- Page 1 Quick Start Guide TWR-S08PT60 5-Volt S08P Family of 8-bit MCUs for Industrial and Appliance Applications TOWER SYSTEM...
- Page 2 Connector TWR-S08PT60 Freescale Tower System The TWR-S08PT60 module is a part of the Freescale Tower System, a modular development platform that enables rapid prototyping and tool re-use through reconfigurable hardware. Elevate your design to the next level and begin constructing your Tower System today.
- Page 3 It can function as a stand-alone, low-cost platform for the evaluation of MC9S08PT60 devices. There is an OSBDM module on the TWR-S08PT60 which can be used to debug MC9S08PT60 devices on both the TWR-S08PT60 module and external customer boards.
- Page 4 Quick Start Guide Step-by-Step Installation Instructions In this quick start guide, you will learn how to set up the TWR-S08PT60 module and run the lab code. Install Software • Go to the Help menu in the current window and Tools • Select “Install New Software” item Please insert the provided DVD into your from the drop down menu computer.
- Page 5 “Install/Install TWR-S08PT60 Module Details” dialog will appear. Select the Service Pack and click “Finish.” Remove the TWR-S08PT60 module from This will automatically install all the anti-static pouch. Ensure the jumpers Service Pack dependencies are in the default positions as shown in • Select the “I accept the terms of...
- Page 6 Quick Start Guide Step-by-Step Installation Instructions (cont.) Start CodeWarrior and 3. Click “File > Import…” menu item to open Import dialog. In the Import Debug Environment dialog, double click “General” and 1. Start CodeWarrior by selecting it from select the “Existing Projects into the Windows Start menu. Workspace”...
- Page 7 Run and Debug Lab Code 7. Click the lab project name to highlight it. Click the “Project > Clean…” menu on TWR-S08PT60 Module item to bring up the Clean dialog. In From the main menu, choose this dialog, check “Clean projects “Run >...
- Page 8 9. Now that you have successfully and stop program execution after completed the software and hardware the routine returns to its caller. This setup, you may continue to explore command causes execution to return TWR-S08PT60 labs by following up the call chain. TWR-S08PT60 Labs Tutorial.
- Page 9 USB port on your computer to to program your own boards by following the mini-B USB connector on the the steps below. TWR-S08PT60 module. Allow the 1. Configure J16 and J28 jumpers as below: PC to automatically configure the USB drivers as needed. USB drivers for your...
- Page 10 Quick Start Guide TWR-S08PT60 Default Jumper Options The following is a list of all default jumper options. Jumper Setting Description 1 – 2 USB to UART2 (Rx) 1 – 2 USB to UART2 (Tx) 2 – 3 UART (SCI0 Tx) 5 – 6 UART (SCI0 Rx) 11 – 12 Infrared (Tx) 14 – 15 Infrared (Rx) 3 – 5 UART (Rx to Tx) 1 – 2...
- Page 11 Power supply 3.3-volt selection 2 – 3 Power supply level selection 1 – 2 OSBDM to on-board PT60 (/RESET) 1 – 2 Power supply for PT60 and IDD measurement Note: For some particular labs, special connections are required. For more information on these connections, consult the TWR-S08PT60 labs tutorial.
-
Page 12: Warranty
Quick Start Guide Visit freescale.com/TWRS08PT60 for information on the TWR-S08PT60, including: • TWR-S08PT60 quick start guide • TWR-S08PT60 labs tutorial • TWR-S08PT60 user guide Support Visit freescale.com/support for a list of phone numbers within your region. Warranty One (1) year limited warranty. Please visit us at freescale.com/warranty for complete warranty information. For more information, visit freescale.com/Tower Join the online Tower community at towergeeks.org...
