D O C - 0 5 0 0 - 0 1 0 ,
R E V
F
TWR-S08
Demonstration Board for Freescale MC9S08LL and
MC9S08LH Families of Microcontrollers
USER GUIDE
www.axman.com
Web Site:
support@axman.com
Support:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TWR-S08 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NXP Semiconductors TWR-S08

Summary of Contents for NXP Semiconductors TWR-S08

  • Page 1 D O C - 0 5 0 0 - 0 1 0 , R E V TWR-S08 Demonstration Board for Freescale MC9S08LL and MC9S08LH Families of Microcontrollers USER GUIDE www.axman.com Web Site: support@axman.com Support:...

  • Page 2: Table Of Contents

    T W R - S 0 8 L L / L H U S E R G U I D E A P R I L 2 7 , 2 0 1 0 U S E R G U I D E CONTENTS CAUTIONARY NOTES ......................
  • Page 3 Date Comments October 5, 2009 Initial Release October 6, 2009 Updated board name to TWR-S08 thru-out Updated References section to correct document names and remove October 7, 2009 Support CD. Updated Figures to show board reference designators March 23, 2010 Removed References section.

  • Page 4: Cautionary Notes

    3) EMC Information on the TWR-S08 board: a) This product as shipped from the factory with associated power supplies and cables, has been verified to meet with requirements of CE and the FCC as a CLASS A product.

  • Page 5: Features

    All MCU signals are available on one or both edge connectors. For purposes of this document, the TWR-S08 is described without regard to the MCU installed. Exceptions will be clearly noted. ...

  • Page 6: Getting Started

    PC to disconnect the board. Damage to the host PC, target board, or Tower System may result if this current limit is violated. NOTE: The OSBDM will not connect to the TWR-S08 board if the target MCU is in STOP mode. Wake the target device with an external event then connect to the target.

  • Page 7: Osbdm Bootloader

    T W R - S 0 8 L L / L H U S E R G U I D E A P R I L 2 7 , 2 0 1 0 U S E R G U I D E CAUTION: When powered from the USB bus, do not exceed the 500mA maximum allowable current drain.

  • Page 8: Power

    The external BDM is now ready for use. POWER The TWR-S08 board may be powered from the OSBDM or from the Tower System. 190mAH battery holder is applied for battery-powered operation. The USB current limit must be observed while using the USB connection from the host PC to supply power to the target board.

  • Page 9: Vdd_En

    T W R - S 0 8 L L / L H U S E R G U I D E A P R I L 2 7 , 2 0 1 0 U S E R G U I D E Figure 2: V_SEL Option Header, JP8 ...

  • Page 10: Low Voltage Reset

    Consult the target device RM for details on LVD operation. TIMING The TWR-S08 uses the MC9S08LL or MC9S08LH internal timing source by default. external 32 kHz XTAL oscillator, configured for low-power operation, is also provided. Consult the target device RM for details on configuring the selected timing source.

  • Page 11: Com Connector

    ● ● ● The TWR-S08 applies a GD-5306P, 2x28 chip-on-glass, LCD connected directly to the target MCU. The target MCU provides the internal charge-pump and regulated LCD reference voltage required by the LCD. LCD contrast is trimmable under MCU control. Refer to the target device RM for further details on configuring using the LCD interface.

  • Page 12: Accelerometer

    G U I D E ACCELEROMETER The TWR-S08 applies the MMA7361L, 3-axis, analog accelerometer for tilt and motion-sense applications. The accelerometer supports 2 user selectable sensitivities - 1.5g / 6g. The SLEEP* input allows the device to be placed in a low-power mode. Separate X-, Y-, and Z- axis readings are routed to the MCU.

  • Page 13: Vdd1 Enable

    SW 1 may not function properly. Pushbutton Switches The TWR-S08 applies 4, normally open, push-button switches for user input. Each push- button switch is configured for active-low operation. A 22pF capacitor is applied to each push- button switch to minimize switch bounce.

  • Page 14: User Led's

    (*) – Default Position Potentiometer The TWR-S08 board provides a 5K ohm potentiometer (POT) to simulate analog input. The POT is decoupled to minimize noise during adjustment. Figure 12 below shows the USER enable position and associated signal for the buzzer.

  • Page 15: Differential Adc Input

    Rev B boards. EDGE CONNECTOR PIN-OUT The TWR-S08 board connects to the Freescale Tower System using the 2 PCIe Edge Connectors. Note that according to the PCIe specification, the Bx signals are located on the top of the board and the Ax signals are located on bottom. Pin B1 for the primary and secondary connectors are at opposite ends of the board.
  • Page 16 T W R - S 0 8 L L / L H U S E R G U I D E A P R I L 2 7 , 2 0 1 0 U S E R G U I D E Mechanical Key Pri_B12 Pri_A12...

  • Page 17: Figure 15: Secondary Edge Connector, J2

    T W R - S 0 8 L L / L H U S E R G U I D E A P R I L 2 7 , 2 0 1 0 U S E R G U I D E Pri_B61 Pri_A61 PTC7/IRQ/TCLK...
  • Page 18 T W R - S 0 8 L L / L H U S E R G U I D E A P R I L 2 7 , 2 0 1 0 U S E R G U I D E Sec_B24 Sec_A24 Sec_B25...
  • Page 19 T W R - S 0 8 L L / L H U S E R G U I D E A P R I L 2 7 , 2 0 1 0 U S E R G U I D E Sec_B74 Sec_A74 LCD9...
