Sony MKS-8010A Operation Manual

Ccp-8000 center control panel pack.
Hide thumbs

Advertisement

CENTER CONTROL PANEL PACK
CCP-8000
MKS-8010A
MKS-8015A
MKS-8020A
MKS-8022ASC
MKS-8025MS
MKS-8030A
MKS-8033A
MKS-8036A
MKS-8075A
OPERATION MANUAL
2nd Edition (Revised 3)
MKS-8011A
MKS-8017A
MKS-8021A
MKS-8023A
MKS-8026A
MKS-8031AJS
MKS-8034ADK
MKS-8040
MKS-8076
MKS-8013A
MKS-8018A
MKS-8021ASC
MKS-8023AB
MKS-8027A
MKS-8031ATB
MKS-8034AFB
MKS-8041
HK-PSU02
[English]
MKS-8014A
MKS-8019A
MKS-8022A
MKS-8024A
MKS-8028A
MKS-8032A
MKS-8035A
MKS-8042

Advertisement

Table of Contents

   Related Manuals for Sony MKS-8010A

   Summary of Contents for Sony MKS-8010A

  • Page 1 CENTER CONTROL PANEL PACK CCP-8000 MKS-8010A MKS-8011A MKS-8013A MKS-8014A MKS-8015A MKS-8017A MKS-8018A MKS-8019A MKS-8020A MKS-8021A MKS-8021ASC MKS-8022A MKS-8022ASC MKS-8023A MKS-8023AB MKS-8024A MKS-8025MS MKS-8026A MKS-8027A MKS-8028A MKS-8030A MKS-8031AJS MKS-8031ATB MKS-8032A MKS-8033A MKS-8034ADK MKS-8034AFB MKS-8035A MKS-8036A MKS-8040 MKS-8041 MKS-8042 MKS-8075A MKS-8076 HK-PSU02...
  • Page 2 WARNING: THIS WARNING IS APPLICABLE FOR USA WARNING ONLY. If used in USA, use the UL LISTED power cord specified To reduce the risk of fire or electric shock, below. DO NOT USE ANY OTHER POWER CORD. do not expose this apparatus to rain or moisture.
  • Page 3 CET APPAREIL DOIT ÊTRE RELIÉ À LA TERRE. Für Kunden in Europa (nur MKS-8011A/8013A/8014A/ 8015A/8017A/8018A/8019A/8020A/8021A/8021ASC/ 8022A/8022ASC/8023A/8023AB/8024A/8025MS/8026A/ For the customers in Europe (MKS-8010A only) 8027A/8028A/8030A/8031AJS/8031ATB/8032A/8033A/ This product with the CE marking complies with both the EMC 8034ADK/8034AFB/8035A/8036A/8040/8041/8075A/8076) Directive (89/336/EEC) and the Low Voltage Directive (73/23/ Dieses Produkt besitzt die CE-Kennzeichnung und erfüllt die...
  • Page 4 Für Kunden in Europa (nur HK-PSU02) Dieses Produkt besitzt die CE-Kennzeichnung und erfüllt die EMV-Richtlinie (89/336/EWG) der EG-Kommission. Angewandte Normen: For the State of California, USA only (MKS-8010A only) • EN55103-1: Elektromagnetische Verträglichkeit Perchlorate Material - special handling may apply, See (Störaussendung) www.dtsc.ca.gov/hazardouswaste/perchlorate...
  • Page 5: Table Of Contents

    Overview ................7 Features..................7 Units and Modules ..............7 Optional Accessories ..............9 Location and Function of Parts......... 10 MKS-8010A Front Panel ............10 MKS-8010A Rear Panel ............11 MKS-8011A Menu Panel ............13 Main Panel ................13 AUX Panel................14 MKS-8025MS “Memory Stick”/USB Module.......
  • Page 6 MKS-8018A 24 XPT Module ..........25 MKS-8019A 16 XPT Module ..........25 MKS-8020A Standard Transition Module ......25 MKS-8021A Simple Transition Right Module .......25 MKS-8021ASC Simple Transition Compact Right Module ...25 MKS-8022A Simple Transition Left Module......25 MKS-8022ASC Simple Transition Compact Left Module ..26 MKS-8023A Compact Key Transition Module ......
  • Page 7: Overview

    Powerful external device control editing systems. The center control panel can control devices such as Sony “Center control panel” refers to the control panel as a routing switchers and IF processors. Control of devices whole, which is comprised of the following three elements.
  • Page 8 MKS-8018A 24 XPT Module MKS-8023AB Compact Key Transition Module An M/E or PGM/PST bank cross-point module with 24 cross-point buttons. A key transition operation module for 2/4-keyer transitions. Used in combination with the MKS-8021A/ 8021ASC/8022A/8022ASC. MKS-8019A 16 XPT Module An M/E or PGM/PST bank cross-point module with 16 MKS-8024A Flexi Pad Module cross-point buttons.
  • Page 9: Optional Accessories

    HK-PSU02 Power Supply Unit (on MKS- 8010A) A backup power supply unit. The MKS-8010A is supplied standard with one power unit. Installing an HK-PSU02 gives two power units. This allows a backup system to be constructed which will operate normally even if one of the power supply units fails.
  • Page 10: Location And Function Of Parts

    POWER B switch indicator. Caution Before installing an optional Backup Power Supply Unit in your unit, be sure to contact your Sony service representative. Note If a status indicator does not light when you turn a POWER switch on, there may be a fault in the power circuits.
  • Page 11: Mks-8010a Rear Panel

    MKS-8010A Rear Panel qgMENU PANEL connector qsMAIN PANEL connector 6-AC IN A and B connectors 3EXT PANEL 1 to 3 connectors AC IN MENU PANEL EXT PANEL1 EXT PANEL2 EXT PANEL3 MAIN PANEL EXT DISPLAY DATA DEVICE EDITOR PANEL REF IN...
  • Page 12 CTRL (control) connector (RJ-45) Caution Connect to an Ethernet switch. For information about installing, contact your Sony The MVS-8000A/8000ASF Switcher Processor, the service representative. MVE-8000A DME Processor and other devices are connected in the same way to the Ethernet switch to form g U (signal ground) terminal a network for exchange of signals between the devices.
  • Page 13: Mks-8011a Menu Panel

    Connect to the MAIN PANEL connector of the MKS- 8010A System Control Unit. b HOST connector (USB Type B) Connect to the DEVICE connector of the MKS-8010A System Control Unit. c DEVICE connectors (USB Type A) Connect to external devices with USB connectors.
  • Page 14: Aux Panel

    Connect to one of the EXT PANEL 1 to 3 connectors of the MKS-8010A System Control Unit. For connectable devices, contact your Sony service representative. b HOST connector (USB Type B) Connect to the DEVICE connector of the MKS-8010A System Control Unit. MKS-8025MS “Memory Stick”/USB Module 1Status indicator 2“Memory Stick” slot...
  • Page 15: Mks-8075a Extension Adaptor

    (D-sub 50-pin, special interface) Connect to one of the EXT PANEL 1 to 3 connectors of the Connect to the SCU IN connector of the MKS-8075A. MKS-8010A System Control Unit or to the SCU OUT connector of the MKS-8075A. MKS-8076 Memory Card/USB Adaptor...
  • Page 16: Example System Configuration

    Example System Configuration MVS-8000A System Configuration MVE-8000A DME Processor Reference video signal DATA CTRL Ethernet switch Ethernet switch MKS-8010A System Control Unit CTRL PERIPH REMOTE DATA DATA CTRL Reference video signal EDITOR PANEL BKS-R Series MVS-8000ASF Switcher Processor Reference HDS-X Series...
  • Page 17: Center Control Panel Connection

    USB Module. •To install it in the main panel, connect the DEVICE connector on the MKS-8010A and the HOST connector on the main panel. •To install it on the AUX panel, connect the DEVICE connector on the MKS-8010A and the HOST connector on the AUX panel.
  • Page 18: Exchanging Button Labels

    The number of modules that can be connected to a single Exchanging Button MKS-8010A System Control Unit is as follows. (The maximum number of adaptors that can be connected Labels on 1 channel is 8.) Model Module name Max. modules...
  • Page 19: Adjusting Fader Torque

    To make adjustment, it is necessary to use the two holes provided in the back side of the module. If you want split fader torque to be adjusted, consult your Sony service representative. Single fader modules MKS-8020A Standard Transition Module MKS-8030A Key Frame Module...
  • Page 20: Care Of The Control Panel

    Care of the Control Panel About a “Memory Stick” Clean the control panel unit, switches, and fader levers, by What Is “Memory Stick”? gently wiping with a soft dry cloth. In the event of excessive grime, moisten the cloth with a “Memory Stick”...
  • Page 21: Available Types Of "memory Stick

    • “Memory Stick” (with memory select Before Using a “Memory Stick” function) Equipped with the multiple memories (128 MB). You can select the memory to use with the memory selects switch Terminal on the back of the “Memory Stick.” You cannot use different memories simultaneously or continuously.
  • Page 22: Caution When Formatting "memory Stick" On A Personal Computer

    Operation Manual (1) • To prevent data loss, make backups of data frequently. In Installation Manual (1) no event will Sony be liable for any loss of data. User’s Guide (2) • Unauthorized recording may be contrary to the Software License Agreement (1) ∗...
  • Page 23: Aux Panel

    USB Type A (2) E): 1291×98×528 mm Maximum supply current 400 mA ×3 ×20 inches) Example 6: (24 crosspoint buttons, 3 M/ MKS-8010A System Control Unit E): 1071×98×528 mm ×3 ×20 inches) Example 7: (24 crosspoint buttons, 2 M/ General E): 1291×92×396 mm...
  • Page 24: Mks-8011a Menu Panel

    Reference input MKS-8011A Menu Panel REF IN BNC type, 75Ω, with loop-through output General HDTV systems: HD tri-level sync/SDTV analog black Power requirements burst/SDTV analog sync 12 V DC SDTV systems: Power consumption Analog black burst/analog sync Max. 1 A Dimensions (w/h/d, excluding projections) 424×46×220 mm Control connectors...
  • Page 25: Mks-8017a 32 Xpt Module

    Dimensions (w/d, excluding projections) Power consumption 436×132 mm (17 ×5 inches) Max. 1 A Mass Approx. 1.2 kg (2 lb 10 oz) Dimensions (w/d, excluding projections) Accessories supplied 293×132 mm (11 ×5 inches) Operation and Installation Guide (1) Mass Approx. 0.9 kg (1 lb 15 oz) (supplied only when product is Accessories supplied purchased separately)
  • Page 26: Mks-8022asc Simple Transition Compact Left Module

    Accessories supplied MKS-8022ASC Simple Transition Operation and Installation Guide (1) Compact Left Module (supplied only when product is purchased separately) Power requirements 12 V DC MKS-8025MS “Memory Stick”/USB Power consumption Module Max. 1 A Dimensions (w/d, excluding projections) 220×132 mm (8 ×5 inches) General...
  • Page 27: Mks-8028a Compact Transition Left Module

    Operation and Installation Guide (1) Mass Approx. 0.7 kg (1 lb 8 oz) (supplied only when product is Accessories supplied purchased separately) Operation and Installation Guide (1) (supplied only when product is purchased separately) MKS-8028A Compact Transition Left Module MKS-8032A DSK Fader Module Power requirements Power requirements 12 V DC...
  • Page 28: Mks-8035a Key Control Module

    147×132 mm (5 ×5 inches) Dimensions (w/d, excluding projections) Mass Approx. 0.3 kg (10 oz) 220×132 mm (8 ×5 inches) Accessories supplied Mass Approx. 0.4 kg (14 oz) Operation and Installation Guide (1) Accessories supplied (supplied only when product is Operation and Installation Guide (1) purchased separately) (supplied only when product is...
  • Page 29: Mks-8076 Memory Card/usb Adaptor

    MKS-8076 Memory Card/USB Adaptor General Power requirements 5 V DC Power consumption Max. 1A Dimensions (w/h/d, excluding projections) 263×79×132 mm ×3 ×5 inches) Mass Approx. 0.6 kg (1 lb 5 oz) Control connectors HOST USB Type B Accessories supplied Connecting panel A (2) Connecting panel B (1) Connecting panel C (1) Panel cover (L) (1)
  • Page 30 Specifications...
  • Page 31 The material contained in this manual consists of information that is the property of Sony Corporation and is intended solely for use by the purchasers of the equipment described in this manual. Sony Corporation expressly prohibits the duplication of any...
  • Page 32 Sony Corporation CCP-8000 Printed in Japan (WW) 2007.12.13 3-206-011-14 (1) © 2001 Printed on recycled paper...
