The 8xAA sled holds four AA batteries on the inside like the quad-AA sled (shown
i
above), and an additional four batteries under an outside cover that levers down-
ward (as shown below).
8 AA Sled Closed
3. Mount the battery sled in place on the back of the MixPre-3.
To mount L-Series batteries:
1. Press the release lever at one end of the battery sled to remove it from the
back panel.
2. Position the battery so the two terminals on the battery line up with the tips
of the two pins on one side of the sled.
3. Press the battery against the sled and slide the battery onto the pins. The
battery retainer tab will spring back to center, securing the battery.
Retainer Tab
Left Side of Sled
4. Repeat steps 2 and 3 to mount second battery to other side of sled.
5. Mount the battery sled in place on the back of the MixPre-3.
Release Levers
Pins
Release Levers
Release Lever
8 AA Sled Opened
L-Mount Battery
Right Side of Sled
POWER
