  • Page 1 TWR-K70F120M Tower Module User's Manual Rev. 1.2 Freescale Semiconductor Inc.

  • Page 2: Table Of Contents

    Table of Contents 1 TWR-K70F120M and TWR-K70F120M-KIT Overview ............... 5 1.1 Contents ....................................6 1.2 Features ....................................6 1.3 Getting Started ..................................8 1.4 Reference Documents ............................... 8 2 Hardware Description ........................... 8 2.1 K70FN1M0 Microcontroller ............................9 2.2 Clocking ....................................10 2.3 System Power ..................................
  • Page 3 List of Figures Figure 1. Freescale Tower System Overview ....................5 Figure 2. Callouts on front side of the TWR-K70F120M ................7 Figure 3. Callouts on back side of the TWR-K70F120M ................7 Figure 4. TWR-K70F120M Block Diagram ....................9 List of Tables Table 1.
  • Page 4 Updated USB section to include instruction for May 29, 2014 connections to allow for USB OTG testing. TWR-K70F120M Tower Module User's Manual Page 4 of 25...

  • Page 5: Twr-K70F120M And Twr-K70F120M-Kit Overview

    1 TWR-K70F120M and TWR-K70F120M-KIT Overview The TWR-K70F120M is a development board for the K61 and K70 family 32-bit ARM® Cortex™-M4 MCUs. The TWR-K70F120M is populated with a device rated for 120 MHz operation across the full -40C to 85C temperature range. At room temperatures the board can be over-clocked to 150 MHz to allow for evaluation of the K70 and K61 devices that are rated for 150 MHz operation across the full temperature range.

  • Page 6: Contents

    1.1 Contents The TWR-K70F120M contents include:  TWR-K70F120M board assembly  3ft USB cable  Interactive DVD with software installers and documentation  Quick Start Guide The TWR-K70F120M-KIT contains:  TWR-K70F120M MCU module  TWR-ELEV – Primary and Secondary Elevator Modules ...

  • Page 7: Figure 2. Callouts On Front Side Of The Twr-K70F120M

    Figure 2. Callouts on front side of the TWR-K70F120M Figure 3. Callouts on back side of the TWR-K70F120M TWR-K70F120M Tower Module User's Manual Page 7 of 25...

  • Page 8: Getting Started

    1.3 Getting Started Follow the Quick Start Guide found printed in the TWR-K70F120M box or the interactive DVD for the list of recommended steps for getting started. There are also lab walk-through guides available on the tool support page for the TWR-K70F120M: http://www.freescale.com/TWR-K70F120M. 1.4 Reference Documents The documents listed below should be referenced for more information on the Kinetis family, Tower System, and MCU Modules.

  • Page 9: K70Fn1M0 Microcontroller

    Tower Elevator Expansion Connectors 5.0V 3.3V SDHC, I S, SPI, I C, ADC, USB, DAC, PWM, UARTs, Flexbus, Ethernet, LCD, and ULPI 32.768 KHz XTAL 12 MHz XTAL 50 MHz OSC IR Output 5.0V Infrared Port Comparator JTAG OSJTAG K70FN1M0 JTAG, Power, SCI GPIO / Interrupts Mini-B...

  • Page 10: Clocking

     SPI, I C (w/ SMBUS support), UART (w/ ISO7816, CEA709.1-B (LON), and IrDA support), CAN, I  SD Host Controller (SDHC)  GPIO with pin interrupt support, DMA request capability, digital glitch filtering  Capacitive touch sensing inputs (TSI) ...

  • Page 11: Rtc Vbat

    2.3.1 RTC VBAT The Real Time Clock (RTC) module on the K70 has two modes of operation, system power-up and system power-down. During system power-down, the RTC is powered from the backup power supply, VBAT. The TWR-K70F120M provides a battery holder for a coin cell battery that can be used as the VBAT supply.

  • Page 12: Graphical Lcd Interface

    Function TWR-K70F120M Connection TRACEDATA[2] PTA8/FTM1_CH0/FTM1_QD_PHA/TRACE_D2 TRACEDATA[3] PTA7/FTM0_CH4/TRACE_D3 Note: Many of the trace signals connected to the debug connector are also connected elsewhere on the TWR-K70F120M. Refer to Table 6 “I/O Connectors and Pin Usage Table” and Table 7 “TWR- K70F120M Primary Connector Pinout” for more information. 2.5 Graphical LCD Interface The K70FN1M0 processor includes an on-chip graphical LCD controller module.

  • Page 13: General Purpose Tower Plug-In (Twrpi) Socket

    2.11 General Purpose Tower Plug-in (TWRPI) Socket The TWR-K70F120M features a socket that can accept a variety of different Tower Plug-in modules featuring sensors, RF transceivers, and more. The General Purpose TWRPI socket provides access to I2C, SPI, IRQs, GPIOs, timers, analog conversion signals, TWRPI ID signals, reset, and voltage supplies. The pinout for the TWRPI Socket is defined in Table 2.

  • Page 14: Ethernet

    Table 3. Touch TWRPI socket pinout Description 5V VCC 3.3 V VCC Electrode 0 3.3V VDDA Electrode 1 VSS (Analog GND) Electrode 2 Electrode 3 Electrode 4 Electrode 5 Electrode 6 Electrode 7 Electrode 8 Electrode 9 Electrode 10 Electrode 11 ADC: TWRPI ID 0 ADC: TWRPI ID 1 Reset...

  • Page 15: Usb

    TWR-SER TWR-SER TWR-SER 9-10 2.14 USB The K70FN1M0 features two different USB modules--a USB full-speed/low-speed OTG/Host/Device controller with built-in transceiver and a high-speed OTG/Host/Device controller that requires a external ULPI PHY. 2.14.1 FS/LS USB The TWR-K70F120M routes the USB D+ and D- signals from the K70 MCU to the Primary Connector, allowing the connection to external USB connectors or additional circuitry on a Tower peripheral module.

  • Page 16: Jumper Table

    bus can access devices on Tower peripheral modules. Refer to Table 7 “TWR-K70F120M Primary Connector Pinout” and sheet 8 of the TWR-K70F120M schematics for more details. 3 Jumper Table There are several jumpers on the TWR-K70F120M that provide configuration selection and signal isolation.

  • Page 17: Input/Output Connectors And Pin Usage Table

    Power supply to 50MHz oscillator enabled. *ON* (revC 50 MHz oscillator power board) Power supply to 50MHz oscillator disabled. On-board 50MHz oscillator enabled. On-board 50 MHz clock *ON* drives main EXTAL. On-board 50MHz oscillator disabled. Off-board clock drives main EXTAL. 50MHz clock disable.
  • Page 18 E1 / Orange LED PTA11 PTA11 E2 / Yellow LED PTA28 PTA28 LEDs E3 / Green LED PTA29 PTA29 E4 / Blue LED PTA10 PTA10 Potentiometer Potentiometer (R71) ― ADC1_DM1 I2C SDA PTE18 I2C0_SDA I2C SCL PTE19 I2C0_SCL Accelerometer INT1 PTB4 PTB4 INT2...

  • Page 19: Tower Elevator Connections

    RXD0 PTE7 I2S0_RXD0 RX_BCLK PTE9 I2S0_RX_BCLK TX_BCLK PTE12 I2S0_TX_BCLK MCLK PTE6 I2S0_MCLK 5 Tower Elevator Connections The TWR-K70F120M features two expansion card-edge connectors that interface to the Primary and Secondary Elevator boards in a Tower system. The Primary Connector (comprised of sides A and B) is utilized by the TWR-K70F120M while the Secondary Connector (comprised of sides C and D) only makes connections to the GND pins.
  • Page 20 Etherne ETH_TXD1 Ethernet PTA17 ETH_RXD1 PTA12 Etherne ETH_TXD0 Ethernet PTA16 ETH_RXD0 PTA13 GPIO / PTE19 SSI_MCLK GPIO1 / RTS1 UART PTE6 GPIO / PTE0 SSI_BCLK GPIO2 / SDHC_D1 SDHC PTE12 SSI_FS GPIO3 GPIO PTE28 PTE11 SSI_RXD CLKIN0 Clock PTA18 PTE7 SSI_TXD CLKOUT1 Clock...
  • Page 21 Analog SPI0_CS0_b SPI 0 PTD11 VDDA Vref VDDA SPI0_CS1_b SPI 0 PTD15 CANRX1 CAN 1 SPI0_CLK SPI 0 PTD12 CANTX1 CAN 1 Power Ground Power Ground SCL1 I2C 1 PTE19 GPIO14 GPIO SDA1 I2C 1 PTE18 GPIO15 GPIO GPIO5 / GPIO / SD_CARD_DET SDHC...

  • Page 22: Table 8. Twr-K70F120M Primary Connector Pinout

    EBI_D7 PTB20 PTC8 EBI_AD7 EBI_D6 PTB21 PTC9 EBI_AD6 EBI_D5 PTB22 PTC10 EBI_AD5 EBI_D4 PTB23 PTD2 EBI_AD4 EBI_D3 PTC12 PTD3 EBI_AD3 EBI_D2 PTC13 PTD4 EBI_AD2 EBI_D1 PTC14 PTD5 EBI_AD1 EBI_D0 PTC15 PTD6 EBI_AD0 Power Ground Power Ground 3.3V Power 3.3V Power 3.3V Power 3.3V Power...
  • Page 23 GPIO18 GPIO ETH_RXDV Ethernet GPIO / GPIO / GPIO19 / SDHC_D4 GPIO27 / SDHC_D6 SDHC SDHC GPIO / GPIO / GPIO20 / SDHC_D5 GPIO28 / SDHC_D7 SDHC SDHC ETH_TXD1 Ethernet ETH_RXD1 Ethernet ETH_TXD0 Ethernet ETH_RXD0 Ethernet ULPI_NEXT / ULPI / USB ULPI_DATA0 / ULPI / USB1_DM...
  • Page 24 UART 2 / LCD_CONTRAST Display PTC18 RTS2 / TSI2 UART 2 / LCD_OE / LCD_P27 Display PTF1 CTS2 / TSI3 UART 3 / LCD_D0 / LCD_P0 Display PTF4 RXD3 / TSI4 UART 3 / LCD_D1 / LCD_P1 Display PTF5 TXD3 / TSI5 UART 3 / LCD_D2 / LCD_P2 Display...
  • Page 25 EBI_AD24 / EBI / EBI_TSIZE0 / EBI / LCD_P46 Display LCD_P32 Display EBI_AD25 / EBI / EBI_TSIZE1 / EBI / LCD_P47 Display LCD_P33 Display EBI_AD26 / EBI / EBI / LCD_P48 Display EBI_TS_b / LCD_P34 Display EBI_AD27 / EBI / EBI_TBST_b / EBI / LCD_P49...
