General Information - MULTIQUIP WRS5200 Operation Manual

This equipment was designed with user safety in mind;
however it can present hazards if improperly operated or
misused.
The application of this roller screed is to strike off the
surface of the concrete at a predetermined grade.
This equipment is to be used only for its intended
application and for no other purpose. Any misuse of
this equipment will void any and all warranties.
Misuse is defined as the following but not limited to:
„ Modifications or repairs made to the equipment without
written approval from Multiquip.
„ Improper storage
„ Poor maintenance
„ Dirty machine
„ Improper lifting that may cause frame to bend
„ Screeding surfaces other than concrete
„ Scarring of strike tube surface
„ Removal of guards
„ Operating with defective on worn parts
„ Inadequate forms (cannot support weight of screed)
PAGE 22 — WRS5200DFPU HYDRAULIC ROLLER SCREED • OPERATION MANUAL — REV. #2 (03/08/18)
Gradability (Slopes)
This roller screed shall not be used on grades (up or down)
that exceed 7% (4°). Reference Figure 9.
Figure 7. Grade Percentages

GENERAL INFORMATION

CAUTION
Operating the screed on slopes greater than 7% (4°)
may cause the operator to loose control. This condition
may cause severe damage to the equipment and bodily
harm to the operator.
