12. The three LEDs on the development board start blinking in sequence. If the LEDs do
not blink, start over from
13. Press the
pushbutton to change the sequence of the LEDs to blink in the opposite
TEST
direction.
For more information about using ZDS II and building projects for the Z8 Encore! XP
development kit, refer to the
(UM0130).
QS002810-0111
Z8FMC16100 Series Motor Control Development Kit
Figure 3. ZDS II Active Screen
Step 2 on page
9.
Zilog Developer Studio II – Z8 Encore! User Manual
Quick Start Guide
®
Page 11 of 12
