Operating Manual
No. 596-1 GB
Big Baler
Big Pack 88 / MultiCut
Big Pack 127 / MultiCut
Big Pack 127 / MultiCut
(from machine no. 490 000)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Big Pack 88 / MultiCut and is the answer not in the manual?

Questions and answers

ANDREW CHARLES SUMNALL
June 21, 2025

is there a shear bolt for rake drum

0

Subscribe to Our Youtube Channel

Related Manuals for Krone Big Pack 88 / MultiCut

Summary of Contents for Krone Big Pack 88 / MultiCut

  • Page 1 Operating Manual No. 596-1 GB Big Baler Big Pack 88 / MultiCut Big Pack 127 / MultiCut Big Pack 127 / MultiCut (from machine no. 490 000)
  • Page 2 Krone-Big Baler Models: Big Pack 88 / MultiCut; Big Pack 127 / MultiCut Big Pack 128 / MultiCut to which this declaration relates corresponds to the relevant basic safety and health requirements of the Directive 89/392 (EEC) and to the requirements of the other relevant Directives: Spelle, 01.11.2001...

  • Page 3: Table Of Contents

    List of contents List of Contents General Designated Purpose ......................I - 1 Technical Data ........................I - 1 Saftey Identifying Safety Instructions in the Operating Manual ............ II - 1 Safety Instructions and Accident Prevention Regulations ..........II - 1 Introduction ........................
  • Page 4 List of contents 6.10 Basic adjustment of the flywheel brake ................VI - 9 6.11 Installing the flywheel brake.................... VI - 10 Care and Maintenance Special Notes on Safety ....................VII - 1 General ........................... VII - 1 Cleaning ......................... VII - 2 Tyres ..........................

  • Page 5: Designated Purpose

    1.1 Designated Purpose The big square balers Big Pack 88 / MultiCut, Big Pack 127 / MultiCut and Big Pack 128 / MultiCut are pick-up balers mit dem "Variablen Füll-System". They produce highly compressed and consistent big square bales with a length from 1.0 to 2.5 m and 1.2 or 0.8 m width.
  • Page 6 General Information 1.2.6 Designated Use The Big Baler Big Pack 88 / MultiCut; Big Pack 127 / MultiCut and Big Pack 128 / MultiCut is designed for standard agricultural use only (intended use). Any use of the machine for other purposes is deemed not to be in accordance with intended use.
  • Page 7 General Information 1.2.8 Technical Data Big Pack 88 / MultiCut; Big Pack 127 / MultiCut; Big Pack 128 / MultiCut I - 3...
  • Page 8 General Information PTO Shaft Speed 1000 rpm PTO Shaft Tractor-wide angle with free wheel Machine-free wheel slip clutch Hitching Trailer coupling; Swinging drawbar (permitted load min. 1200 kg; MultiCut = 1500 kg) (height of swinging drawbar variable) Caution! When making an adjustment the hexagonal screws must be tightened up to: see page 59 for torque moments Support...
  • Page 9 General Information Hydraulic Connections on the Tractor Pick up lifting (yellow protective caps Single action control valve Residual pack ejection Double action control valve Blade controle MultiCut (blue protective caps) Single action control valve Swath Distributor (yellow protective caps) Double action control valve Electrical Connections on the Tractor Baler lighting 7-pole socket...
  • Page 10 General Information I - 6...

  • Page 11: Identifying Safety Instructions In The Operating Manual

    Safety Safety 2.2 Safety Instructions and Accident Prevention 2.1 Identifying Safety Instructions Regulations in the Operating Manual 2.2.1 Personnel Qualification and The safety instructions contained in this manual, which could result in personal injury if not followed, are Training identified by the general danger sign: The big baler must only be used, maintained and repaired by personnel who are acquainted with the machine and have been informed of the dangers...
  • Page 12 Safety Observe the applicable traffic laws when using public unintentionally triggered at any transport or roads (for example, in Germany, the Road Traffic Type working positions. Approval Law and Road Traffic Law). 16. Ensure that implements are in the prescribed 2.2.4 Safety Instructions and Accident condition for on-road travel and lock them in place according to the manufacturer's instructions!
  • Page 13 Safety 12. Always switch off PTO shaft when the angle is 2.2.5 Trailer Implements too large or the PTO shaft is not required! 1. Secure implements against rolling. 13. Caution! The flywheel will continue to rotate for 2. Observe the maximum supported load on the some time even after the PTO shaft has been trailer coupling, swing drawbar or hitch! disengaged! Keep clear of the implement during...
  • Page 14 2.2.8 Tyres technical requirements set by the manufacturer of the implements! 1. When working on the tyres, make sure that the This is guaranteed when using genuine KRONE implement has been safely lowered and secured replacement parts! against rolling (wheel chocks).
  • Page 15 Safety II - 5...

  • Page 16: Introduction

    Safety 2.3 Introduction The KRONE big baler is equipped with all required safety devices (protective equipment). Not all potentially dangerous positions on this implement can be fully secured, as this would be incompatible with full functional capability. Corresponding danger notices attached to the machine warn against any dangers.
  • Page 17 Safety 939 101-4 1000/ MAX. MAX. Before putting the machine The PTO shaft speed may not exceed 1000 rpm! into operation read and The hydraulics system operating pressure may observe the operating not exceed 200 bar! instructions. Order No.: 939 101-4 (1x) Order No.: 939 471-1 (1x) Never reach into the pick up Danger from rotating...
  • Page 18 Safety 2.4 Overview of the Big Pack Baler with Tandem Axle (Left Side) 1. Mechanical Flywheel Holding Brake 8. Jack Stand 2. Bracket for Quick-Release Coupling and Plug 9. Adjustable Swinging Drawbar 3. Longitudinal Adjustment of Packs 10. Wide Angle PTO Shaft with Overload Protection 4.

  • Page 19: Overview Of Big Pack Baler With Tandem Axle (Right Side)

    Safety 2.5 Overview of Big Pack Baler with Tandem Axle (Right Side) 1. Electronic Control Valves with Pressure Gauges 7. PTO Shaft for MultiCut 2. Knotter Shaft 8. Shut-Off Tap for Pick Up Hydraulics 3. Hydraulic Oil Reservoir Tank 9. Slewable Mudguard 4.

  • Page 20: The Big Pack Baler Working Method

    Safety The BIG PACK Baler Working Method Multi Cut - VFS Fördersystem 14 15 BP-VFS-004 II - 10...
  • Page 21 Safety Special Equipment The BIG PACK Baler must be driven by a tractor with at least a 65 kW (85 bhp) power output. Swath distributor: The BIG PACK Baler is hitched to the trailer coupling or A swath distributor is available as an extra to ensure an the swinging drawbar.
  • Page 22 Safety II - 12...

  • Page 23: Preparing The Big Pack Baler

    Preparing the Big Pack Baler 3. Preparing the Big Pack Baler 3.1 Special Notes on Safety • Particular care is required when attaching the big pack baler to or detaching it from the tractor. There must be nobody between the tractor and the big pack baler. After coupling, switch off the engine and remove the ignition key.
  • Page 24 Preparing the Big Pack Baler Removal of the flywheel brake For any adaptation of the drawbar height, the flywheel brake must be removed from the drawbar. For this proceed as follows: 1. With the flywheel brake pulled, withdraw pin (1) from the brake lever and remove the brake lever.

  • Page 25: Adapting The Main Pto Shaft

    Preparing the Big Pack Baler Installation of the flywheel brake Place the brake housing onto the drawbar and tighten the securing bolts. Check that the brake disc runs freely through the brake saddle. For any correction of the brake adjustment see section 6.13 “Basic adjustment of the flywheel brake”.

  • Page 26: Putting The Big Pack Baler Into Operation

    Preparing the Big Pack Baler 3.4 Putting the Big Pack Baler into Operation 3.4.1 General Main Drive A straight bevel gear pair provides the main drive. The necessary torque is transmitted by the PTO shaft and a large flywheel mass. The maximum PTO shaft speed of 1000 rpm may not be exceeded.
  • Page 27 Preparing the Big Pack Baler Pick Up Drive The drive for the pick up is located on the right hand side of the machine. The torque is transmitted by a bevel gear arrangement (1) downwards through a PTO shaft (2) with an overload protection mechanism (over- run clutch) to an angular gear (3).
  • Page 28 Preparing the Big Pack Baler Jack Stands As soon as the big pack baler is hitched up, take the load off the support foot (3) by turning the crank (1). Pull out the retaining bolt (5) on the lower part of the jack stand (2), slide in the jack stand and secure in position (4) with the bolt.
  • Page 29 Preparing the Big Pack Baler Hydraulic Connections The big pack baler requires one double and two single action hydraulic control valves on the tractor. The pro- tective caps on the hydraulic (1) hoses in the chute (2) are colour-coded. This means perfect identification of the necessary control valves is guaranteed: yellow = single-action control valve (pick up) blue...
  • Page 30 Preparing the Big Pack Baler PTO Shaft Before sliding the PTO shaft on to the tractor PTO shaft, always secure with the mechanical or hydraulic holding brake. To fix the flywheel turn the brake lever (1) on the left hand side of the swinging drawbar from position (b) to position (a).
  • Page 31 Preparing the Big Pack Baler Electrical Connection Cables The big pack baler requires an electrical supply for the on-board computer. A socket to be mounted on the tractor is part of the scope of supply. Plug the connect- ion cables into the corresponding sockets on the baler and secure them from coming loose.
  • Page 32 Preparing the Big Pack Baler 3.4.4 Road Journeys • Driving on public highways is only permitted with the bale channel empty and the pack chute folded in. • The maximum speed is 40 km/h. • Carrying passengers on the big pack baler is not permitted. •...
  • Page 33 Preparing the Big Pack Baler Lights Connect the lighting unit to the tractor electrical system. Check and clean the tail lights (2) and the rear reflector (1). The same applies for the yellow reflectors on the sides of the big baler and the front white clearance lamps.
  • Page 34 Preparing the Big Pack Baler The wheel chocks (1) are located on the rear left and right hand sides beside the bale channel. Place the wheel chocks in front of and behind the wheels. The machine is thereby secured from rolling away. BP380-7-028 Jack Stand and PTO Shaft for Top Attachment Gently wind down the raised jack stand (4) using crank...
  • Page 35 Preparing the Big Pack Baler Compressed Air and Hydraulic Hoses Fit the compressed air hoses (1) and (2) in the corres- ponding brackets on the top side of the swinging draw- bar. Lay the hydraulic hoses (3) in the bracket (4). BP380-7-030 Bei hydraulischer Bremse Den Schlauch für hydraulische Bremse auf den...
  • Page 36 Preparing the Big Pack Baler 3.4.7 Fire Extinguisher There is a fire extinguisher (1) mounted on the left hand side of the machine beside the bale channel. Please have the fire extinguisher registered. This is the only way of guaranteeing that the necessary inspections are carried out.

  • Page 37: Comfort Controls

    Comfort Controls 4. Comfort Controls 4.1 Special Notes on Safety • Switch off the engine when carrying out assembly work on the tractor or the big pack baler. Remove the ignition key. Apply the flywheel brake. • Secure the tractor and the big pack baler from rolling away. •...
  • Page 38 Comfort Controls 4.3 Mounting Attach the control box on the tractor in a place where it is clearly visible to the driver. Connect the comfort controls to the on-board computer: • Plug the control cable (1) into the control box (3) socket (2). •...
  • Page 39 Comfort Controls The Control Box Prog BP-VFS-011 blade check indicator light Reduce density force (–) Programme button free Increase density force (+) Quit button free "+" button “alarm off” button "Open bale chamber" indicator light "-" button "Bale counter" button "Display Information"...
  • Page 40 Comfort Controls 4.5 Ready Status • Switch on control box at the main switch (14). • Actuate ---- K R O N E ----- Komfortelektronik - - T E R M I N A L -- A brief self-test follows if the power supply is properly Version Nr..: x.x -- Prog Quit...
  • Page 41 Comfort Controls 4.6 Basic setting 4.6.1 Adjusting the density force A bar chart display (a) appears just after the control box is switched on showing the set pack density. When the big pack baler is put into operation displays (b) and Prog Quit (c) appear in the display field showing the current den-...
  • Page 42 Comfort Controls Correction measures for deviations 1.) The LED (d) on button (7) comes on. Displays (b) and (c) (current density) are significantly smaller than the nominal density (a). The prescribed nominal density (a) can not be Prog Quit attained at the oil pressure and the previous conditions (baling material parameters and throughput) given by the on-board hydraulics.

  • Page 43: Open Bale Channel

    Comfort Controls With significant deviations between the current density readings (b) and (c) an arrow (d) appears in the left or right-hand are of the display. It shows the driver which side of the swath he should drive along to correct this and fill the bale chamber evenly.

  • Page 44: Bale Counter

    Comfort Controls 4.6.3 Bale Counter The on-board computer on the big pack baler is equipped with an integral bale counter. When button Ballen Stueck: 1723 pressed the following message appears in the display: Ballen G-Stueck:2693 St--- loeschen --Gst Prog Quit Bales pie.:..1723 Bales tot.:..2693 pie.-- clear- --tot.

  • Page 45: Alarm Messages

    Comfort Controls 4.6.5 Alarm Messages Alarm messages appear in the display when irregulari- ties are picked up by the on-board computer. Alarm messages always take preference. They interrupt the current display immediately. - Alarm-Nr.:..0000 Fadenspanner defekt! - Alarm-No.:..0000 Prog Quit Tensioner faulty!!..
  • Page 46 Comfort Controls IV - 10...

  • Page 47: Working With The Big Pack Baler

    Working with the Big Pack Baler 5. Working with the Big Pack Baler 5.1 Special Notes on Safety • The following always applies for all maintenance, repair and adjustment work: switch off the PTO shaft, switch off the engine and remove the ignition key. Apply the flywheel brake. •...
  • Page 48 Working with the Big Pack Baler Adjusting the Low Limiter To prevent the pick up from becoming buried in the ground, when for example driving over deep ruts, it is fitted on each side with a low limiter (1). To adjust, undo the screws (2) and set the low limiter to the desired position in the slot (3).
  • Page 49 Working with the Big Pack Baler 5.2.2 Pack Chute When folded out the pack chute is an extension of the bale channel. The pack chute must be at the same level as the bale channel so that the packs can be deposited properly.

  • Page 50: Adjusting The Length Of The Big Packs

    Working with the Big Pack Baler 5.3 Adjusting the Length of the Big Packs The length of the big packs is adjusted on the left hand side. The length of the big pack can be pre-selected by turning the crank (1). The indicator (2) on the scale (3) provides an aid for the adjustment.
  • Page 51 Working with the Big Pack Baler 5.4.2 Inserting the Twine The knotter shaft must be secured every time new twine is inserted, so that the needle yoke cannot move. To do this move the safety lever (1) from position (a) to posit- ion (b) and rest on shaft (2).
  • Page 52 Working with the Big Pack Baler Feeding the Twine into the Twine Brake Das durch die unteren Garnösen des Garnkasten kom- mende Bindegarn (1) in die Garnbremsen (2) einführen und über die äußere Garnführung (3), in die Ösen (4) einfädeln. Von hier aus über die Garnspannfedern (5) über die Garnösen (6) in die Bindenadeln (7) einfädeln und an die entsprechenden Ösen (8) anknoten.
  • Page 53 Working with the Big Pack Baler Die Einstellung der Garnbremsen (siehe Kap. 6.4) erfolgt durch Verdrehen der Einstellschrauben (1). BP-VFS-016 5.4.3 Electric Twine Fault Display If the end of the twine has been reached or the twine is broken, the sprung twine tensioners (1) auf den Dreh- winkel (2) ablegen.

  • Page 54: Emptying The Bale Channel

    Working with the Big Pack Baler 5.5 Emptying the Bale Channel The maintenance platform may only be mounted when the machine is at a standstill. Switch off the engine and remove the ignition key. Apply the flywheel brake. The packs in the bale channel should be bound before emptying the bale channel.

  • Page 55: Settings

    Settings 6. Settings 6.1 Special Notes on Safety • The following always applies for all maintenance, mounting, repair and adjustment work: switch off the PTO shaft. Switch off the engine and remove the ignition key. Apply the flywheel brake. • Only put the big pack baler into operation when all protective devices have been attached and are in a proper operating condition.
  • Page 56 Settings 6.2.2 Height of the Needles on the Knotter Single Knotter To set the height of the needles on entry into the knot- ter, the needle yoke is turned upwards at the flywheel mass after manually initating the binding process. It is turned up in the working direction until the rollers in the needle tips are above the cleaning disc on the carrier (2).
  • Page 57 Settings 6.2.4 Needles in Idle Position If the needle yoke is in the idle position, i.e. the crank arm (1) and the needle drive connecting rod (2) are ex- tended, there must be a distance „c“ = 0 - 20 mm between the cross tube of needle yoke (4) and brake (3).
  • Page 58 Settings 6.2.5 Needles Relative to the Baling Ram To set the needles relative to the baling ram, the drive PTO shaft for the knotter shaft must first of all be dis- mounted. The baling ram is turned manually in the wor- king direction at the flywheel mass until the crank arms and the piston rods are overlapping each other (i.e.

  • Page 59: Twine Bar

    Settings 6.3 Twine Bar The twine bar (1) draws the twine down from the needle and presses it against the knotter hook. If the twine is not taken by the twine bars, the knotter hook cannot take up the twine. BP-VFS-020 6.3.1 Adjusting the Twine Bar Initiate the binding process manually (see chapter 5.4.4...
  • Page 60 Settings 6.4 Einstellung der Garnbremse (Single knotter) Die Garnbremsen (2) befinden sich unter den Garnvor- ratsbehältern. Durch die Einstellschrauben (3) wird das Bindegarn (1) unter Spannung gehalten. Unterschiedliche Bindegarnsorten können unterschiedli- che Reibeigenschaften besitzen. Die Zugspannung des Bindegarnstranges muß bei Bindegarnsortenwechsel überprüft werden.

  • Page 61: Baling Ram Setting

    Settings 6.5 Baling Ram Setting • The guide rollers for the baling ram must carry uniformly. • The gap between the baling ram blade and the blades in the bale channel must be uniform over the whole width of the ram. The bale chamber is equipped with two blades (6).

  • Page 62: Setting The Rake Relative To The Baling Ram

    Settings 6.6 Setting the Rake Relative to the Baling Turn the rake manually in the working direction until the small guide roller (3) des Zubringers (1) is visible in window (2) on the right hand side of the machine. Lift up the guide roller with a mounting lever (4) so far that it meets resistance.
  • Page 63 Settings 6.7 Setting the clutch 1. Adjust the adjusting screw (14) so that the clutch switch ratchet (18) sits B = 8 – 10 mm on the middle of the roller (19) when the clutch is switched off. 2. If the anvil (15) sits on the adjusting screw (14), the rear of the back holder rake (12) has to stand parallel to the back wall of the feed packer channel.

  • Page 64: Adjusting The Flywheel Cleaning Mechanism

    Settings 6.9 Setting the sensibility of the actuator The spring (23) is responsible for bringing the back holder rake into its swing position again after the feeder insertion (over the anvil (15) and the threaded rod (13)). The anvil (15) therefore has to arrive at the adjust screw (24).
  • Page 65 Settings 6.11 Lage der Sensoren Die Angaben zur Einstellung der Sensoren entnehmen Sie bitte dem Anhang A1.2.2! Lage der Sensoren an der BP 88 / 127 / 128 Left hand side Blade sensor "Multi Cut" Needle connecting rod sensor Twine tightener sensor Flywheel brake sensor VI - 11...
  • Page 66 Settings Right hand side Lage der Sensoren an der BP 88 / 127 / 128 Pack shute sensor Calibration sensor Rake controle sensor Measurement sensor Sensor Rafferzufuhr Knotter sensor VI - 12...
  • Page 67 Settings 6.12 Adjusting the Sensors Das Maß zwischen dem Geber (2) und dem Sensor (1) muß "a" = 3 mm betragen. Adjustment: • Muttern an beiden Seiten des Sensors lösen. • Turn the nuts until the distance "a" = 3 mm has been reached.

  • Page 68: Basic Adjustment Of The Flywheel Brake

    Settings 6.13 Basic adjustment of the flywheel brake The flywheel brake must be re-adjusted if the brake power is no longer satisfactory (worn brake block) or if the flywheel brake has been removed (e.g. after replacement of the friction clutch). For this proceed as follows: 1.

  • Page 69: Installing The Flywheel Brake

    Settings 6.14 Installing the flywheel brake The flywheel brake must be removed for any replacement of the friction clutch. Utmost care is essential during the subsequent installation of the brake. Installation procedure: 1. Install the intermediate PTO shaft onto the friction clutch.
  • Page 70 Settings VI - 16...

  • Page 71: Care And Maintenance

    Care and Maintenance 7. Care and Maintenance 7.1 Special Notes on Safety • Repair, care, maintenance and cleaning work may only be carried out with the machine at a standstill. Switch off the engine and remove the ignition key. Apply the flywheel brake. •...

  • Page 72: Cleaning

    Care and Maintenance 7.3 Cleaning The big pack baler, in particular the knotter, must be cleaned of chaff and dust every time it is used. Under very dry working conditions clean several times a day. Ebenfalls täglich die Raffersteuerung und das Schwungrad von Spreu und Staub reinigen.

  • Page 73: Hydraulics

    Check hydraulic hoses and lines regularly and replace any damaged ones. • The replacement parts employed must comply with the technical requirements of the machine manufacturer. Only use genuine KRONE replacement parts. • Repair work to the hydraulics system may only be carried out by qualified specialists.

  • Page 74: Changing And Checking The Oil In The Gearboxes

    Care and Maintenance 7.6.3 On-Board Hydraulic Circuit Diagram BP380-7-077 Designations: Abbreviations: Designations: a) Circuit diagram for the on-board hydraulics A = Outlet I = Electro-hydraulic valve block b) Circuit diagram for the pick up hydraulic cylinder M = Pressure gauge II = Baling flap cylinder c) Circuit diagram for the flywheel brake P = Pump...
  • Page 75 Care and Maintenance 7.7.2 Main Gearbox The oil check (3) and oil drain (2) screws are located on the left hand side of the main gearbox (1). Checking the Oil Check the oil level in the main gearbox every time before using the machine.
  • Page 76 Care and Maintenance 7.7.5 Pick Up Gearbox The upper and lower pick up gearboxes (3) are located on the right hand side of the machine. Checking the Oil Check the oil level in the upper pick up gearboxes (3) every time before using the machine. To do this unscrew the oil check screw (1).

  • Page 77: Compressed Air Unit

    Care and Maintenance Oil check Check the oil level in the angular gearbox (1) before each operation. To do this remove the check screw (2). The oil level must reach the lower edge of the check hole, if necessary top up the oil through the breather hole (3). Oil change The oil should be changed after every season.

  • Page 78: Replacing The Guide Rollers On The Rakes

    Care and Maintenance 7.8.3 Brake Cylinders Excess pressure should be released from the compressed air system before disassembling the membrane brake cylinder. There is a danger of injury! Special maintenance for the brake cylinders (1) is not necessary. The membrane cylinders should be removed, disassembled, cleaned, parts subject to wear replaced and reassembled at least every two years.

  • Page 79: Lubrication

    Lubrication 8. Lubrication 8.1 Special Notes on Safety • Repair, care, maintenance and cleaning work may only be carried out with the machine at a standstill. Switch off the engine and remove the ignition key. Apply the flywheel brake. • Secure the big pack baler and the tractor from rolling away.
  • Page 80 Lubrication Lubrication Points In the following table lists the most lubrication points on the big pack baler, as well as the number of lubricating nipples. Lubrication Points No. of Lubricating Nipples Crank pin for bale ram drive right and left Piston piin for baling ram drive right and left Bearing rollers on ram right and left Guide rollers on conveyor and feeder rakes...
  • Page 81 Lubrication Lubrication Points on the Big Pack Baler (left hand side) VIII - 3...
  • Page 82 Lubrication Lubrication Points on the Big Pack Baler (right hand side) VIII - 4...
  • Page 83 Lubrication Lubrication Points on the Big Pack Baler with MultiCut (left hand side) VIII - 5...
  • Page 84 Lubrication Lubrication Points on the Big Pack Baler with MultiCut (right hand side) VIII - 6...

  • Page 85: Knotter

    Knotter 9. Knotter 9.1 Special Notes on Safety • All maintenance, adjustment and repair work on the knotter may only be carried out with the machine at a standstill. Switch off the engine and remove the ignition key. • Lock the flywheel brake. •...

  • Page 86: The Twine Mount

    Knotter 9.3 The Twine Mount The groove for the carrier (5) (Fig. BP 380-0-055) must be positioned between the twine mount (6) tips and the rear halves of the cleaners (7) so that the strand of twine can be inserted properly. To check that the groove is positioned correctly at least two binding cycles must be completed.
  • Page 87 Knotter The stripping comb on the blade lever (2) must touch the rear of the knotter hook (3) lightly but uniformly. The distance between the stripping comb on the blade lever (2) and the tip of the knotter hook (1) should be "a"...

  • Page 88: Knotting

    Knotter Adjusting the blade Lever To adjust the blade lever (1), loosen the Knotting device's fixing device (3) on the bale channel and swing the frame around the knotting device drive shaft. For bending the blade lever (1) it is useful to make an approximately 400 mm long straightening lever (2) like in fig.

  • Page 89: Over The Winter Special Notes On Safety

    Have the necessary repair work carried out in the time directly after the harvest season. Prepare a list of all spare parts required. By doing this it is easier for your KRONE dealer to process your orders and you can be sure that your machine will be in top condition for the start of the next season.
  • Page 90 X - 2...

  • Page 91: Putting Into Operation Again

    Putting into Operation Again 11. Putting into Operation Again 11.1 Special Notes on Safety • The following always applies for all maintenance, assembly, repair and adjustment work: bring the machine to a standstill. Switch off the engine. Remove the ignition key. Apply the flywheel brake.
  • Page 92 Putting into Operation Again XI - 2...

  • Page 93: Special Equipment

    Special Equipment 12. Special Equipment 12.1 MultiCut cutting system 12.1.1 Special notes on safety The following always applies for all maintenance, assembly, repair and adjustment work: • Bring the machine to a standstill. • Switch off the engine and remove the ignition key. •...
  • Page 94 Special Equipment Setting the cutting length Turn the locking lever (3) to the right. (selector disc unlocked.) Fit the special spanner (1) onto the blade control shaft (2) and turn it in the direction of the arrow. BP380-7-105 The blade control shaft must be secured using the locking lever once the setting has been made.
  • Page 95 Special Equipment 12.1.4 Changing blades The cutter system blades can be reached from underneath the machine. Clean the conveyor channel before changing the blade. Put the blade control shaft into an intermediate position An intermediate position is a setting BP-VFS-031 between 2 control settings.
  • Page 96 Special Equipment 12.1.5 Blade stop Switching blade control shaft off mechanically Unlock the locking lever (3). Die Messerschaltwelle (2) mit dem Spezialschlüssel in eine Zwischenposition drehen. If the Big Pack MultiCut is to be operated for a long time without a cutting system, we recommend removing the blades.
  • Page 97 Special Equipment 12.1.6 Setting the blade control shaft sensors The sensor (2) is only used to send a signal to the comfort control. Blade operation is indicated on the comfort control. The sensor (2) is on the left-hand side of the machine on the blade control shaft.

  • Page 98: Compressor

    Special Equipment • Let the control lever (2) engage in position B • Turn back flywheel until the blockage is removed. When you start up the machine again the free-wheel switches on automatically. The control lever (2) goes back into basic position A. BP380-7-117 12.2 Compressor If the big pack baler is fitted with hydraulic brakes, the...

  • Page 99: Swath Distributor

    Special Equipment 12.3 Swath Distributor To be able to distribute narrow swaths along the total width of the pick-up, the hydraulically driven swath distributor is available as an accessory. Swath distributor is not fitted at the factory. 12.3.1 Assembly Instructions BP380-7-120 1) Lateral limiter (left) 2) Hydraulic hoses (pressure and reverse-flow hose)
  • Page 100 Special Equipment Installing swath distributor • Lift the swath distributor (1) from below to the drawbar (3) • Place swath distributor with screws (2) on drawbar • Line up the swath distributor in the centre in front of the pick-up •...

  • Page 101: Hydraulic Folding Bale Chute With Rollers

    Special Equipment 12.4 Hydraulic folding bale chute with rollers Secure the vehicle and machine against rolling away. Keep people clear of the danger zone when folding the bale chute in and out. Only drive on public roads if the bale chute has been folded in. A hydraulic folding bale chute (4) with seven rollers (3) is available for the Big Pack as an optional extra.
  • Page 102 Special Equipment Folding the bale chute in and out To fold out the bale chute (1), lift the safety collar (2) and move the operating lever (3) to position (B). To fold in the bale chute (1), lift the safety collar (2) and move the operating lever (3) to position (A).

  • Page 103: Wide Pick-Up

    Special Equipment 12.5 Wide pick-up Transporting the Big Pack 127 and 128 with wide pick-up (2.4 m) on public roads is only permissible with retracted gauge wheels. Observe the type approval requirements! Folded in the gauge wheels • Remove pin (1). BP380-7-128 •...
  • Page 104 Special Equipment with cutting mechanism MultiCut • Place the gauge wheel bracket into its support (4). • Secure the bracket by installing pin (5) in the lower hole (7). BP380-7-130 with cutting mechanism BigCut • Place the gauge wheel bracket into its support (8). •...
  • Page 105 Special Equipment 12.7 Doppelknoter 12.7.1 Arbeitsweise des Systems Während der Ballenbildung wird dem Ballen ein oberer und unterer Garnstrang zugeführt, die jeweils am Anfang (Startknoten) und Ende (Schließknoten) des Ballens miteinander verknotet werden. Der untere Garnstrang wird dem Ballen über ein Spannsystem durch die Nadel zugeführt und um- schließt den Boden und die beiden Endseiten des Ballens, wobei der obere Garnstrang dem Ballen direkt...
  • Page 106 Special Equipment 12.7.3 Bindegarn einlegen Bindegarn einlegen s. Kap. 5.4.2. Alle abweichenden Punkte werden hier gesondert aufgeführt. Während des Ballenbindekreislaufs werden jedem der 6 (4) Knüpfer zwei Garnstränge zugeführt, wobei der eine von unten durch die Nadeln und der zweite von oben direkt dem Ballen zugeführt wird.
  • Page 107 Special Equipment Unterer Garnstrang (linke Seite) Das Garn (1) wird durch die Ösen (2) des Garnkasten, über die Garnführung (3) in die Bremse (4) geführt. Von dort aus gelangt es über die Öse der Spannfeder (5) durch die Rollen der Knoternadeln (6), auf die Untersei- te des Ballens.
  • Page 108 Special Equipment 12.7.4 Garnlaufanzeige Der untere Garnstrang wird elektronisch kontrolliert (Kap. 5.4.3 Elektrische Garnfehlanzeige). Der obere Garnlauf kann durch Reflektoren (Garnlauf- anzeiger), die oberhalb der Maschine angebracht sind, überwacht werden. Im Verlauf der Ballenbildung sollten sich die Garnlauf- anzeiger pulsierend hin und her bewegen. Alle Anzeiger heben und senken sich im allgemeinen gleichzeitig, außer im Falle einer Störung.
  • Page 109 Special Equipment 12.7.5 Einstellungen In diesem Kapitel werden nur die Einstellungen be- schrieben, die sich abweichend von denen des Einfachknoters darstellen. Ansonsten sind die Angaben der Einstellung den entsprechenden Kapiteln zu ent- nehmen. Garnspannung am oberen Garnstrang Die oberen Garnstränge (1) sollten bis zu einer Zugkraft von 80 - 100 N durch die Bremsen (2) zurückgehalten werden.
  • Page 110 Special Equipment Bindenadel-Einlegearm-Ausrichtung Die Mitten der Einlegearmrollen sollten um a = ca. 3 mm nach links versetzt zur Nadelmitte laufen, so daß die Einlegearme mit einem Sicherheitsabstand von b = 1-2 mm zur linken Seite des Kanalschlitzes einge- stellt werden. Dieses kann durch Ausgleichen mit Passscheiben an den Enden der Einlegearmwelle geschehen.
  • Page 111 Special Equipment 12.8 Störungssuche beim Doppelknoter Die Erfahrung hat gezeigt, daß ein Großteil der Bindeprobleme auf unzureichende Garnspannung zurückzuführen sind. Den Garnlauf und die Garnspannung vor Antritt der Arbeit überprüfen. Im folgenden werden die häufigsten Störfälle mit deren Ursache aufgeführt und für deren Behebung ein Hinweis gegeben.
  • Page 112 Special Equipment Störfall mögliche Ursache Behebung Kap. Erster Knoten: Der Garnriegel hat den unteren Den Garnriegel nachstellen. 12.7.5 (Schließknoten) Garnstrang nicht gegriffen. ausschließlich am Nadeleinstellung überprüfen. oberen Garnstrang vorhanden. Zweiter Knoten: Der Garnriegel ist zuweit vom Den Garnriegel in Richtung Einlegearm 12.7.5 (Startknoten) Einlegearm entfernt eingestellt...
  • Page 113 Special Equipment Störfall mögliche Ursache Behebung Kap. Kein Knoten- Garnriegel wird nicht betätigt. Den Garnriegelmechanismus und deren 12.7.5 vorhanden, weder Einstellung kontrollieren. im oberen noch im unteren Garnstrang. Beschädigte Knoterzunge. Die Knoterzunge auswechseln. 12.7.5 Unzureichende Spannung an Die Spannung an der Knoterzunge erhö- 12.7.5 der Knoterzunge.
  • Page 114 Special Equipment XII - 22...

  • Page 115: Faults, Their Causes And Elimination

    (2). Check whether the shear bolt is broken. If necessary replace with a M10 x 60, DIN 931-10.9 bolt. Only use genuine KRONE replacement parts. Fehler wird durch eine Fehlermeldung am Bedienpult und das Ertönen eines Huptones angezeigt.

  • Page 116: Rake Drum

    Faults, their Causes and Elimination 13.5 Rake Drum The rake drive is protected from overloading with a spring-loaded ratchet clutch inside the gearbox. If the clutch is activated, switch off the PTO shaft imme- diately. Stop the tractor and the machine. Allow the big pack baler to come to a standstill.

  • Page 117: Further Faults

    Faults, their Causes and Elimination 13.7 Further Faults Cause / Remedy Fault Horn and indicator lamp for the twine error display 1. Cable connection, 3-pole plug to tractor not activated at end of twine or when twine broken. defective. Horn and indicator lamp for twine activated. 1.
  • Page 118 Faults, their Causes and Elimination Fault Cause / Remedy 1. Readjust the twine brake, clean or replace if necessary. 2. Readjust the knotter shaft brake. 3. Remove tangled twine. 4. Straighten the pack initiating mechanism. 5. Check the twine bar – readjust. BP 380-7-137 Knot tying mechanism (twine has snagged on the knotter hook and is broken.)
  • Page 119 Faults, their Causes and Elimination Fault Cause / Remedy 1. Blunt twine blade – sharpen the cutting edge of the Knot ends frayed. twine blade or replace blade. 2. Too little tension on the twine retainer – tighten the Knot only in the strand of twine guided upwards by the springs by tightening up the hexagonal screw (do needle.
  • Page 120 Faults, their Causes and Elimination Fault Cause / Remedy Knots hanging on the knotter hook. 5. Blade lever scraping distance too low (the blade lever can be deformed if the twine blade is blunt) – remove the blade lever and position, replace if necessary;...

  • Page 121: Finding Errors In The Central Lubrication System

    Faults, their Causes and Elimination 13.8 Finding Errors in the Central Lubrication System Fault Eliminating the Fault Blockage in the system or in any connected Establishing the Causes of Blockages and Eliminating bearings. Them. PROCEDURE Hand-actuated systems. First check whether the transport pump is working and is Hand lever cannot be moved or is hard to move.
  • Page 122 Faults, their Causes and Elimination XIII - 8...
  • Page 123 Appendix A1 Integrated Diagnostic Program – Comfort Controls A1.1 General Information The integrated diagnostic program is an integral part of the comfort controls. The diagnostic program enables you to check the electri- cally and electronically operated components on the big baler and their power supply.
  • Page 124 Appendix A1.2 Sensor Test Überprüfen und Einstellen der Sensoren und Ventile mit Hilfe des Diagnoseprogramms: • Taste betätigen und betätigt halten. Hand Auto Sensortest • Actuate key. weiter...ok?..Prog Quit • Taste loslassen, wenn „Sensortest“ im Display erscheint. • Mit Taste kann im Diagnoseprogramm weiter geblättert werden...
  • Page 125 Appendix A1.2.2 Manual Sensor Test Jeder Sensor wird einzeln überprüft und das Ergebnis wird angezeigt. • Taste betätigen. Hand Auto Sensortest weiter...ok?..Prog Quit BP-VFS-046 Beispiel: 1. Zeile: Sensor Messer Eichen 2. Zeile: Fehlertyp bzw. Schaltzustand z. B.: Fehlertypen Masseschluss Messer Eichen Kabelbruch...
  • Page 126 Appendix Wenn alle Sensoren überprüft wurden, schaltet die Anzeige zum Sensortest zurück. Mit Taste zum Ventiltest blättern. Hand Auto Sensortest weiter...ok?..Prog Quit BP-VFS-046 A1.3 Valves Test A.1.3.1 Auto Valves Test • Taste betätigen. Keine Überprüfung der mechanischen/hydraulischen Funktion der Ventile. Alle Ventile der Maschine werden elektronisch überprüft.
  • Page 127 Appendix Wird während der Überprüfung ein Fehler festgestellt, hält das Programm an. Im Display der Bedienung erscheint folgende Meldung: 1. Zeile Ventilspulenbezeichnung 2. Zeile Fehlertyp z. B.: Masseschluss Kabelbruch Kurzschluss zu .. Regelung ..auf Kabelbruch Powerschluss X6: 34/5 -> Y2: 2/1 weiter zurück Prog...
  • Page 128 Appendix Beispiel: 1. Zeile: zu .. Regelung .. auf 2. Zeile: Fehlertyp bzw. Schaltzustand z. B.: Fehlertypen Masseschluss Kabelbruch zu .. Regelung ..auf Kabelbruch Kurzschluss X6: 34/5 -> Y2: 2/1 Powerschluss weiter zurück Prog Quit Schaltzustand ein ! aus ! defekt ! 3.
  • Page 129 Appendix Ventil der Knoterreinigung Das Druckluftventil der Knoterreinigung befindet sich vorne links am Knotertisch. Durch Betätigen Taste wird das Ventil geöffnet. Befindet sich Druckluft im Ventil Knoterreinig..aus !..Vorratsbehälter der Knoterreinigung, wird diese abge- weiter zurück Prog Quit blasen.
  • Page 130 Appendix Electrical Circuit Diagram Big Pack 88/127/128 x1/24 x1/42 x1/34 x1/15 Nadelzugstange x1/25 x1/41 x1/36 Ballenschurre x1/22 x1/32 x1/16 x1/18 Fadenkontrolle gelb Kraftsensor x1/14 gr n Rechts braun x2/13 gelb Kraftsensor x2/9 gr n Links braun x2/29 x2/31 Sensor Messen x2/19 x2/32 Sensor...
  • Page 131 Appendix A1.4 Alarm and Error Messages Big Pack 88/127/128 Problem Possibles cause Remedy ALARM-NO.: • Twine broken • Check twine and twine tensioner TWINE TIGHTENER DEF! • End of twine ALARM-NO.: • Blockage in the feed area • Stop the machine immediately RAKE CARRYING OVER! of the packer •...
  • Page 132 . . konsequent, kompetent Maschinenfabrik Bernard Krone GmbH Heinrich-Krone-Straße 10, D-48480 Spelle Postfach 11 63, D-48478 Spelle Phone +049 (0) 59 77/935-0 +049 (0) 59 77/935-339 Internet: http://www.krone.de eMail: info.ldm@krone.de...
