7 RS-485 Communication Features
This section in the user manual explains how to control the inverter with a PLC or a
computer over a long distance using the RS-485 communication features. To use the RS-
485 communication features, connect the communication cables and set the
communication parameters on the inverter. Refer to the communication protocols and
parameters to configure and use the RS-485 communication features.

7.1 Communication Standards

Following the RS-485 communication standards, S100 products exchange data with a PLC
and computer. The RS-485 communication standards support the Multi-drop Link System
and offer an interface that is strongly resistant to noise. Please refer to the following table for
details about the communication standards.
Item
Communication
method/ Transmission
type
Inverter type name
Number of connected
inverters/ Transmission
distance
Recommended cable
size
Installation type
Power supply
Communication speed 1,200/2,400/9,600/19,200/38,400/57,600/115,200 bps
Control procedure
Communication system Half duplex system
Character system
Stop bit length
Frame error check
Parity check
RS-485/Bus type, Multi-drop Link System
S100
Maximum of 16 inverters / Maximum1,200m (recommended distance:
within 700m)
0.75mm², (18AWG), Shielded Type Twisted-Pair (STP) Wire
Dedicated terminals (S+/S-/SG) on the control terminal block
Supplied by the inverter - insulated power source from the inverter's
internal circuit
Asynchronous communications system
Modbus-RTU: Binary / LS Bus: ASCII
1-bit/2-bit
2 bytes
None/Even/Odd
RS-485 Communication Features
