Operating Instructions
SG 310/330 Rev. 2

LED Status

Power (LED Display)
Power Supply Acitve Green
Power Supply Failure Red
SSD Active Blue
LEDs on each RJ45 Ethernet connector
ACT/LNK Green Constantly
(Left LED)
Flashing
Off
Speed Amber On
(Right LED)
Green On
Off
LEDs on each SFP connector
ACT/LNK Green Constantly
Flashing
Off
LEDs on each SFP+ connector
ACT/LINK Green Constantly
(Left LED)
Flashing
Off
ACT/LINK Blue On
(Right LED)
Amber On
Off
LAN Bypass (LED Display)
LAN Bypass Active
Green
LAN Bypass Off Off
Back side
Power Supply Green
Constantly
Off
1. The Ethernet port is receiving power.
2. Good connection between the Ethernet port and hub.
The adapter is sending or receiving network data. The
frequency of the flashes varies with the amount of traffic.
1. The adapter and switch are not receiving power.
2. No connection between both ends of network.
3. Network drivers have not been loaded
or do not function correctly.
The Ethernet port is operating at 1,000 Mbps.
The Ethernet port is operating at 100 Mbps.
The Ethernet port is operating at 10 Mbps.
1. The SFP connector is receiving power.
2. Good linkage between the SFP connector and hub.
The adapter is sending or receiving network data. The
frequency of the flashes varies with the amount of traffic.
1. The adapter and switch are not receiving power.
2. No connection between both ends of network.
3. Network drivers have not been loaded
or do not function correctly.
1. The SFP+ connector is receiving power.
2. Good linkage between the SFP+ connector and hub.
The adapter is sending or receiving network data. The
frequency of the flashes varies with the amount of traffic.
1. The adapter and switch are not receiving power.
2. No connection between both ends of network.
3. Network drivers have not been loaded
or do not function correctly.
The SFP+ connector is operating at 10,000 Mbps.
The SFP+ connector is operating at 1,000 Mbps.
Either the LED is not working or the SFP+ connector
is operating at a speed below 1,000 Mbps.
Power
No power
3
