vacon • 9
3
1
Figure 2. Removing the option slot cover.
• Make sure that the sticker on the connector of the board says "dv" (dual
voltage). This indicates that the board is compatible with Vacon 20CP/X.
See below:
• NOTE: Incompatible boards cannot be installed on Vacon 20CP/X. Compat-
ible boards have a slot coding that enable the placing of the board (see
above).
Multipurpose Application
Slot coding
9116.emf
