- Page 1 BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 New Information MN04012006E For more information visit: www.EatonElectrical.com...
- Page 3 August 2006 Important Notice – Please Read The product discussed in this literature is subject to terms and conditions outlined in Eaton Electrical Inc. selling policies. The sole source governing the rights and remedies of any purchaser of this equipment is the relevant Eaton Electrical Inc. selling policy.
-
Page 4: Table Of Contents
Modbus/TCP Option Board OPTCi for 9000X Drives User Manual August 2006 Table of Contents LIST OF FIGURES ............LIST OF TABLES . - Page 5 BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 List of Figures Figure 1-1: Cutler-Hammer BACnet Option Board OPTCJ ......Figure 2-1: Bus Cables .
-
Page 6: Safety
Modbus/TCP Option Board OPTCi for 9000X Drives User Manual August 2006 Safety Definitions and Symbols WARNING This symbol indicates high voltage. It calls your attention to items or operations that could be dangerous to you and other persons operating this equipment. Read the message and follow the instructions carefully. -
Page 7: Warnings And Cautions
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Warnings and Cautions WARNING Internal components and circuit boards are at high potential when the drive is connected to the power source. This voltage is extremely dangerous and may cause death or severe injury if you come into contact with it. - Page 8 Modbus/TCP Option Board OPTCi for 9000X Drives User Manual August 2006 For more information visit: www.EatonElectrical.com MN04012006E...
-
Page 9: Chapter 1 - General
This manual describes the installation, configuration and use of the OPTCJ BACnet fieldbus adapter from Eaton’s electrical business. The OPTCJ is a plug-in board that is compatible with any open or enclosed drive product that uses an SVX or SPX processor module (including the HVX9000 or CPX9000 family). -
Page 10: Optcj Board
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 OPTCJ Board Table 1-1: BACnet Option Board Technical Data Category Description Specification Connections Interface OPTCJ: Pluggable connector (5.08 mm) Data transfer method RS-485 MS/TP, half-duplex Transfer cable Twisted pair (1 pair and shield) Electrical isolation 500V DC Communications... -
Page 11: Bacnet Fieldbus Board Layout And Connections
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 BACnet Fieldbus Board Layout and Connections The BACnet option board is connected to the fieldbus through either a 5-pin pluggable bus connector (board OPTCJ) or a 9-pin female sub-D-connector (board OPTC8). The communication with the control board of the drive takes place through the standard ®... - Page 12 BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 For more information visit: www.EatonElectrical.com MN04012006E...
-
Page 13: Chapter 2 - Installation
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Chapter 2 — Installation Grounding Cable Shield Grounding by Clamping the Cable to the Converter Frame (Recommended) This manner of grounding is the most effective and especially recommended when the distances between the devices are relatively short or if the device is the last device on the net. -
Page 14: Figure 2-3: Locate Grounding Clamp
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 3. Insert the data conductors of both cables into terminals #3 (Line B) and #4 (Line A). 4. Strip the cable at such a distance from the terminal that you can fix it to the frame with the grounding clamp. -
Page 15: Figure 2-5: Both Cables On One Clamp
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Grounding Only One Point on the Net In this manner of grounding, the shield is connected to ground only at the last device on the net in the same way as described on Pages 2-1 and 2-2 . Other devices of the net just pass the shield. -
Page 16: Figure 2-7: Biasing Resistor Connections
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Bus Biasing Bus biasing is recommended to ensure fault free communication between all of the devices on RS-485. Bus biasing ensures that the bus is at the proper potential when no device is transmitting. -
Page 17: Led Indications
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 LED Indications The two LED indications next to the connector show the present statuses of the BACnet board (yellow) and the Fieldbus Module (green). Yellow Green Figure 2-8: LED Indications on the BACnet Board Table 2-2: BACnet Board Status LED (BS) YELLOW LED is: Meaning... -
Page 18: Table 2-4: Installing The Bacnet Option Board
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Installing the BACnet MS/TP Option Board in an 9000X Drive CAUTION Make sure that the drive is switched OFF before an option or fieldbus board is changed or added. Table 2-4: Installing the BACnet Option Board Item Description... - Page 19 BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Table 2-4: Installing the BACnet Option Board (Continued) Item Description Install the BACnet option board in slot E on the control board of the drive. Make sure the grounding plate (shown below) fits tightly in the clamp.
- Page 20 BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 For more information visit: www.EatonElectrical.com MN04012006E...
-
Page 21: Chapter 3 - Configuration
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Chapter 3 — Configuration IMPORTANT First read the Menu Information Chapter in your 9000X drive user manual. Note: You must select Fieldbus as the active control place, if you wish to control the drive through fieldbus. -
Page 22: Figure 3-2: Communication Status
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Table 3-1: BACnet Option Board Parameters Name Default Range Description MAC ADDRESS 1 – 127 INDEX NUMBER 0-65535 Unique system identifier BAUD RATE 1 – 9600 baud Communication speed 2 –... -
Page 23: Annex - Protocol Implementation Conformance Statement (Normative)
(This annex is part of this Standard and is required for its use.) BACnet Protocol Implementation Conformance Statement Date: May 31, 2005 Vendor Name: Eaton Cutler-Hammer Product Name: BACnet Option Board Product Model Number: OPTCJ Applications Software Version: 10522 Firmware Revision: 1 BACnet Protocol Revision: 4 Product Description: BACnet Option board is designed for CH SVX family devices. -
Page 24: Object Map
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Object Map Table 3-3: Object Types and Properties Supported Object Type Property Device Binary Value Analog Value Object Identifier Object Name Object Type System Status Vendor Name Vendor Identifier Model Name Firmware Revision Appl Software revision... -
Page 25: Table 3-4: Binary Value Object
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Table 3-4: Binary Value Object Instance Present Value Object Name Description Inactive / Active Access Type Ready State Indicates whether the drive is Not Ready / Ready ready or not Run/Stop State Indicates whether the drive is Stop / Run... -
Page 26: Table 3-5: Analog Value Object
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Table 3-4: Binary Value Object (Continued) Instance Present Value Object Name Description Inactive/Active Access Type BV24 FBFixedControlWord Application Specific bit from 0 / 1 Bit_9 the Fixed Control Word BV25 FBFixedControlWord Application Specific bit from... - Page 27 BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 Table 3-5: Analog Value Object (Continued) Instance Present Value Object Name Description Units Access Type AV16 FBProcessDataOut2 Application specific -32768.0 to +32767.0 resolution 1.0 AV17 FBProcessDataOut3 Application specific -32768.0 to +32767.0 resolution 1.0 AV18...
- Page 28 BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 For more information visit: www.EatonElectrical.com MN04012006E...
-
Page 29: Chapter 4 - Fault Tracking
If installation is correct contact ● Duplicate MAC ID (Bad Frames in “Comm. the nearest Eaton representative. status” is incremented every time a frame Check that MAC ID is unique. is received from a device with the same MAC ID on the same segment.) -
Page 30: For More Information Visit: Www.eatonelectrical.com
BACnet MS/TP Option Board OPTCJ for 9000X Drives User Manual August 2006 For more information visit: www.EatonElectrical.com MN04012006E... -
