Specifications; Troubleshooting; Disposal - Qtx QTFX-2000 mkII User Manual

Specifications

Power supply
Fuse
Heating element
Reheat time
Fog output (approx.)
Tank capacity
Remote control
Remote cable length
RF Remote frequency
DMX connection
DMX channels
Dimensions
Weight

Troubleshooting

Warning: Hot components! ... Switch off and allow to cool before touching the unit.
No light on mains
switch
Ready light stays off
Ready light is on but
no fog output on
manual or
continuous
No fog output on
timer function
No response to DMX
Disposal: The "Crossed Wheelie Bin" symbol on the product means that the product is classed as Electrical or
Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful
life. The goods must be disposed of according to your local council guidelines
230Vac, 50Hz (IEC)
F10A (5 x 20mm)
2000W
8 to 10 mins (approx.)
40,000 Cu Ft (1133m³)/ min
5l
Wireless remote, wired timer remote, DMX512
5m
433MHz
3-pin XLR in/out (1-channel)
Single channel – 0=No output, 1-255=full output
670 x 350 x 260mm
10kg
Check mains voltage is correct and socket is switched on
Check IEC lead is OK and connected properly
Check mains fuse in IEC connector and fuse in plug top
If fuse blowing repeatedly, refer to qualified service personnel
Check remote is connected properly
If light is permanently off, refer to qualified service personnel
Check fog fluid level
If fluid is OK and pump working, the lines may be blocked
Check that nozzle is not blocked or obstructed
If blocked, clean with fog machine cleaner & distilled water
Ensure timer button is pressed in and timer LED is lit
Check interval, duration and output control settings – test manually if necessary
Check that XLR leads are connected properly
Check that DMX signal is OK by testing on other equipment
Check that the DIP switch settings are set to the correct address
Ensure that the other remote controls are not overriding DMX
Errors and omissions excepted.
Copyright© 2014. AVSL Group Ltd.
160.473UK User Manual
