- Page 1 IOPS-302 Open Pluggable Specification Digital Signage Player User’s Manual Version 1.0 (May 2018)
- Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).
-
Page 3: Compliance
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) IOPS-302 User Manual... -
Page 4: Important Safety Information
Do not try to repair, disassemble, or make modifications to the device. Doing so will void the warranty and may result in damage to the product or personal injury. CAUTION Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries by observing local regulations. IOPS-302 User Manual... -
Page 5: Warranty Policy
The arrangement of the peripherals • Software used (such as OS and application software) 3. If repair service is required, please download the RMA form at http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and contact your distributor or sales representative. IOPS-302 User Manual... -
Page 6: Table Of Contents
Clearing CMOS Data (JP2) ..........14 2.5.3 System Fan Power Connector (SYS_FAN1) ......15 Chapter 3 Driver Installation ..............16 Introduction ................... 17 AMD Merlin Falcon Graphics Driver Installation ........17 HD Audio Driver Installation ..............18 LAN Driver Installation ................19 IOPS-302 User Manual... - Page 7 4.5.2 North Bridge ................32 Security Settings ................... 33 Boot Settings..................34 Save & Exit Settings................35 Appendix ...................... 36 I/O Port Address Map ................37 Interrupt Request Lines (IRQ) ............... 40 Watchdog Timer Configuration .............. 41 IOPS-302 User Manual...
-
Page 8: Chapter 1 General Information
Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Specifications • Optional Accessories • Overview • Dimensions... -
Page 9: Introduction
1.1 Introduction The IOPS-302 is a slot-in digital signage player compliant with OPS (Open Pluggable Specification). It is powered by AMD 3 Generation R & G series processors, supports HDMI high definition video playback, and provides outstanding performance. It is fully compatible with large format OPS displays and monitors and allows cableless deployment and easy maintenance. -
Page 10: Specifications
AMD R & G -Series 28 nm QC / DC APU FP4 BGA package, 37 x 29 mm, 0.8 mm pitch Chipset AMD integrated SoC IOPS-302: 2 x DDR4-2133 SO-DIMM, dual channel, Max. 32GB Memory IOPS-302-N224: 1 x DDR4-2133 SO-DIMM, single channel, Max. 16GB Graphics Next-gen. -
Page 11: Overview
RJ50 COM RS-232 Port (for the optional docking kit) Audio Jacks HDMI Port (From left to right: Line-Out, Mic-In) GbE LAN Port Antenna Holes USB 3.0 Power Button LED Indicators USB 2.0 (From left to right: for power, for HDD) IOPS-302 User Manual... -
Page 12: Dimensions
General Information 1.7 Dimensions Unit: mm IOPS-302 User Manual... -
Page 13: Chapter 2 Hardware Configuration
Chapter 2 Hardware Configuration This section contains general information about: • Installations • Jumper and connectors... -
Page 14: Installations
To remove a module, use your fingers to press the clips outwards until the module pops up. Grab the module gently and pull it out of the slot. IOPS-302 User Manual... -
Page 15: Cards Installation
1. Fasten the hex nut and the washer. Then 2. Apply adhesive around here. install the antenna. Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC). IOPS-302 User Manual... -
Page 16: Pin Assignment For Com Rs-232 Port
2.2 Pin Assignment for COM RS-232 Port (RJ50 connector) Signal Name Signal Name DSR (Data set ready) DCD (Data carrier detect) Ground DTR (Data terminal ready) Ground CTS (Clear to send) TX (Transmit) RTS (Request to send) RX (Receive) RI (Ring indicator) IOPS-302 User Manual... -
Page 17: Setting The Jumpers
1 2 3 When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e. turned On. When a jumper cap is removed from two jumper pins, this jumper is open, i.e. turned Off. IOPS-302 User Manual... -
Page 18: Jumper & Connector Locations On Motherboard
Hardware Configuration 2.4 Jumper & Connector Locations on Motherboard Motherboard: OPS302 OPS302 – top view IOPS-302 User Manual... - Page 19 OPS302 – bottom view IOPS-302 User Manual...
-
Page 20: Jumper & Connectors Quick Reference
DDR4 Memory Slot J3, J6 M.2 E2230 Slot M.2 M2280 Slot LED Indicator LED1 (for power), LED2 (for HDD) Battery Socket BAT1 Factory Use Only J1, J4, J5 [1]: Refer to 2.2 Pin Assignment for COM RS-232 Port. IOPS-302 User Manual... -
Page 21: Atx & At Mode Selection (Jp1)
2.5.1 ATX & AT Mode Selection (JP1) Function Pin closed Illustration ATX Mode (default) AT Mode 2.5.2 Clearing CMOS Data (JP2) Function Pin closed Illustration Normal (default) Clear CMOS IOPS-302 User Manual... -
Page 22: System Fan Power Connector (Sys_Fan1)
Hardware Configuration 2.5.3 System Fan Power Connector (SYS_FAN1) Signal Name Signal Name Ground Rotation detection +12V IOPS-302 User Manual... -
Page 23: Chapter 3 Driver Installation
Chapter 3 Driver Installation The information provided in this chapter includes: • AMD Merlin Falcon Graphics Drivers • HD Audio Drivers • LAN Network Drivers... -
Page 24: Introduction
3.2 AMD Merlin Falcon Graphics Driver Installation 1. Run the Setup.exe file to start the installer. 2. Tick the desired items and click Install. 3. When the installation is complete, restart the system for changes to take effect. IOPS-302 User Manual... -
Page 25: Hd Audio Driver Installation
1. Run the Setup.exe file and the wizard will start. 2. On the Welcome screen of the InstallShield Wizard, click Next to start installing the audio driver on your system. 3. When installation is complete, restart the system for changes to take effect. IOPS-302 User Manual... -
Page 26: Lan Driver Installation
3.4 LAN Driver Installation 1. Run the Setup.exe file. 2. On the Welcome screen of the InstallShield Wizard, click Next to continue. 3. Click Install. 4. Installation is now complete. Restart the system for changes to take effect. IOPS-302 User Manual... -
Page 27: Chapter 4 Bios Setup
Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: • Main Settings • Advanced Settings • Chipset Settings • Security Settings •... -
Page 28: Introduction
These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. IOPS-302 User Manual... -
Page 29: Main Settings
4.3 Main Settings BIOS Setting Description System Date Sets the date. Use the <Tab> key to switch between the data elements. System Time Set the time. Use the <Tab> key to switch between the data elements. IOPS-302 User Manual... -
Page 30: Advanced Settings
(OS/S4 Sleep State). This option may be not effective with some OS. ACPI Sleep State Selects the highest SCPI sleep state the system will enter when the SUSPEND button is pressed. Options: Suspend Disabled, S3 (Suspend to RAM) IOPS-302 User Manual... -
Page 31: Ide Configuration
F81846 Super IO Configuration BIOS Setting Description Serial Port Configuration Sets parameters of Serial Ports (COMA). Enables / Disables the serial port and select an optimal setting for the Super IO device. Power Failure Options: Always on, Always off IOPS-302 User Manual... - Page 32 IO = 2F8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 • IO = 3E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 • IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 IOPS-302 User Manual...
- Page 33 IO = 2F8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 • IO = 3E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 • IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 IOPS-302 User Manual...
-
Page 34: Hardware Monitor
The values are read-only values as monitored by the system and show the PC health status. CPU Shutdown This field enables or disables the Shutdown Temperature Temperature Options: Disabled, 70°C, 75°C, 80°C, 85°C, 90°C, 95°C IOPS-302 User Manual... -
Page 35: Cpu Configuration
4.4.5 CPU Configuration BIOS Setting Description Node 0 Information When the function is enabled,a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. IOPS-302 User Manual... -
Page 36: Csm Configuration
Video Controls the execution of UEFI and Legacy Video OpROM. Options: Do not launch, UEFI, Legacy Other PCI devices Determines OpROM execution policy for devices other than network, storage or video. Options: Do not launch, UEFI, Legacy IOPS-302 User Manual... -
Page 37: Usb Configuration
The maximum time the device will take before it properly reports itself to the Host Controller. “Auto” uses default value for a Root port it is 100ms. But for a Hub port, the delay is taken from Hub descriptor. IOPS-302 User Manual... -
Page 38: Chipset Settings
BIOS Setup 4.5 Chipset Settings BIOS Setting Description South Bridge System Agent parameters North Bridge North Agent parameters 4.5.1 SB SATA Configuration IOPS-302 User Manual... -
Page 39: North Bridge
BIOS Setting Description OnChip SATA Channel Enables / Disables the Serial ATA. OnChip SATA Type Options: Native IDE, AHCI 4.5.2 North Bridge IOPS-302 User Manual... -
Page 40: Security Settings
BIOS Setup 4.6 Security Settings BIOS Setting Description Administrator Password Sets an administrator password for the setup utility. User Password Sets a user password. IOPS-302 User Manual... -
Page 41: Boot Settings
Bootup NumLock State Selects the keyboard NumLock state. Quiet Boot Enables / Disables Quiet Boot option. Boot Mode Select Selects a Boot mode. Boot Option Priorities Sets the system boot order priorities for hard disk, CD/DVD, USB, Network. IOPS-302 User Manual... -
Page 42: Save & Exit Settings
Restore Defaults Restores / Loads defaults values for all the setup options. Save as User Defaults Saves the changes done so far as user defaults. Restores the user defaults to all the setup Restore User Defaults options. IOPS-302 User Manual... -
Page 43: Appendix
Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. • I/O Port Address Map • Interrupt Request Lines (IRQ) • Watchdog Timer Configuration... -
Page 44: I/O Port Address Map
0x0000F100-0x0000F10F AMD SATA Controller 0x00000020-0x00000021 Programmable interrupt controller 0x000000A0-0x000000A1 Programmable interrupt controller 0x000003E0-0x00000CF7 PCI Express Root Complex 0x000003B0-0x000003DF PCI Express Root Complex 0x000003B0-0x000003DF AMD Radeon R7 Graphics 0x00000D00-0x0000FFFF PCI Express Root Complex 0x0000F000-0x0000F0FF AMD Radeon R7 Graphics IOPS-302 User Manual... - Page 45 Motherboard resources 0x0000040B-0x0000040B Motherboard resources 0x000004D6-0x000004D6 Motherboard resources 0x00000C00-0x00000C01 Motherboard resources 0x00000C14-0x00000C14 Motherboard resources 0x00000C50-0x00000C51 Motherboard resources 0x00000C52-0x00000C52 Motherboard resources 0x00000C6C-0x00000C6C Motherboard resources 0x00000C6F-0x00000C6F Motherboard resources 0x00000CD0-0x00000CD1 Motherboard resources 0x00000CD2-0x00000CD3 Motherboard resources 0x00000CD4-0x00000CD5 Motherboard resources 0x00000CD6-0x00000CD7 Motherboard resources IOPS-302 User Manual...
- Page 46 Appendix Address Device Description 0x00000CD8-0x00000CDF Motherboard resources 0x00000800-0x0000089F Motherboard resources 0x00000B00-0x00000B0F Motherboard resources 0x00000B20-0x00000B3F Motherboard resources 0x00000900-0x0000090F Motherboard resources 0x00000910-0x0000091F Motherboard resources 0x0000FE00-0x0000FEFE Motherboard resources 0x00000061-0x00000061 System speaker IOPS-302 User Manual...
-
Page 47: Interrupt Request Lines (Irq)
AMD USB 3.0 eXtensible Host Controller - 1.0 (Microsoft) IRQ 4294967290 Realtek PCIe GBE Family Controller IRQ 4294967291 AMD Radeon R7 Graphics IRQ 4294967292 AMD PSP 2.0 Device IRQ 4294967293 AMD PSP 2.0 Device IRQ 4294967294 PCI Express Root Port IOPS-302 User Manual... -
Page 48: Watchdog Timer Configuration
Fintek 81846, program abort.\n"); return(1); }//if (SIO == 0) if (argc != 2) printf(" Parameter incorrect!!\n"); return (1); bTime = strtol (argv[1], endptr, 10); printf("System will reset after %d seconds\n", bTime); if (bTime) EnableWDT(bTime); } else DisableWDT(); } return 0; IOPS-302 User Manual... - Page 49 //--------------------------------------------------------------------------- void DisableWDT(void) unsigned char bBuf; Set_F81846_LD(0x07); //switch to logic device 7 bBuf = Get_F81846_Reg(0xFA); bBuf &= ~0x01; Set_F81846_Reg(0xFA, bBuf); //disable WDTO output bBuf = Get_F81846_Reg(0xF5); bBuf &= ~0x20; bBuf |= 0x40; Set_F81846_Reg(0xF5, bBuf); //disable WDT //--------------------------------------------------------------------------- IOPS-302 User Manual...
- Page 50 Init_Finish; } F81846_BASE = 0x00; result = F81846_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_F81846 (void) outportb(F81846_INDEX_PORT, F81846_UNLOCK); outportb(F81846_INDEX_PORT, F81846_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81846 (void) outportb(F81846_INDEX_PORT, F81846_LOCK); //--------------------------------------------------------------------------- void Set_F81846_LD( unsigned char LD) Unlock_F81846(); outportb(F81846_INDEX_PORT, F81846_REG_LD); outportb(F81846_DATA_PORT, LD); Lock_F81846(); IOPS-302 User Manual...
- Page 51 //--------------------------------------------------------------------------- #defineF81846_INDEX_PORT (F81846_BASE) #defineF81846_DATA_PORT (F81846_BASE+1) //--------------------------------------------------------------------------- #defineF81846_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81846_UNLOCK 0x87 #defineF81846_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81846(void); void Set_F81846_LD( unsigned char); void Set_F81846_Reg( unsigned char, unsigned char); unsigned char Get_F81846_Reg( unsigned char); //--------------------------------------------------------------------------- #endif // F81846_H IOPS-302 User Manual...
