TWR-KL28Z User's Guide

1. Introduction

The Tower development platform is a set of software
and hardware tools for evaluation and development. It is
an ideal tool for the rapid prototyping of
microcontroller-based applications.
The TWR-KL28Z supports power supply voltage range
from 1.71 V to 3.6 V. It features a KL28Z, a device
boasting a maximum operating frequency of 72 MHz,
up to 512 KB Flash and numerous analog and digital
peripherals.
The TWR-KL28Z includes the ARM open standard
embedded serial and debug adapter known as CMSIS-
DAP. This circuit offers the user several options for
serial communications, flash programming, and run-
control debugging.
The TWR-KL28Z microcontroller module is designed
to work either in standalone mode or as part of the
Tower System, a modular development platform that
enables rapid prototyping and tool re-use through
reconfigurable hardware.
© 2016 NXP B.V.
Document Number: TWRKL28ZUG
Contents
1.
Introduction .................................................................... 1
2.
Getting Started ................................................................ 2
3.
TWR-KL28Z Features ..................................................... 2
4.
TWR-KL28Z Hardware Description ................................ 4
4.1.
Power supply ........................................................ 4
4.2.
Serial and debug adapter (OpenSDA) .................... 5
4.3.
Microcontroller ..................................................... 6
4.4.
Capacitive touch pad ............................................. 9
4.5.
I2C Accelerometer Sensor ..................................... 9
4.6.
LED ................................................................... 11
4.7.
Analog reference voltage..................................... 11
4.8.
Input/output headers............................................ 12
5.
References .................................................................... 13
6.
Revision History ........................................................... 13
Rev. 0 , 06/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TWR-KL28Z and is the answer not in the manual?

Questions and answers

Summary of Contents for NXP Semiconductors TWR-KL28Z

  • Page 1: Table Of Contents

    4.1. Power supply ............4 4.2. Serial and debug adapter (OpenSDA) ....5 The TWR-KL28Z supports power supply voltage range 4.3. Microcontroller ............. 6 from 1.71 V to 3.6 V. It features a KL28Z, a device 4.4. Capacitive touch pad ..........9 4.5.
  • Page 2: Getting Started

    I/O with a large ecosystem of compatible hardware, a flexible programming and debug interface, and a large ecosystem of software development environments. 2. Getting Started Refer to the TWR-KL28Z Quick Start Package for step-by-step instructions for getting started with the freedom board. See the “Jump Start Your Design” section at nxp.com/FREDEVPLA for the Quick Start Package and software lab guides.
  • Page 3 TWR-KL28Z Features Figure 1. TWR-KL28Z block diagram Figure 2. TWR-KL28Z feature call-outs TWR-KL28Z User’s Guide, Rev. 0, 06/2016 NXP Semiconductors...
  • Page 4: Twr-Kl28Z Hardware Description

    4.1. Power supply The TWR-KL28Z offers a design with multiple power supply options. It can be powered from the USB connector, the VIN pin on the I/O header, or an off-board 1.71-3.6 V supply from the 3.3 V pin on the I/O header.
  • Page 5: Serial And Debug Adapter (Opensda)

    10-pin Cortex Debug connector (J30) as shown in Figure 5. In order to isolate the KL28Z MCU from the CMSIS-DAP circuit and use J30 to connect to an off-board TWR-KL28Z User’s Guide, Rev. 0, 06/2016 NXP Semiconductors...
  • Page 6: Microcontroller

    (CDC) interface that bridges serial communications between the USB host and this serial interface. 4.3. Microcontroller The TWR-KL28Z is a MCU module featuring the MKL28Z512VLL7, a Kinetis microcontroller with USB 2.0 full-speed OTG controller in a 100 LQFP package. An on-board debug circuit, CMSIS-DAP, provides a SWD interface and a power supply input through a mini-USB connector, as well as serial to USB and CDC class compliant UART interface.
  • Page 7 32 MHz. An 8 MHz crystal is the default external source for the SCG oscillator inputs (XTAL/EXTAL). 4.3.2. Serial port The primary serial port interface signals are PTA1 and PTA2. These signals are connected to both the CMSIS-DAP and to the J1 I/O connector. TWR-KL28Z User’s Guide, Rev. 0, 06/2016 NXP Semiconductors...
  • Page 8 The Kinetis KL28 microcontrollers feature a dual-role USB controller with on-chip full-speed and low- speed transceivers. The USB interface on the TWR-KL28Z is configured as a full-speed USB device. J29 is the USB connector for this interface. As shown in Figure 6.
  • Page 9: Capacitive Touch Pad

    It is interfaced through an I C bus and two GPIO signals as shown in Figure 8 Table 5 below. By default, the I C address is 0x1D. TWR-KL28Z User’s Guide, Rev. 0, 06/2016 NXP Semiconductors...
  • Page 10 TWR-KL28Z Hardware Description Figure 8. MMA8451Q schematic diagram Table 5. Accelerometer FXOS8700CQ signal connections MMA8451Q KL28Z PTC11 PTC10 INT1 PTC5 INT2 PTC6 TWR-KL28Z User’s Guide, Rev. 0, 06/2016 NXP Semiconductors...
  • Page 11: Led

    Voltage Low (VREFL) pins to set high and low voltage references for the analog modules. By default VREFH is attached to P3V3_KL28Z (3.3 V Supply). VREFL is connected to GND. Figure 10. VREFH circuit schematic If desired, VREFH can use a VDDA independent reference by cut J35 jumper. TWR-KL28Z User’s Guide, Rev. 0, 06/2016 NXP Semiconductors...
  • Page 12: Input/Output Headers

    The MKL28 MCU is packaged in a 100-pin LQFP. Some pins are utilized by on-board circuitry, but many are directly connected to one of four I/O headers (J13, J25, J24, J26) as shown in Figure 11 below. Figure 11. Input/output header TWR-KL28Z User’s Guide, Rev. 0, 06/2016 NXP Semiconductors...
  • Page 13: References

    Revision History 5. References The reference documents for the TWR-KL28Z hardware are shown below. All documents can be found nxp.com • TWR-KL28Z Quick Start Guide • TWR-KL28Z User’s Guide • TWR-KL28Z Schematics PDF • KL28 Sub-Family Reference Manual 6. Revision History Table 6.
