Summary of Contents for NXP Semiconductors TRK-MPC5606B

  • Page 1 Quick Start Guide TRK-MPC5606B StarterTRAK Development Board StarterTRAK...
  • Page 2 Figure 1: TRK-MPC5606B Board* TRK-MPC5606B Freescale StarterTRAK The TRK-MPC5606B board is part of the Freescale StarterTRAK series, a development platform that enables rapid prototyping and tool re-use. Take your design to the next level and begin constructing with your StarterTRAK system today.
  • Page 3 In this Quick Start Guide, you will learn how to install the software tools provided in the Fast Start Kit for TRK-MPC5606B installation media, how to set up TRK-MPC5606B board and run a LED example that demonstrates all the software tools provided with the installation media.
  • Page 4 Read the release notes and the PC and the other end to the mini-B documentation located on the DVD and at connector on the TRK-MPC5606B board. freescale.com/StarterTRAK. Allow the PC to automatically configure the • The Qorivva Simple Cookbook provides USB drivers if needed.
  • Page 5 TRK-MPC5606B TRK-MPC5606B Jumper Options Jumper Option Setting Description External Power 9 V DC to 12 V DC Regulated Down to 5 V DC System Power USB OSBDM Supplies 5 V DC SBC33905 Supplies 5 V DC Pull Up SBC I/O LED Pull...
  • Page 6 Quick Start Guide TRK-MPC5606B Jumper Options (continued) Jumper Option Setting Description LIN1 Signals to 1-2, 3-4 Connects LIN1 Signals to LIN1 Connector Connector Enable MCU LIN0TX to Transceiver LIN TXD Signal MCU LIN1TX to Transceiver MCU LIN0RX to Transceiver LIN RXD Signal...
  • Page 7 TRK-MPC5606B TRK-MPC5606B Jumper Options (continued) Jumper Option Setting Description Pushbutton Pull Pull Up Up/Down Enable, Pull Down Opposite of J24 Pushbutton signals 1-2, 3-4, Connects MCU port PE0, PE1, PE2 and PE3 to Corresponding Enable 5-6, 7-8 push buttons 1-2, 3-4,...
  • Page 8: Warranty Information

    Quick Start Guide Support Visit freescale.com/support for a list of phone numbers within your region. Warranty Visit freescale.com/warranty for complete warranty information. For more information, visit freescale.com/StarterTRAK Freescale, the Freescale logo and CodeWarrior are trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Qorivva is a trademark of Freescale Semiconductor, Inc.
