Default Ticket Formats - Rice Lake 520 Installation Manual

Command
<SPnn> Space (nn = number of spaces)*
<SU> Toggle weight data format (formatted/unformatted)**
NOTES:
Gross, net, tare and setpoint values are 9 digits in length, including sign (10 digits with decimal point), followed by a space and
a two-digit units identifier. Total field length with units identifier is 12 (or 13) characters.
ID and consecutive number (CN) fields are 1–7 characters in length, as required.
ID numbers included in the print format string (<ID> command) must be set using the UID EDP command or via keypad in
setup mode.
Ticket header (AE) inserts information specified for the HDRFMT header format.
* If nn is not specified, 1 is assumed. Value must be in the range 1–99.
** After receiving an SU command, the indicator sends unformatted data until the next SU command is received. Unformatted
data omits decimal points, leading and trailing characters.
The <G2>, <N2>, and <T2> commands listed in Table 11-1 print the gross, net, and tare weights in
NOTE:
non-displayed units—that is, in the units not currently displayed on the indicator.

11.2 Default Ticket Formats

Table 11-2 shows the default print formats for the 520 and lists the conditions under which each print format is
used. The HDRFMT format is used to specify header information that can be used by the other ticket formats.
The contents of the HDRFMT format can be inserted into any other ticket format using the <AE> formatting
command.
Format
GFMT GROSS<G><NL2><TD><NL>
NFMT GROSS<G><NL>TARE<SP><T><NL>NET<SP2><N>
<NL2><TD><NL>
CFMT GROSS<G><NL>TARE<SP><T><NL>NET<SP2><N><NL>COUNT<
C><NL>APW<SP2><W><NL>
SPFMT <SCV><SP><SPM><NL>
EDPFMT GROSS<G><NL2><TD><NL>
HDRFMT COMPANY NAME<NL>STREET ADDRESS<NL>
CITY, ST ZIP<NL2>
STRMFMT <2><P><W7.><U><M><S><CR><LF>
NOTES:
In OIML and CANADA modes, the letters PT (preset tare) are automatically inserted after the printed tare weight.
For most applications, when using a printer attached to the EDP port, set PRNDEST (on the SERIAL menu) to EDP. If
PRNDEST=BOTH, only the EDP format is sent to the printer.
Description
Table 11-1. Print Format Commands (Continued)
Default Format String
Table 11-2. Default Print Formats
Ticket Format
GFMT/NFMT/
EDPFMT/CFMT
√
√
Used When
Normal mode, no tare in system
Normal mode, tare in system
Count mode.
Setpoint push print
(PSHPRNT=ON)
Normal mode, PRNDEST=BOTH
(SERIAL menu). GFMT (or NFMT) print
format is sent to
simultaneously.
N/A
Print format is set to CUSTOM on PRN
or EDP menus.
Print Formatting
SPFMT
√
√
operation
printer port
57
