INSTRUCTION MANUAL
DOMI, CLAS, DREX, S, BPU, CLASVORT, VX, VORTIX, CANAL, STONE, TRITUR, D4, D6
1. RECEIPT
When you receive the equipment, check that the packaging
is in good conditions. If not, indicate this in writing on the
carrier's delivery note. Unpack the equipment and verify its
state. If there is damage, inform the dealer immediately.
2. SAFETY INSTRUCTIONS
In this manual, the important safety instructions are
specifically marked. These marks have the following
symbols:
Safety instructions whose lack of fulfilment could affect
the safety of people and installations.
Safety instructions
(hydrocution, ...)
Safety instructions whose lack of fulfilment could
WARNING
affect the equipment and its operation.
All the equipment supplied by BOMBAS ITUR are
properly protected to prevent possible accidents, but in
any case all the safety recommendations indicated on
the pump, on all the documents supplied with it or in
applicable regulations, must be followed.
Failure to comply with these instructions exempts BOMBAS
ITUR S.A. from any responsibility.
The safety recommendations indicated are based on our
experience and on normal use of the equipment.
The installer/user is exclusively responsible for assessing
the individual risks that exist in each installation and for not
permitting its connection and start up without the
appropriate protections.
3. GENERAL COMMENTS
The user must not carry out operations that are not
permitted in this manual. Any operation or handling
must always be carried out with the appropriate means,
by duly qualified personnel and after having read and
understood this manual.
Any installation, maintenance, repair or transport
operations must be carried out with the pump stopped
and safely disconnected.
The correct state of both the electrical system and
pipes must be verified on a regular basis. If their state
is not safe, the pump must be stopped and repaired.
This is especially important if the defects are located in
electrical devices or cables.
When starting the equipment up, by activating the
switch or connecting it to a socket, make sure that this
SUBMERSIBLE PUMPS
to prevent electrical risks
is done on a dry floor, and never with wet hands and/or
without proper footwear.
Before starting the pump up, all its elements, especially
those that affect safety, must be correctly installed and
fastened. Never start the pump up when there are
people close to it.
Never use the power cable or the discharge tube as a
means of elevating or supporting the pump. A metal
cable or chain must be fitted, suitable for the weight,
attached to the handle or hooks prepared for this.
4. LOCATION
Access to the pump or installation must be sufficiently
restricted, so that nobody can inadvertently access it.
Safety elements must be placed that prevent the entry
of children or other risk people. Never remain in the
area where the pump is placed whilst it is in operation.
The pump, except those specifically designed for this,
must NOT be installed in places classified as having an
explosion risk.
if the pump is outdoors and there is a risk of frost,
WARNING
it must be completely submerged and operating.
Never let the ice affect it, or let ice form on the inside.
If the pump is not going to be used for a long period of
time, it must be cleaned and stored in a dry and
ventilated place.
If the pump is in a well or pit, before carrying out any
operation, verify that
suffocating or explosive gases. If you are going to use
a blower or fan to evacuate the gases, verify that this
does not represent a risk of explosion. Whilst the pit is
open, place protections to prevent accidental falls.
WARNING If the bottom of the area where the pump is going
to be place is sandy or muddy, the pump must be
suspended using adequate means, or placed on a
sufficient base, to prevent it from sinking.
If the pumps are going to be used in swimming pools,
gardens or similar places, European Regulation 60335,
Section 2, protection class 1, must be complied with.
Check with a specialist.
5. LIQUID PUMPED
The pumps must never work dry.
WARNING
The pumps referred to in this manual, have been
designed for use under the conditions indicated in the
catalogue, pump and applicable documents.
In any case, and as a general rule, the liquid pumped must
NOT be:
MIF-6100/02-I
01-09-05
there are no poisonous,
