> WEEKLY MAINTENANCE PROCEDURES
To achieve a good weekly maintenance you will have to do the following actions:
7
days
+ Suction Cap Cleaning
+ Wiper Cleaning
> Always use this menu to perform cleanings or replace parts :
Menu
>
Maintenance
Suction Cap & Exhaust Cleaning
>
The black silicon lips of the two cappings should be cleaned with the Cleaning Stick R
dipped in Cleaning Solution.
It is necessary to remove the built-up of the remaining ink staying on the edges of the
cappings. It will prevent air leakage and keep the good suction of the pumps!
Be careful not to touch the foam! Keep it flat!
The four extrusion lances (see in the blue circle...) and the hole
sitting on the side of the capping at the Exhaust position need
also to be cleaned and free of dried ink.
Always clean first the hole at the front and go backward while
cleaning the lances !
Suction Cap Cleaning
W E E K L Y
>
Maintenance Part Clean/Replace
Exhaust Cleaning
WEEKLY MAINTENANCE
M A I N T E N A N C E
+ Exhaust Cleaning
+ Nozzle Guards Cleaning
>
and follow instructions on the display
MENU
OK
TO BE DONE EVERY WEEK
!
Direction to clean
7
