I/O Interface Module Catalog Number 1756-DHRIOXT Topic Page Important User Information About the 1756-DHRIOXT Module About ControlLogix-XT Systems ControlLogix-XT with Traditional ControlLogix Components Before You Begin Set the Network Type and Node Address Switches Prepare the Chassis for Module Installation... - Page 2 2 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Topic Page Alphanumeric Display Startup Sequence Power Supply Status Alphanumeric Display Codes Status Indicators General Specifications - 1756-DHRIOXT Environmental Specifications - 1756-DHRIOXT Certifications - 1756-DHRIOXT Additional Resources Publication 1756-IN638A-EN-P - March 2009...
-
Page 3: Important User Information
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment. - Page 4 4 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Environment and Enclosure This equipment is intended for use in a Pollution Degree 2 industrial ATTENTION environment, in overvoltage Category II applications (as defined in IEC 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR 11.
- Page 5 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 5 North American Hazardous Location Approval The following information applies when Informations sur l'utilisation de cet operating this equipment in hazardous équipement en environnements dangereux: locations: Products marked "CL I, DIV 2, GP A, B, C, D" are suitable for Les produits marqués "CL I, DIV 2, GP A, B, C, D"...
- Page 6 6 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module European Hazardous Location Approval European Zone 2 Certification (The following applies when the product bears the Ex or EEx Marking) This equipment is intended for use in potentially explosive atmospheres as defined by European Union Directive 94/9/EC and has been found to comply with the Essential Health and Safety Requirements relating to the design and construction of Category 3 equipment intended for use in potentially explosive atmospheres, given in Annex II to this Directive.
-
Page 7: About The 1756-Dhrioxt Module
Store the equipment in appropriate static-safe packaging when not in use. About the 1756-DHRIOXT Module You can use the 1756-DHRIOXT module to communicate on a DH+ or remote I/O network. The 1756-DHRIOXT module functions in the same way as the traditional 1756-DHRIO module. - Page 8 8 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Use this diagram to identify external features of the module. FRONT SIDE 1756-DHRIOXT BOTTOM 31925-M Item Description Network type switches Alphanumeric display Status Indicators 8-pin mini DIN port for programming terminal Channel A connector...
-
Page 9: About Controllogix-Xt Systems
ControlLogix-XT module can withstand only the environments specified for the traditional ControlLogix version of the module. For example, if a 1756-DHRIOXT module is used in a traditional 1756-A10 chassis, the 1756-DHRIOXT module can withstand only the environment specified for the traditional 1756-DHRIO module. -
Page 10: Before You Begin
10 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Before You Begin Before you install your module, complete these tasks: • Set the Network Type and Node Address Switches, page 10 • Prepare the Chassis for Module Installation, page 11 • Determine Module Slot Location, page 12 Set the Network Type and Node Address Switches Before you install the module, set the network type switches for each... -
Page 11: Prepare The Chassis For Module Installation
ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 11 If you set the network type to Data Highway Plus (DH+), also set the node address switches for that channel to a unique address within the range of 0…77. 2. Set the node address switches on the bottom of the module to a unique node address. -
Page 12: Determine Module Slot Location
12 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Determine Module Slot Location You can use the ControlLogix-XT chassis that suits your application requirements. The 1756-DHRIOXT modules can be: • installed in any open chassis slot. • used in multiples in one chassis, within the limits of the ControlLogix-XT power supply. -
Page 13: Install The Module
ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 13 Install the Module Complete these steps to install the 1756-DHRIOXT module. Do not force the module into the backplane connector. If you cannot seat the ATTENTION module with firm pressure, check the alignment. Forcing the module into the chassis can damage the backplane connector or the module. -
Page 14: Remove Or Replace The Module
14 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Remove or Replace the Module Complete these steps to uninstall the 1756-DHRIOXT module. 1. Push on upper and lower module tabs to disengage them. 2. Slide the module out of the chassis. -
Page 15: Wire The Connectors For The Module Channels
A when channel A is configured for DH+ communication. Pin No. Wire Blue Shield Clear Channel A and B Connections Use the wiring specific to your application of the 1756-DHRIOXT module. Remote I/O Pin No. Wire Pin No. Wire... -
Page 16: Connect The Programming Terminal
16 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Connect the Programming Terminal Connect the programming terminal by using the 8-pin mini DIN connector. The local programming terminal port is intended only for temporary use and WARNING must not be connected or disconnected unless the area is assured to be nonhazardous. -
Page 17: Connect The Dh+ Or Remote I/O Network
Connect the DH+ or Remote I/O network to the channel A or B connector as appropriate. 10/10 0/BAS E T LINK NET 1756- DHRIO XT Apply Chassis Power Apply power to the ControlLogix-XT power supply to provide power to the 1756-DHRIOXT module installed in the chassis. Publication 1756-IN638A-EN-P - March 2009... -
Page 18: Check Power Supply And Module Status
18 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Check Power Supply and Module Status After you apply chassis power, check the power supply and module status indicators to verify the module is working properly. 31931-M See the section titled Status Indicators, page 24 for more information about interpreting module status. -
Page 19: Alphanumeric Display Startup Sequence
ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 19 Alphanumeric Display Startup Sequence At powerup, the module’s alphanumeric display cycles through this sequence. • Channel A and the network used for channel A - DH+ or RIO • Channel A node address, if used for DH+ •... -
Page 20: Power Supply Status
Operating None - this is normal operation. Configure Your 1756-DHRIOXT Module After installing your 1756-DHRIOXT module, you must configure it. The 1756-DHRIOXT module is configured using the same methods and considerations as the traditional 1756-DHRIO module. For more information about configuring and using the 1756-DHRIOXT and... -
Page 21: Alphanumeric Display Codes
ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 21 Alphanumeric Display Codes Your 1756-DHRIOXT module displays alphanumeric codes that provide diagnostic information. The alphanumeric display flashes the codes at approximately 1-second intervals. These tables describe codes and interpretations specific to the application of the module. - Page 22 22 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Remote I/O Codes and Interpretations Code Description Recommended Actions MUTE No adapters found on remote I/O. Add an adapter to the remote I/O LINK network. RACK Rack overlap on remote I/O. Reconfigure remote I/O racks. OVER DUPL Duplicate scanner on remote I/O.
- Page 23 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 23 Remote I/O Codes and Interpretations Code Description Recommended Actions Normal operation. None. MUTE No adapters found on remote I/O. Add an adapter to the remote I/O LINK network. RACK Rack overlap on remote I/O. Reconfigure remote I/O racks.
-
Page 24: Status Indicators
24 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Status Indicators Three status indicators on the module provide information about your module and the status of each channel. The following tables outline the indicator condition and the corresponding status, and explain what each condition means. OK Status Indicator State Description... - Page 25 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 25 Channel A and B Indicators State Channel Mode Description Recommended Actions Not on line. Place channel on line. Green RIO scanner Active RIO link. All None - this is normal adapter modules are operation.
-
Page 26: General Specifications - 1756-Dhrioxt
26 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module General Specifications - 1756-DHRIOXT Attribute Value Module location 1756 ControlLogix-XT chassis, any slot Backplane current 1.7 mA (mA) at 24V Backplane current 850 mA (mA) at 5V Power dissipation, max 4.5 W Thermal dissipation, max 15.4 BTU/hr... -
Page 27: Environmental Specifications - 1756-Dhrioxt
ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 27 Environmental Specifications - 1756-DHRIOXT Attribute Value Temperature, Operating -25…70 °C (-13…158 °F) IEC 60068-2-1 (Test Ad, Operating Cold), IEC 60068-2-2 (Test Bd, Operating Dry Heat), IEC 60068-2-14 (Test Nb, Operating Thermal Shock) Temperature, Nonoperating -40…85 °C (-40…185 °F) - Page 28 28 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module Attribute Value • 10V/m with 1 kHz Radiated RF Immunity sine-wave 80% AM from IEC 61000-4-3 80…2000 MHz • 10V/m with 200 Hz 50% Pulse 100% AM at 900 • 10V/m with 200 Hz 50% Pulse 100% AM at 1890 •...
-
Page 29: Certifications - 1756-Dhrioxt
ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 29 Certifications - 1756-DHRIOXT (1) (2) Certification Value c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584. UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations, certified for U.S. -
Page 30: Additional Resources
Product Certifications website, Provides declarations of conformity, http://www.ab.com certificates, and other certification details. You can view or download publications at http://literature.rockwellautomation.com. To order paper copies of technical documentation, contact your local Rockwell Automation distributor or sales representative. Publication 1756-IN638A-EN-P - March 2009... - Page 31 ControlLogix-XT Data Highway Plus-Remote I/O Interface Module 31 Notes: Publication 1756-IN638A-EN-P - March 2009...
- Page 32 New Product Satisfaction Return Rockwell Automation tests all of its products to ensure that they are fully operational when shipped from the manufacturing facility. However, if your product is not functioning and needs to be returned, follow these procedures.
