Technical data
Electrical data, load voltage supply [X9A]
CMMT-AS
Required quality of the
mains supply
Short circuit current
rating (SCCR)
Alternative DC supply
feed
1) dependent on the network impedance; if a line inductor is used, somewhat less mains current results
Tab. 99 Load voltage supply
Electrical data, logic voltage supply
CMMT-AS-
Logic voltage range
Nominal voltage
Current consumption
(without holding brake,
CDSB, digital I/Os and
auxiliary supply out-
puts without load)
Current consumption
(with holding brake)
Current consumption
(with holding brake,
with CDSB, digital I/Os
and auxiliary supply
outputs with load and
with fan, if present)
Starting current (with
28.8 V)
Protective functions
Tab. 100 Logic supply
Intermediate circuit and brake chopper
Festo — CMMT-AS-C2/C4-3A-... — 2018-02
C2-3A
Corresponds to the requirements of EN 61800-3, if not specified
otherwise
[A] 10000
[V DC] 80 360
...
C2-3A
[V DC] 24 ± 20 %
[V DC] 24
[A] 0.5
[A] 1.3
[A] 2.1
[A] 20
<
– Overvoltage
– Polarity reversal
– Short circuit to 0 V (24 V outputs)
C4-3A
C4-3A
1.5
2.3
91
