The following instructions are intended as a basic guide
for machine start-up and operation. Following these
instructions will help preserve and maintain the life of this
equipment.
BEFORE STARTING
Fuel Check (Gasoline)
DO NOT smoke while refueling, gasoline/propane fuel is
highly flammable and can be dangerous if mishandled.
DANGER
Fuel spillage on a hot engine can cause
a fire or explosion. If fuel spillage occurs,
wipe up the spilled fuel completely to
prevent fire hazards. NEVER smoke
around or near the generator.
1. To check the engine fuel level, place the power unit on
a secure flat surface with the engine stopped.
2. Read the gasoline fuel gauge (Figure 32) located on
top of the fuel tank cap.
Figure 32. Gasoline Tank Fuel Gauge
3. If fuel level is low, remove fuel filler cap (Figure 33)
and fill with gasoline fuel. Wipe up any spilled fuel
immediately.
PAGE 47 — WRS5200DFPU HYDRAULIC ROLLER SCREED • OPERATION MANUAL — REV. #2 (03/08/18)
Figure 33. Adding Fuel
4. After replenishing fuel, make sure cap is securely
tighten to fuel tank.
Fuel Check (LPG\Propane)
1. Read the propane fuel gauge (Figure 34) located on
top of propane tank.
E
Figure 34. Propane Tank Fuel Gauge
2. If the propane fuel level is low, there are two methods
for refueling. Method 1 will allow refueling of the
propane tank in place (attached to power unit). Method
2 will required removal of the empty propane tank from
the power unit.

INSPECTION
