Inverter Diagnosis State

Check the diagnosis of components or devices for inverter to check if they need to be
replaced.
Group Code Name
CAP, FAN
Pr 89 replacement
warning

Operation Mode on Option Card Trip

Option card trips may occur when an option card is used with the inverter. Set the operation
mode for the inverter when a communication error occurs between the option card and the
inverter body, or when the option card is detached during operation.
Group Code
Operation mode on
Pr 80
option card trip
Operation Mode on Option Trip Setting Details
Code
Pr.80 Opt Trip
Mode
LCD Display
Inverter State
Name LCD Display
Opt Trip Mode
Setting
0 None
1 Free-Run
2 Dec
Learning Protection Features
Parameter
Setting Range
Setting
Bit 00-10
00 -
00
01 CAP Warning
10 FAN Warning
Parameter
Setting
0 None
1 Free-Run
2 Dec
Description
Function
No operation
The inverter output is blocked and fault trip
information is shown on the keypad.
The motor decelerates to the value set at Pr.07
(Trip Dec Time).
Unit
Bit
Setting range Unit
0-3 -
