QUICK-START GUIDE
PRO-TILL 20/26/28
for
* Refer to operators manual for complete safety and operation info.
A
Connect Hydraulics
PITCH
ADJUSTMENT
Maintenance
(Check Machine Daily)
• Hydraulic Connections & Hoses
• Working points & pins
• Hubs & Spindles
• Tire Pressure: 58 PSI (400 kPa)
• Check for missing, worn or
damaged parts.
* Refer to operators manual for
complete safety and operation info.
*
REMEMBER! You must complete Product
Registration to be eligible for Warranty.
DEPTH
1
WINGS
2
TRANSPORT
3
JACK
4
2
1
1
3
4
WARRANTY
FLOAT
2
1
2
1
1
3
FLOAT
4
3
PITCH
ADJUSTMENT
143366 v1.4
Advertisement
Related Manuals for Degelman PRO-TILL 26
Summary of Contents for Degelman PRO-TILL 26
- Page 1 QUICK-START GUIDE WARRANTY PRO-TILL 20/26/28 REMEMBER! You must complete Product * Refer to operators manual for complete safety and operation info. Registration to be eligible for Warranty. Connect Hydraulics FLOAT DEPTH FLOAT WINGS TRANSPORT JACK PITCH PITCH ADJUSTMENT ADJUSTMENT Maintenance (Check Machine Daily) •...
- Page 2 Put in Field Position 1” iii) Depth Adjustment Set Cutting Depth Pitch Adjustment (2 Inner Wheel Cylinders) (2 Outer Cylinder Adjustment Rods) (Start with 8 stops (Tool Storage Location) per cylinder, test depth & adjust) (IMPORTANT: Add depth Typically stops starting from depth plate end ) Set to 2”...
