User Manual – AS5261 / AS5262 Adapterboard
AS5261-EK-AB / AS5262-EK-AB
12 BIT Magnetic Angle Position
Sensor with 2 Outputs
www.ams.com
Revision 1.0 / 2012/10/31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS5262 and is the answer not in the manual?

Questions and answers

Summary of Contents for AMS AS5262

  • Page 1 User Manual – AS5261 / AS5262 Adapterboard AS5261-EK-AB / AS5262-EK-AB 12 BIT Magnetic Angle Position Sensor with 2 Outputs www.ams.com Revision 1.0 / 2012/10/31...
  • Page 2: Table Of Contents

    Table of Contents General Description ....................... 2 Package and Board Description .................... 3 AS5261/ AS5262 and adapter board pin out ................. 5 Operation case ........................6 Programming the AS5261 / AS5262 ..................6 AS5261 /AS5262 adapter board hardware ................7 Ordering Information ......................
  • Page 3: General Description

    12 bit ratiometric analog output. The AS5261 / AS5262 operates at a supply voltage of 5V and the supply and output pins are protected against overvoltage up to +20V. In addition the supply pins are protected against reverse polarity up to –20V.
  • Page 4: Package And Board Description

    Diametrial Magnets Board Description The AS5261 / AS5262 adapter board is a simple circuit allowing test and evaluation the rotary encoder quickly without building a test fixture or PCB. The PCB requires a 4-wire connection: 5V power supply, GND and two output connection . If there is the need to use full redundancy ( 6- wire connection), a different PCB is required.
  • Page 5 Magnet AS516x A diametric magnet must be placed over or under the AS5261 / AS5262 Sensorboard, and should be placed centered in x and y direction. Tolerance of 0.5mm The airgap between the magnet and the encoder casing should be maintained in the range of 0.5mm~2mm ( magnet related).
  • Page 6: As5261/ As5262 And Adapter Board Pin Out

    AS5261/ AS5262 Adapterboard User manual 3. AS5261/ AS5262 and adapter board pin out NC_T NC_B Epad VDD3V3_T NC_B VDD3V3_B NC_T Figure 4 AS5261/AS5262 adapterboard connectors and sensor pinout Table 2: Pin Out Pin# Pin# Symbol Type Description Board AS5261/62 Board...
  • Page 7: Operation Case

    The internal LDO provides the current for programming. The AS5261 / AS5262 uses a standard UART interface with an address byte and two data byte. For programming the AS5261 / AS5262 there is a DemoSoftware ( Executable Labview) and an easy UART-Interfaceboard available.
  • Page 8: As5261 /As5262 Adapter Board Hardware

    AS5261/ AS5262 Adapterboard User manual FOTO 6. AS5261 /AS5262 adapter board hardware AS5261-EK-AB; AS5262-EK-AB Schematic Figure 6 Adapterboard Schematic AS5261-EK-AB; AS5262-EK-AB PCB layout Figure 7: Adapterboard Layout www.ams.com Revision 1.0 / 10/31/12 page 7/10...
  • Page 9: Ordering Information

    AS5261/ AS5262 Adapterboard User manual 7. Ordering Information Table 2: Ordering Information Ordering Code Description comments AS5261-EK-AB Adapterboard 3 diametric magnets AS5261-EK-AB Adapterboard 3 diametric magnets www.ams.com Revision 1.0 / 10/31/12 page 8/10...
  • Page 10: Copyright

    No obligation or liability to recipient or any third party shall arise or flow out of ams AG rendering of technical or other services.
  • Page 11 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: AS5262-EK-AB AS5261-EK-AB...
