Specifications - Altronix AL400ULPD4 Installation Manual

These UL Listed multi-output power supply/chargers convert a 115VAC / 60Hz input, to a 12VDC or 24VDC
regulating output (see specifications below).
AL400ULPD Series Power Supply Configuration Reference Chart:
AL400ULPD4
AL400ULPD4CB
AL400ULPD8
AL400ULPD8CB
AL400ULXPD16
AL400ULXPD16CB
Do not exceed total output rating of 2.5 amp per unit.
Input:
• Input 115VAC / 60Hz, 1.45 amp.
• AC input and DC output LED indicators.
Output:
• Class 2 Rated power-limited output(s).
• 12VDC or 24VDC selectable output.
• 4 amp total supply current at 12VDC
or 3 amp total supply current at 24VDC.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
- 2 -
PD4UL 4 x -
PD4ULCB 4 - x
PD8UL 8 x -
PD8ULCB 8 - x
Two (2)
16 x -
PD8UL
Two (2)
16 - x
PD8ULCB
Overview:
3.5 3
2.5 2.5
3.5 3
2.5 2.5
3.5 3
2.5 2.5

Specifications:

Battery Backup (cont'd.):
• Automatic switch over to stand-by battery when
AC fails.
• Maximum charge current .7 amp.
• Zero voltage drop when switched over to battery backup.
Supervision:
• AC fail supervision (form "C" contacts).
• Low battery supervision (form "C" contacts).
• Battery presence supervision (form "C" contacts).
Additional Features:
• Power supply, enclosure, cam lock and battery leads.
• All models are available in red enclosure
(add an "R" suffix to the part # e.g. AL400ULPD8R).
UL File # S4707
UL 294 UL Listed for Access Control
System Units.
UL 603 UL Listed for Power Supplies for
Use with Burglar-Alarms Systems.
UL 1069 UL Listed Hospital Signaling and
Nurse Call Equipment.
UL 1481 UL Listed for Power Supplies for
Fire Protective Signaling Systems
"Signal Equipment" Evaluated to
CSA Standard C22.2
No.205-M1983
AL400ULPD series
