Switch settings

Start address End address
0xEFF40000 0xEFFFFFFF
0xEFF20000 0xEFF3FFFF
0xEFF10000 0XEFF1FFFF
0xEFF00000 0xEFF0FFFF
0xED300000 0xEFEFFFFF
0xEC800000 0xEC8FFFFF
0xEC020000 0XEC7FFFFF
0xEC000000 0XEC01FFFF
0xEBF40000 0XEBFFFFFF
0xEBF20000 0XEBF3FFFF
0xEBF10000 0XEBF1FFFF
0XEBF00000 0XEBF0FFFF
0xE9300000 0XEBEFFFFF
0XE8800000 0XE88FFFFF
0xE8020000 0xE86FFFFF
0xE8000000 0xE801FFFF
4.4 Switch settings
This chapter defines the default switch settings and other boot source settings.
You may find slightly different default switch settings,
depending on the SDK being used; check the relevant
information.

4.4.1 Switch default settings (NOR flash boot)

This section defines the default switch settings for NOR flash boot.
ON and OFF are being represented as 0 and 1 respectively, on
the board.
QorIQ T1040 Reference Design Board User Guide, Rev. 0, 06/2015
58
Table 4-2. Image layout in NOR flash
U-Boot (current bank)
U-Boot env (current bank)
QUICC Engine microcode (current bank)
FMan microcode (current bank)
rootfs (alternative bank)
Hardware device tree (alternative bank)
Linux.uImage (alternative bank)
RCW (alternative bank)
U-Boot (alternative bank)
U-Boot env (alternative bank)
QUICC Engine microcode (alt bank)
FMan microcode (alternative bank)
rootfs (current bank)
Hardware device tree (current bank)
Linux.uImage (current bank)
RCW (current bank)
NOTE
NOTE
Image Max size
768KB
128KB
64KB
64KB
43MB
1MB
7MB+875KB
7MB+875KB
768KB
128KB
64KB
64KB
43MB
1MB
7MB+875KB
128KB
