PT 6500 S / PT 15000 S
EN
ORIGINAL INSTRUCTIONS
AIR CONDITIONER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT 6500 S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trotec PT 6500 S

Summary of Contents for Trotec PT 6500 S

  • Page 1 PT 6500 S / PT 15000 S ORIGINAL INSTRUCTIONS AIR CONDITIONER...

  • Page 2: Table Of Contents

    Note This signal word indicates important information (e.g. material damage), but does not indicate hazards. Info Information marked with this symbol helps you to carry out your tasks quickly and safely. air conditioner PT 6500 S / PT 15000 S...

  • Page 3: Safety

    • Insert the mains plug into a properly secured mains Maintenance tasks which require the housing to be opened socket. must only be carried out by specialist companies for cooling and air-conditioning or by Trotec. air conditioner PT 6500 S / PT 15000 S...
  • Page 4 Do not leave the packaging lying around. Children may use it as a dangerous toy. Warning Risk of death due to suspended loads! Make sure that nobody is situated in the immediate proximity. air conditioner PT 6500 S / PT 15000 S...

  • Page 5: Information About The Device

    The "operating hours counter" option is already integrated in the control of PT 6500 S and PT 15000 S. As standard the PT 15000 S comes with an installed energy meter. For the PT 6500 S you can optionally order a dual counter. air conditioner PT 6500 S / PT 15000 S...
  • Page 6 (MID-compliant) optional earthing connection protective earth conductor vent valve for water circuit air conditioner PT 6500 S / PT 15000 S...
  • Page 7 (MID-compliant) earthing connection vent valve for water circuit adjustable spacer for device protection air conditioner PT 6500 S / PT 15000 S...

  • Page 8: Transport And Storage

    After transporting the device, observe the following: • Set up the device in an upright position after transport. • Apply and lock the brakes at the wheels again. air conditioner PT 6500 S / PT 15000 S...

  • Page 9: Assembly And Installation

    • with a cover to protect it from invasive dust if necessary • Place no further devices or objects on top of the device to prevent it from being damaged. air conditioner PT 6500 S / PT 15000 S...
  • Page 10 Please note, that to the front the external heat exchanger requires a minimum distance of 3 m to the wall or other objects. Towards the rear a spacer (8) fitted to the external heat exchanger of the PT 6500 S ensures a sufficient spacing. air conditioner PT 6500 S / PT 15000 S...
  • Page 11 This loss is compensated for with the liquid from the mixture. Therefore, a little liquid exits during coupling. compensation tank (5). This loss is compensated for with the liquid from the compensation tank (5). air conditioner PT 6500 S / PT 15000 S...
  • Page 12 Also check the glycol content (using an antifreeze tester). Note Only use monopropylene glycol and do not mix different types of glycol. The maximum glycol concentration amounts to 30 % (see technical data). air conditioner PT 6500 S / PT 15000 S...

  • Page 13: Operation

    The operating hours will be indicated on the display (23). SET + button To increase or reduce the target temperature for cooling. SET - button ON/OFF button Switches the device on or off. VENT. button To activate or deactivate ventilation mode. air conditioner PT 6500 S / PT 15000 S...

  • Page 14: Available Accessories

    After automatic defrosting the device keeps running for approx. 90 s for the purpose of air circulation – regardless of the ambient temperature and the desired room temperature. Afterwards the device resumes operation with the set values. air conditioner PT 6500 S / PT 15000 S...

  • Page 15: Errors And Faults

    • Check the temperature setting at the device. Reduce the set temperature if it is higher than the room temperature. • Also check the points listed under the error message HIPS. air conditioner PT 6500 S / PT 15000 S...
  • Page 16 • Disconnect the mains plug and plug it back in after 5 s to reset the cooling circuit between the basic alarm. device and the external unit. • Check whether there is sufficient water in the tank (5). air conditioner PT 6500 S / PT 15000 S...

  • Page 17: Maintenance

    Check the air filter for dirt and foreign objects and clean or replace if necessary Replace the air filter Check for damage Check the attachment screws Test run air conditioner PT 6500 S / PT 15000 S...
  • Page 18 12. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......13. Date: ......14. Date: ......15. Date: ......16. Date: ......Signature: ......Signature: ......Signature: ......Signature: ......air conditioner PT 6500 S / PT 15000 S...
  • Page 19 Do not use any aggressive cleaning If the pump is jammed, please contact an authorised specialist agents such as cleaning sprays, solvents, alcohol-based or company or Trotec. abrasive cleaners to dampen the cloth. air conditioner PT 6500 S / PT 15000 S...
  • Page 20 • The refrigerant circuit of the basic device is a maintenance-free, hermetically sealed system and may only be maintained or repaired by specialist companies for cooling and air-conditioning or by Trotec. air conditioner PT 6500 S / PT 15000 S...
  • Page 21 6. Allow the filter to dry completely. Do not insert a wet filter into the device! 7. Reinsert the air filter into the device. air conditioner PT 6500 S / PT 15000 S...

  • Page 22: Technical Annex

    B: rear: 30 cm C: side: 30 cm C: side: 30 cm D: front: 30 cm D: front: 30 cm Sound pressure level 59 dB(A) 65 dB(A) at a distance of 3 m (stage 1, basic device) air conditioner PT 6500 S / PT 15000 S...
  • Page 23 Circuit diagram air conditioner PT 6500 S / PT 15000 S...

  • Page 24: Disposal

    Trotec GmbH & Co. KG Grebbener Straße 7, D-52525 Heinsberg Phone: +49 2452 962-400 E-mail: info@trotec.de Place and date of issue: Heinsberg, 28.05.2018 Detlef von der Lieck, Managing Director air conditioner PT 6500 S / PT 15000 S...
  • Page 26 Trotec GmbH & Co. KG Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
