Installation
Specifications
Hydrim L110w instrument washer:
Dimensions:
Height (free-standing)
Height (built-in)
Width
Depth
Depth with Door Open
Weight
Running Noise
Hot Water Connection
Rinse aid dispenser
Water softener
Filling system
Wash Temperature
Rinse and hold
Electrical Consumption:
North America
Rated Load
Other:
Equipment Pollution Degree
Equipment Installation Category
Maximum relative humidity
Mains supply
Operating mode
HYDRIM L110w Installation Guide
850 mm / 33.5"
810 mm / 32"
600 mm / 23.75"
600 mm / 23.75"
1143 mm / 45"
85 kg / 187 lbs
58 dB wash
78 dB dry
60˚C max / 158˚F
80 ml / 2.7 U.S. fl. oz. capacity
1.0 kg / 2.2 lbs salt capacity
4.5 L / 135 U.S. fl. oz. capacity
50˚C / 122˚F
30˚C / 86˚F
208 - 240 V 60 Hz 15 A
2.5 kW
2
II
80 % for temp. up to 31˚C / 88˚F
50 % for temp. up to 40˚C / 104˚F
+ / - 10 % of nominal
Free-standing or Built in
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SciCan Hydrim L110w
Summary of Contents for SciCan Hydrim L110w
- Page 1 Installation Specifications Hydrim L110w instrument washer: Dimensions: Height (free-standing) 850 mm / 33.5" Height (built-in) 810 mm / 32" Width 600 mm / 23.75" Depth 600 mm / 23.75" Depth with Door Open 1143 mm / 45" Weight 85 kg / 187 lbs...
- Page 2 The unit must be connected to the water supply in accordance with local and national plumbing codes. SciCan recommends a hard plumbing installation within 1.5 m / 5 ft. of the unit. If additional distance is necessary, commercial grade plumbing hose, similar to washing machine installation, must be used to minimize possible leaks.
- Page 3 Make sure that the voltage and frequency of the power outlet are the same as indicated on the label of the unit. Make sure that Hydrim cleaning solution is used with Hydrim L110w in North America. The Hydrim L110wd uses Neodisher dental detergent. For both models, see operator’s manual for more information on water softening and rinse aid.
- Page 4 1 . 2 5 6 0 0 5 " + 2 3 . 7 6 0 0 m m + 5 0 m m / 2 3 . 7 5 " + 2 " HYDRIM L110w Installation Guide Page 4...
