QSE-CI-NWK-E Control Interface
The QSE-CI-NWK-E is a versatile integration access
point for Lutron's QS-based systems. Through either
RS232 or TCP/IP over Ethernet, third-party devices
can control and/or monitor a QS system.
Key Features
• Easily integrate with touchscreens, PCs, A/V systems,
or other digital systems and devices.
• Control and monitor GRAFIK Eye
Energi Savr Node , and other products on the wired
TM
QS link.
• Monitor lighting scenes, levels, and shade positions
• Up to ten (10) QSE-CI-NWK-E control interfaces are
allowed per QS link.
• The QSE-CI-NWK-E is Quantum
the Quantum System Specification Sheet for
®
compatibility details.
Compatible Components
The following devices are compatible with the QS link.
For more information on each, refer to
www.lutron.com/qs.
• GRAFIK Eye QS control units.
®
• seeTouch QS wallstations.
®
• Sivoia QS shades.
®
• QS Interfaces (contact closure, Ethernet/RS232).
• Quantum system.
®
• Energi Savr Node units.
TM
• QS Sensor Module.
• QS Keyswitch.
Requirements
• QS Link Power Supply, such as a:
- GRAFIK Eye QS.
®
- QS Link power supply, such as the QSPS-P1-1-50 .
- Energi Savr Node
TM
• QS Communication Link (IEC PELV/NEC
(see QS Link Wire Sizes table).
Protocol
• Protocol document P/N 040-249 included on a
CD accompanying the packaged QSE-CI-NWK-E.
• Also available for download at www.lutron.com/qs.
S p e c i f i c at i o n S u b m i t ta l
R
Job Name:
Job Number:
QS, Sivoia
®
compatible. Refer to
®
QS.
Class 2)
®
Model Numbers:
QSE-CI-NWK-E
QS,
®
Control Interface
