Working Parameters Display

Present current
Battery type – string number
Current task status
Cell voltage
Battgo smart battery
input information
Smart battery brand
Smart battery types&series
Smart battery capacity

Fast Charging

12
Task operation time Device Name
00:17:18 Q6 Pro
8.0
A
Charging
ISDT Battery
LiPo-4S
6800mAh
Sliding the touch panel during operation can switch the displayed information
in the lower half of the screen, which are cell voltage, cell internal resistance,
output information and working parameter.
The output information only shows while connecting a smart battery.
The cell voltage and internal resistance can only be displayed in the mode of
balance charging (3 minutes).
Battery percentage
97%
1.69
Ah
2018-03-20
26℃
Capacity charged
Smart battery
production date
Smart battery
operating temperature
