- Page 1 Quick Start Guide TWR-K60D100M Development Board 100 MHz Arm Cortex -M4 MCU, 512 KB Flash, ® ® 128 KB SRAM, Ethernet, USB Full-Speed, Cryptographic Acceleration TOWER SYSTEM MODULE FOR K10D, K20D, K30D AND K60D KINETIS SUB-FAMILY MCUs...
- Page 2 GET TO KNOW THE TWR-K60D100M BOARD Primary Connector General Purpose Tower Plug-In (TWRPI) MMA8451Q Socket Accelerometer Touch TWRPI Socket Infra-Red LED/Touch SW3 (Reset) Buttons D7, D8, D9, and D11 Power/OSJTAG Mini-B USB Connector MK60DN512VMD10 Secondary Kinetis MCU Connector Figure 1: Front side of TWR-K60D100M module...
- Page 3 Figure 2: Back side of TWR-K60D100M module TWR-K60D100M NXP TOWER SYSTEM BOARD The TWR-K60D100M module is part of the NXP Tower System, a modular development platform that enables rapid prototyping and tool re-use through reconfigurable hardware. The TWR-K60D100M can be used with a broad...
- Page 4 Quick Start Guide TWR-K60D100M FEATURES • MK60DN512VMD10 MCU (100 MHz Arm Cortex -M4 core, 512 KB flash, Ethernet, ® ® USB FS OTG, encryption, 144 MAPBGA) • Integrated open source JTAG (OSJTAG) circuit • MMA8451Q 3-axis accelerometer • Four user-controlled status LEDs •...
- Page 5 SOFTWARE INSTALLATION INSTRUCTIONS In this Quick Start Guide, you will learn how to set up the TWR-K60D100M board and run the included demonstrated software. For more detailed information, review the user manual at www.nxp.com/TWR-K60D100M. Configure the Download Hardware Software...
- Page 6 Kinetis MCUs, available for • Bootloader for Kinetis MCUs at download at the relevant links listed www.nxp.com/kboot here. TWR-K60D100M JUMPER OPTIONS The following is a list of all jumper options. The default installed jumper settings are shown in the shaded boxes. JUMPER OPTION...
- Page 7 TWR-K60D100M JUMPER OPTIONS CONT. JUMPER OPTION SETTING DESCRIPTION Connect main EXTAL to on-board 50 MHz oscillator (Y1) Clock Input Connect EXTAL to the CLKIN0 signal on the elevator Source connector Selection Connect ENET_CLKIN to the CLKIN0 signal on the elevator...
- Page 8 Visit www.nxp.com/support for a list of phone numbers within your region. Download installation software and documentation at WARRANTY www.nxp.com/TWR-K60D100M. Visit www.nxp.com/warranty for complete warranty information. www.nxp.com/TWR-K60D100M, www.nxp.com/Tower NXP, the NXP logo, Kinetis, and Tower are trademarks of NXP B.V. All other product or service names are the property of their respective owners.
