PRESSURE WASHER HYDRAULIC DIAGRAM (OPTION)

CLOSED CENTER SYSTEM HOOKUP
HYDRAULIC
TANK
E
D
C
G
PAGE 65 — WRS5200DFPU HYDRAULIC ROLLER SCREED • OPERATION MANUAL — REV. #2 (03/08/18)
G
F
1800 Series Pressure Washer and Gun Assembly
C
WATER
SUPPLY
A
F
A
B
C
D
E
B
F
F
G
A
5000 PSI
E
D
Table 10. Pressure Washer Specifications
Pressure Gauge
Motor inlet and Outlet
Water Inlet
Water Outlet
Pressure Washer
Hose
Hydraulic Motor
Displacement
Hydraulic Motor Flow
Unloader Valve
5000 psi (35,000 kPa)
1/2" NPT (F)
3/4" Garden Hose
3/8" Quick Disconnect
3/8" I.D., 50' Length
3000 psi (21,000 kPa)
Rating
0.5 cu. in. (8.19 cm )
3
8 gpm/30 lpm @ 1800 psi
For Service Only
