KStar UDC9101RTS Operation Manual

Memopower rt series

Advertisement

Uninterruptible Power Systems
1/2/3KVA
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UDC9101RTS and is the answer not in the manual?

Questions and answers

Summary of Contents for KStar UDC9101RTS

  • Page 1 Uninterruptible Power Systems 1/2/3KVA Operation Manual...
  • Page 2 All rights reserved. The information in this document is subject to change without notice. Publish statement Thank you for purchasing this series UPS. This series UPS is an intelligent, single phase in single phase out, high frequency online UPS designed by our R&D team who is with years of designing experiences on UPS. With excellent electrical performance, perfect intelligent monitoring and network functions, smart appearance, complying with EMC and safety standards, The UPS meets the world’s advanced level.
  • Page 3: Table Of Contents

    Table of Contents 1.  Important Safety Warning ........................2  1-1  Transportation ..........................2  1-2  Preparation ............................ 2  1-3  Installation ............................. 2  1-4  Operation ............................3  1-5  Maintenance, service and faults ....................3  1-6  Symbols used in this guide ...................... 3  2. ...
  • Page 4: Important Safety Warning

    1. Important Safety Warning Important safety instructions – Save these instructions Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully There exists dangerous voltage and high temperature inside the UPS.
  • Page 5: Operation

    1-4 Operation  Do not disconnect the mains cable on the UPS system or the building wiring outlet (shockproof socket outlet) during operations since this would cancel the protective earthing of the UPS system and of all connected loads.  The UPS system features its own, internal current source (batteries). The UPS output sockets or output terminals block may be electrically live even if the UPS system is not connected to the building wiring outlet.
  • Page 6: Installation And Setup

    2. Installation and setup NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. 2-1 Unpack checking  Don’t lean the UPS when moving it out from the packaging ...
  • Page 7 2KVA(H)/3KVA(H) 2KVA(S)-6batt /3KVA(S): 1. AC input 2. Network /Fax/Modem Surge Protection(option) 3. Input circuit breaker 4. EPO(option) 5. USB communication port(option) 6. RS-232 communication port 7. SNMP intelligent slot (option) 8. Output receptacles 9. Battery Terminal 10. Output Terminal...
  • Page 8: Lcd Control Panel

    2-3 LCD control panel LCD control panel introduction (1)LED(from top to bottom: “alarm”, “bypass”, “battery”, “inverter”) (2)LCD display(3) Selectbutton:enter to next item(4)Off button (5)On button 2-4 Setup the UPS Step 1: UPS input connection Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords.
  • Page 9: Operations

    Step 4: Turn on the UPS Press the ON button on the front panel for two seconds to power on the UPS. Note: The battery charges fully during the first five hours of normal operation. Do not expect full battery run capability during this initial charge period. Step 5: Install software For optimal computer system protection, install UPS monitoring software to fully configure UPS shutdown.
  • Page 10: Lcd Display

     Switch LCD message: Press this button to change the LCD message for input voltage, input frequency, battery voltage, output voltage and output frequency etc.  Mute the alarm: When the UPS is on battery mode, FUNC/Mute press and hold this button for at least 2 seconds to Button disable or enable the alarm system.
  • Page 11 Output voltage Load Temperature (EnvironmentTemperatu Firmware Version & UPS model.
  • Page 12 CODE (Operational status and mode) Alarm Code(Warming Message) All alarm codes are present when abnormal behavior(s) occur(s) The charging status can also be shown on the screen as below while the charger is on. Cc MODE Cv MODE...
  • Page 13: Ups Setting

    3-3 UPS setting The setting fuction is controled by 3 buttons (Func,Off/up ▲, On/down▼): Func +Off/up ▲---goes into the setting page, Func --- value adjustment; Off ▲ & On ▼---for choosing different pages. After the UPS turn ON, press buttons Func & ▲ for 5seconds and then goes into the setting interface page.
  • Page 14 Battery capacity setting Press Func button to change the setting (Battery capacity range is 1-200Ah). Press UP button ▲ to select the previous setting. Press DOWN ▼ button to select the next setting. EOD voltage setting Press Func button to change the setting(160/167/175/180.) default setting:...
  • Page 15: Operating Mode Description

    Mute setting Press Func button to change thesetting(ON or OFF). Press UP button ▲ to select the previous setting. Press DOWN ▼ button to save and exit the setup. BYPASS enable / disable setting Press Func button to change thesetting(ON or OFF). Press UP button ▲...
  • Page 16: Operational Status And Mode(S)

    3-5 Operational Status and Mode(s) item Content Displayed Standby Mode No Output Bypass Mode Utility Mode Battery Mode Battery Self-diagnostics Inverter is starting up ECO Mode EPO Mode Maintenance Bypass Mode Fault Mode 3-6 Alarm or Fault reference code Event log UPS Alarm Warning Buzzer Inverter...
  • Page 17: Troubleshooting

    4. Troubleshooting If the UPS system does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Remedy Check if input power cord The AC input power is not firmly connected to the connected well. No indication and alarm even mains.
  • Page 18: Options

    Storage Before storing, charge the UPS 5 hours. Store the UPS covered and upright in a cool, dry location. During storage, recharge the battery in accordance with the following table: Storage Temperature Recharge Frequency Charging Duration -25°C - 40°C Every 3 months 1-2 hours 40°C - 45°C Every 2 months...
  • Page 19 Pins definition of connecting terminal on the board Relaycard electrical parameter Type (Max Switched Voltage) AC:120V AC:120V DC:5~12V DC:24V Relaycardcontact (Max Switched Current) AC:1A AC:1A DC:1A DC:1A...
  • Page 20: Specification

    7. Specification MODEL 1KVA(S) 1KVA(H) 2KVA(S) 2KVA(H) 3KVA(S) 3KVA(H) PHASE Single phase with ground Capacity (VA/Watts) 1000VA / 900W 2000VA / 1800W 3000VA / 2700W INPUT Nominal voltage 200/208/220/230/240VAC 160Vac±5% @100%-80% load; 140Vac±5% @80%-70% load; Low line 120Vac±5% @70%-60% load; transfer 110Vac±5% @60%-0% load;...
  • Page 21 Numbers Backup time Long run unit depends on the capacity of external batteries Typical recharge 4 hours recover to 90% capacity (Typical) time(standard modle) 109. 27.4 41.0 27.4 41.0 54.7 82.1 54.7 82.1 82.1 109.4 82.1 Charging voltage ±1% ±1% ±1% ±1% ±1%...
