains
there as long as the contact is closed.
Normal operation
Setting options Factory settings
MOD1 – MOD11 MOD1
MOD 1 – MOD 2 MOD 2
MOD 1 – MOD 2 MOD 1
