Task Setting
Connect the charger to the power supply and wait for the system to complete the self
testing. Connect the battery to the charger under standby interface, and short press the
shuttle key to make the task setting menu to pop up. The items in the menu are as follows:
Task
Battery type
Cells voltage
Cells count
Current setting
Start task
Back
09
End-voltage setting
Select task contents: Charge, Discharge, Storage
Select battery types
End-voltage slight adjustment, range ±0.05V
Select batteries'strings, and the item processes automatic test and needs
no setting if inserted in balanced interface
Select current, charge/storage 0.1 - 8.0A, discharge 0.1 - 3.0 A
Start to execute tasks
back
Recommended Voltage
