10.1.2

Reporting Commands

Reporting commands (see Table 10-2) send specific
information to the EDP port. These commands can be
used in both setup mode and normal mode.
Command
DUMPALL List all parameter values
SPDUMP Print setpoint configuration
VERSION
Write 520 software version
P Write current displayed weight with units
identifier. See Section 13.4 on page 66 for
more information.
S Write one frame of stream format
Table 10-2. EDP Reporting Commands
10.1.4

Parameter Setting Commands

Parameter setting commands allow you to display or
change the current value for a particular configuration
parameter (Tables 10-3 through 10-12).
Current configuration parameter settings can be
displayed in either setup mode or normal mode using
the following syntax:
command<ENTER>
Most parameter values can be changed in setup mode
only; setpoint parameters listed in Table 12-2 on
page 61 can be changed when in normal weighing
mode.
Use the following command syntax when changing
parameter values:
command=value<ENTER>
Command
GRADS Graduations
ZTRKBND Zero track band
ZRANGE Zero range
MOTBAND Motion band
OVRLOAD Overload
SMPRAT Sample rate
DIGFLTR1 Digital filtering
DIGFLTR2
RATLTRAP Rattletrap filtering
DFSENS Digital filter cutout sensitivity
DFTHRH Digital filter cutout threshold
PWRUPMD Power up mode
TAREFN Tare function
Function
Description
1–9999999
OFF, 0.5D, 1D, 3D
1.9%, 100%
1D, 2D, 3D, 5D, 10D, 20D, OFF
FS+2%, FS+1D, FS+9D, FS
60HZ, 120HZ, 30HZ, 7.5HZ, 15HZ
1, 2, 4, 8, 16, 32, 64, 128, 256
OFF, ON
2OUT, 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
NONE, 2DD, 5DD, 10DD, 20DD, 50DD, 100DD, 200DD, 250DD
GO, DELAY
BOTH, NOTARE, PBTARE, KEYED
Table 10-3. CONFIG EDP Commands
10.1.3

The RESETCONFIGURATION Command

The RESETCONFIGURATION command can be
used in setup mode to restore all configuration
parameters to their default values.
This command is equivalent to using the DEFAULT
function in TEST mode. See Section 13.13 on page 79
for more information about test mode.
All load cell calibration settings are lost when
NOTE:
the RESETCONFIGURATION command is run.
where is either a number or a parameter value.
value
Use no spaces before or after the equal (=) sign. If you
type an incorrect command, the display reads
For example, to set the motion band parameter to 5,
type the following:
MOTBAND=5D<ENTER>
For parameters with selectable values, enter the
command and equal sign followed by a question
mark:
command=?<ENTER>
to see a list of those values. The indicator must be in
setup mode to use this function.
Values
.
??
EDP Commands 47
