Kusam-meco KM 086 Operation Manual

An ISO 9001:2008 Company
SPECIAL FEATURES :
TM
AmpTip low-current range calibrated at Jaw-tip for slim-conditions for accurate readings
MAX/MIN/AVG Recording mode (Auto ranging)
VFD-V & Hz for fundamental V/Hz of most Variable-Frequency-Drives
Display Hold & Non-Contact EF-Detection (NCV)
Back-lighted easy-to-read LCD display
Fast 80ms Peak-RMS mode to capture in-rush currents
Auto-ranging Relative mode with DC-Zero mode & 5ms Crest (Instantaneous Peak-Hold) mode
3-Phase Rotation-R for MAINS supply (Probe contact)
3-Phase Rotation-M (Hi-sensitivity mode) for Motors (Probe-contact)
GENERAL SPECIFICATIONS :
Sensing : AC; True RMS
Jaws Opening size & conductor diameter : 51mm Max.
Display : 3-5/6 digits 6000 counts
Update Rate : 5 per second nominal
Polarity : Automatic
Operating Temperature : -10ºC to 50ºC
Relative Humidity : Non condensing
decreasing linearly to 75% R.H. at 30-40°C & 45% R.H. at 40-50°C
Altitude : Operating below 2000m; Storage below 12000m
Storage Temperature : -20°C ~ 60°C, < 80% R.H. (with battery removed)
Temperature Coefficient : Nominal 0.10 x (specified accuracy) / C @ (-10 C –– 18 C or 28 C –– 50 C),
or otherwise specified
Power Supply : Standard 1.5V AA Battery x 2
Power Consumption : typical 4.3mA
Low Battery : Below approx. 2.85V for Capacitance & Hz
Below approx. 2.5V for other functions
APO timing : Idle for 32 minutes
APO Consumption : typical 5 A
Dimension : 258(L) x 94(W) x 44(H)mm
Weight : approx 312 gms.
SAFETY :
Safety : Double insulation per UL/IEC/EN61010-1 Ed. 3.0, IEC/EN61010-2-033 Ed. 1.0, CAN/CSA C22.2
No. 61010-1 Ed. 3.0, IEC/EN61010-2-032 Ed. 3.0 & IEC/EN61010-031 Ed. 1.1
Measurement Category : CAT III 1000V AND CAT IV 600V AC & DC
E.M.C. : Meets EN61326-1 : 2006 (EN55022, EN61000-3-2, EN61000-3-3, EN61000-4-2, EN61000-4-3,
EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11) :
ACA, DCA and DC+ACA Functions, in an RF field of 1V/m :
Total Accuracy = Specified Accuracy + 60 digits at around 200MHz~350MHz
DC A and Ohm Functions, in an RF field of 1V/m : Total Accuracy = Specified Accuracy + 80 digits
Other Functions, in an RF field of 3V/m : Total Accuracy = Specified Accuracy + 20 digits
Overload Protection :
Current & Hz functions via jaws : 1000ADC/AAC rms at <400Hz
Voltage & 3-Phase Rotation functions via terminals : 1100VDC/ VAC rms
Other functions via terminals : 1000VDC/ VAC rms
Pollution Degree : 2
Transient Protection : 8.0kV (1.2/50 s surge)
Rugged Fire retarded casing.
LVD EN61010-2-032/EN61010-2-033 to CAT III 1000V & CAT IV 600V
ACCESSORIES :
Test leads set, Users Manual, Soft carrying pouch, Bkp60 banana plug K-type thermocouple, Alligator Clip set,
BKB32 banana plug to type-K socket plug adaptor (for optional purchase)
®
An ISO 9001:2008 Company
Chhaya com/D/chhaya/my documents/chhaya/backup/catlog/New catlog/2013-2014/KM 086.cdr
®
1000A AC TRUE RMS DIGITAL CLAMPMETER WITH
VFD, EF-DETECTION, AMPTIP FUNCTION FOR LOW CURRENT
MEASUREMENT & 3 PHASE ROTATION CHECK FUNCTION &
( 10ºC) Maximum 90%R.H. at 10-30°C
o
G-17, Bharat Industrial Estate, T. J. Road, Sewree (W), Mumbai - 400 015. INDIA.
Sales Direct.: 022-24156638,
Email : kusam_meco@vsnl.net,
3 PHASE SEQUENCE INDICATION
o o o o
All Specifications are subject to change without prior notice
Tel. : 022-24124540, 24181649,
MODEL KM 086
25 Functions 32 Ranges
Preliminary Data
Fax : 022-24149659
Website : www.kusamelectrical.com
