General Product Information; Introduction; Intended Use; Symbols - BRONKHORST MASS-VIEW series Instruction Manual

1

General Product Information

1.1

Introduction

®
MASS-VIEW
gases. These smart instruments offer multiple process values as input- or output parameters. Many
parameters can be changed on the instrument through the menu, other parameters can only be
changed using our digital interfaces.
This manual covers the general part of the MASS-VIEW
covers the general instructions needed for the instruments.
1.2

Intended Use

The intended use of
specified gas types as stored in the instrument. The gas has to be clean and dry.
1.3

Symbols

Important information. Discarding this information could cause injuries to people or damage to the
instrument or installation.
Helpful information. This information will facilitate the use of this instrument.
Additional info available on the internet or from your local sales representative.
1.4

Product Support References

®
MASS-VIEW
- Instruction manual MASS-VIEW
- Short form instruction manual MASS-VIEW
- Operation instructions digital instruments
Fieldbus/interface description:
RS232 Interface with FLOW-BUS protocol
Modbus interface
- FlowPlot Manual
- Hook-up diagram
- Dimensional drawing
These documents can be downloaded from our website: www.massflow-online.com
