9.2 Input operating mode
Function Description
DEUTSCH Select the menu language
RUNTIME Monitoring the maximum running time for an OPEN or CLOSE movement.
The running time must be set to be slightly higher than the effective running time of
the door.
OPEN TIME After the door has opened, it runs back automatically in the CLOSING direction after
the set time has elapsed.
If the setting = 0, this function is not active.
If the setting > 0 the impulse input (X3 / 7+8) generates only OPEN commands.
Please note:
If you press the CLOSE button during the open time, the closing run starts immedia-
tely.
If you press the OPEN or STOP button during the open time, the time starts counting
from the beginning again.
If an automatic closing run is interrupted by the SKS, the door opens and the open run
starts counting again from the beginning. If this happens 3 times in a row, automatic
closing is interrupted.
PREWARNING The prewarning is activated before an automatic closing run starts and before closing
in impulse mode.
If the setting = 0, this function is not active.
Please note:
The relay outputs can be used to visualise the prewarning time, e.g. with a red traffic
light.
REVERS.TIME Motor stoppage time each time the door changes direction.
When the closing edge safety device is triggered during the closing movement, the
turnaround time amounts to a quarter of the programmed time.
M1-3 STAND. Red traffic light function (if available and programmed) in standby MOD1 - MOD2,
MOD1 if door is closed. Acts on relay settings MOD1-3 and MOD18.
MOD1: Relay switched off in standby (door closed).
MOD2: Relay switched on in standby (door closed).
QUICK Earlier closing after the photocell has been driven past.
CLOSE
Requirements:
A photocell must be installed at passage height.
OFF: The open time (if programmed) continues as usual.
ON: The open time is cut short after the photocell (X4 / 1-4) has been passed.
The door closes immediately.
This function is also active when the open time = 0.
Pro-Line
SYSTEM
Setting options Factory settings
DEUTSCH DEUTSCH
ENGLISH
FRANCAIS
ESPANOL
NEDERLANDS
POLSKI
CESKY
ITALIANO
1 - 250 seconds 60
0 - 600 seconds 0
0 - 120 seconds 0 = Off
0.1 - 2.0 seconds 0.3
(in 1/10 seconds)
MOD1 – MOD2 MOD1
ON OFF
OFF
