B
PAGE 19 — WRS5200DFPU HYDRAULIC ROLLER SCREED • OPERATION MANUAL — REV. #2 (03/08/18)
C
A
Figure 6. Power Unit Dimensions (WRSPDU)
Table 3. Power Unit Dimensions
Reference
Letter
A
B
C
D
E
F
DIMENSIONS (POWER UNIT)
E
F
Dimension in. (mm.)
30.25 (768.35)
28.25 (717.55)
42 (1066.8)
31.13 (790.7)
61.5 (1562.1)
52.5 (1333.5)
D
