  • Page 1 SI-111-N Intel® Atom® x6000 Fanless Signage Player User’s Manual Version 1.0 (May 2023)
  • Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).
  • Page 3 0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) SI-111-N User Manual...
  • Page 4 Avoid Disassembly Do not disassemble, repair or make any modification to the device. Doing so could generate hazards and cause damage to the device, even bodily injury or property damage, and will void any warranty. SI-111-N User Manual...
  • Page 5 Software in use (such as OS and application software, including the version numbers) 3. If repair service is required, you can download the RMA form at http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and contact the distributor or sales representative. SI-111-N User Manual...

  • Page 6: Table Of Contents

    Chapter 1 General Information ............1 Introduction ..................... 2 Features ....................2 Packing List .................... 3 SI-111-N Specifications ................3 Product View ................... 5 Dimensions ..................... 6 Chapter 2 Hardware Installation & Motherboard Information ....7 Installation / Replacement ............... 8 Switches &...

  • Page 7: Chapter 1 General Information

    Chapter 1 General Information The information provided in this chapter includes: Features • Packing List • Specifications • Product View • Dimensions •...

  • Page 8: Introduction

    1.1 Introduction The SI-111-N is a palm-sized fanless 4K digital signage player system based on the Intel® Atom® x6211E and Celeron® N6210 processors. Equipped with an HDMI 2.0b port that supports 3840 x 2160 @60Hz resolution, the industrial-grade system enables businesses to easily connect to a 4K display and create immersive visual experiences that attract attention and effectively promote their products or services.

  • Page 9: Packing List

    1.3 Packing List The product package should include the items listed below. If any of the items below is missing, contact the distributor or the dealer from whom you purchased the product. SI-111-N Digital Signage Player • Power Adaptor •...
  • Page 10 Mounting Standard system bracket Dimensions 181mm(W) x 123mm(D) x 21.5mm(H) Certificate CE, FCC class B, UL, CCC Environment Operating -10°C ~ 50°C (14°F~122°F) for SI-111-N Temperature -20°C ~ 70°C (-4°F~158°F) for SI-111-N11E Storage -40°C~80°C (-40°F~176°F) Temperature Relative 10%~90% (non-condensing) Humidity...

  • Page 11: Product View

    General Information 1.5 Product View Front View Name Function Power Button HDMI Connector CN4, CN5, CN6 USB3.1 Connector COM1 RS-232 LAN Connector Audio Line-In Connector Audio Line-Out Connector Oblique View SI-111-N User Manual...

  • Page 12: Dimensions

    1.6 Dimensions Unit: mm SI-111-N User Manual...

  • Page 13: Hardware Installation & Motherboard Information

    Chapter 2 Hardware Installation & Motherboard Information The information provided in this chapter includes: Removing the brackets and system cover • Installation of memory modules and M.2 cards • Switches and connectors information •...

  • Page 14: Installation / Replacement

    2.1 Installation / Replacement 2.1.1 Removing the Brackets and Cover The SI-111-N is provided with the two brackets installed as shown in the picture below. To access the internal components, turn the unit upside down and remove the two brackets by removing the four (4) screws as shown below.
  • Page 15 Hardware Configuration Unscrew the six (6) screws shown in the picture below to remove the bottom cover. SI-111-N User Manual...
  • Page 16 3. To remove the module, press the ejector tabs outwards with your fingertips. 4. The second memory slot, J3, can be found on the other side (top) of the board. Repeat the previous steps to install/replace a memory module. SI-111-N User Manual...
  • Page 17 1. To install a card, locate the M.2 card slot. Align the key of the M.2 card to the M.2 interface, and insert the card slantwise. 2. Push the M.2 card down, and fix it onto the standoff with a screw. SI-111-N User Manual...

  • Page 18: Switches & Connectors On The Motherboard

    2.2 Switches & Connectors on the Motherboard MBD111 – top and I/O MBD111 – back and I/O SI-111-N User Manual...
  • Page 19 Hardware Configuration Switches on SI-111-N Switch Function SW1-1 Clear CMOS Data SW1-2 Clear ME Register Power Button 2.2.1 SW1-1: Clear CMOS Data Function Setting Normal (default) P1-OFF Clear CMOS P1-ON 2.2.2 SW1-2: Clear ME Register Function Setting Normal (default) P2-OFF...
  • Page 20 2.2.3 SW2: Power Button Connectors on SI-111-N Connectors Function DC 12V Power Input Connector COM1 RS232 LAN Connector CN4, CN5, CN6 USB 3.1 Connectors HDMI Connector SPI Flash Connector (Factory use only) Program iSmart MCU Connector (Factory use only) DDR4 Slot...
  • Page 21 Hardware Configuration 2.2.4 CN1: DC 12V Power Input Connector Assignment Ground +12V 2.2.5 CN2: COM1 RS232 SI-111-N User Manual...
  • Page 22 2.2.6 CN3: LAN Connector 2.2.7 CN4, CN5, CN6: USB 3.1 Connectors 2.2.8 CN7: HDMI Connector SI-111-N User Manual...
  • Page 23 Hardware Configuration 2.2.9 J1: SPI Flash Connector (Factory use only) 2.2.10 J2: Program iSmart MCU Connector (Factory use only) 2.2.11 J3: DDR4 Slot SI-111-N User Manual...
  • Page 24 2.2.12 J4: Program VCore Connector (Factory use only) 2.2.13 J5: Port 80 Connector (Factory use only) 2.2.14 J6: Front Panel Connector (optional) SI-111-N User Manual...
  • Page 25 Hardware Configuration 2.2.15 J7: Audio Line-In Connector 2.2.16 J8: Audio Line-Out Connector 2.2.17 J9: DDR4 Slot SI-111-N User Manual...
  • Page 26 2.2.18 J10: M.2 E-Key Connector 2.2.19 J11: M.2 M-Key Connector SI-111-N User Manual...

  • Page 27: Chapter 3 Driver Installation

    Chapter 3 Driver Installation The information provided in this chapter includes: Intel ® Chipset Software Installation Utility • VGA Driver • HD Audio Driver • ® Intel Management Engine Drivers Installation • LAN Driver •...

  • Page 28: Introduction

    Chipset drivers should be installed first before the software drivers to install INF files for Plug & Play function for Intel chipset components. 1. Run the driver disk. Click Intel on the left pane and then Intel(R) Elkhartlake Chipset Drivers on the right pane. SI-111-N User Manual...
  • Page 29 Chipset Device Software appears, click Next. 4. Accept the software license agreement and proceed with the installation process. 5. On the Readme File Information screen, click Install. 6. After the installation, press Finish to complete the setup process. SI-111-N User Manual...

  • Page 30: Vga Driver Installation

    3.3 VGA Driver Installation 1. Run the driver disk. Click Intel on the left pane and then Intel(R) Elkhartlake Chipset Drivers on the right pane. 2. Click Intel(R) Elkhartlake Graphics Driver. SI-111-N User Manual...
  • Page 31 Driver Installation 3. On the intel Graphics Driver Installer screen, click Begin installation. 4. Click I agree. SI-111-N User Manual...
  • Page 32 5. Click Start. 6. Click Finish. SI-111-N User Manual...

  • Page 33: Hd Audio Driver Installation

    Driver Installation 3.4 HD Audio Driver Installation 1. Run the driver disk. Click Intel on the left pane and then Intel(R) Elkhartlake Chipset Drivers on the right pane. 2. Click Realtek High Definition Audio Driver. SI-111-N User Manual...
  • Page 34 3. On the Welcome screen, click Next. 4. On the Custom Installation Help screen, click Next. 5. When InstallShield Wizard has finished the installation, click Finish. SI-111-N User Manual...

  • Page 35: Intel® Me Drivers Installation

    Driver Installation 3.5 Intel® ME Drivers Installation 1. Run the driver disk. Click Intel on the left pane and then Intel(R) ME Drivers. 2. On the Welcome screen to the Intel® Management Engine Components, click Next. SI-111-N User Manual...
  • Page 36 3. Accept the license agreement and click Next. 4. On the Setup’s Destination Folder screen, click Next to install to the default folder, or click Change to choose another destination folder. 5. After the Intel® Management Engine Components have been installed, click Finish. SI-111-N User Manual...

  • Page 37: Lan Drivers Installation

    3.6 LAN Drivers Installation 1. Run the driver disk. Click LAN Card on the left pane and then Intel LAN Controller Drivers on the right pane. 2. Choose Intel(R) I21x/ I22x Gigabit Network Drivers. 3. Click Install Drivers and Software. SI-111-N User Manual...
  • Page 38 4. On the welcome screen to the install wizard for Intel(R) Network Connections, click Next. 5. On the Setup Options screen, click Next. 6. Click Install. 7. When Install wizard has completed the installation, click Finish. SI-111-N User Manual...

  • Page 39: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS. The topics covered in this chapter are as follows: Main Settings • Advanced Settings • Chipset Settings • Security Settings • Boot Settings • Save & Exit •...

  • Page 40: Introduction

    These defaults have been carefully chosen by both AMI and the system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. SI-111-N User Manual...

  • Page 41: Main Settings

    Set the time. System Time Use the <Tab> key to switch between the time elements. 4.4 Advanced Settings This section allows the configuration of the system and the selection of the system features according to your preference. SI-111-N User Manual...
  • Page 42 4.4.1 CPU Configuration BIOS Setting Description When enabled, a VMM can utilize the Intel (VMX) Virtualization additional hardware capabilities provided by Technology Vanderpool Technology. SI-111-N User Manual...
  • Page 43 ME State Temporarily Disabled Mode. When disabled, AMT BIOS Features are no longer supported and user is no longer able to AMT BIOS Features access MEBx Setup. Note: This option does not disable Manageability Features in FW. SI-111-N User Manual...
  • Page 44 TPM 1.2 will restrict support to TPM 1.2 devices only. TPM 2.0 will restrict support to TPM 2.0 devices only. Device Select Auto will support both with the default being set to TPM 2.0 deices if not found, and TPM 1.2 device will be enumerated. SI-111-N User Manual...
  • Page 45 Hardware Monitor BIOS Setting Description These fields are the parameters of the hardware monitoring function feature of the Temperatures / Voltages motherboard. The values are read-only values as monitored by the system and show the PC health status. SI-111-N User Manual...
  • Page 46 The maximum time the device will take before it properly reports itself to the Host Controller. Device power-up delay “Auto” uses default value for a Root port it is 100ms. But for a Hub port, the delay is taken from Hub descriptor. SI-111-N User Manual...
  • Page 47 BIOS Setup 4.4.6 Network Stack Configuration BIOS Setting Description Network Stack Enables / Disables UEFI Network Stack. 4.4.7 NVMe Configuration SI-111-N User Manual...

  • Page 48: Chipset Settings

    BIOS Setting Description System Agent (SA) Configuration System Agent (SA) parameters PCH-IO Configuration PCH parameters 4.5.1 System Agent (SA) Configuration BIOS Setting Description Graphics Configuration Configures the graphics settings. VT-d Checks if VT-d function on MCH is supported. SI-111-N User Manual...
  • Page 49 Note: Above 4GB MMIO BIOS assignment is automatically enabled when selecting 2048 MB aperture. To use this feature, disable CSM support. 4.5.2 PCH-IO Configuration BIOS Setting Description SATA Configuration SATA Devices Options Settings PinCntrl Driver GPIO Enable/Disable PinCntrl Driver GPIO Scheme Scheme SI-111-N User Manual...
  • Page 50 BIOS Setting Description SATA Controller(s) Enables / Disables the SATA device. SATA Mode Selection Determines how SATA controller(s) operate. Serial ATA Ports Enables / Disables serial ports. SATA Ports Hot Plug Enables / Disables SATA Ports HotPlug. SI-111-N User Manual...

  • Page 51: Security Settings

    BIOS Setup 4.6 Security Settings BIOS Setting Description Administrator Sets an administrator password for the setup utility. Password User Password Sets a user password. Secure Boot Configures Secure Boot. SI-111-N User Manual...
  • Page 52 Restore Factory Forces system to user mode. Install factory default Keys Secure Boot key databases. Enables expert users to modify Secure Boot Policy Management variables without full authentication. SI-111-N User Manual...

  • Page 53: Boot Settings

    Selects the keyboard NumLock state. NumLock State Quiet Boot Enables / Disables Quiet Boot option. Boot Option Sets the system boot order. Priorities UEFI Hard Disk Specifies the Boot Device Priority sequence from Drive BBS available UEFI Hard Disk Drives. Priorities SI-111-N User Manual...

  • Page 54: Save & Exit Settings

    Restores / Loads defaults values for all the setup Restore Defaults options. Save as User Saves the changes done so far as User Defaults. Defaults Restore User Restores the user defaults to all the setup options. Defaults SI-111-N User Manual...

  • Page 55: Appendix

    Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. • I/O Port Address Map • Interrupt Request Lines (IRQ)

  • Page 56: I/O Port Address Map

    0x00000070-0x00000070 System CMOS/real time clock 0x00000080-0x00000080 Motherboard resources 0x00000092-0x00000092 Motherboard resources 0x000000B2-0x000000B3 Motherboard resources 0x00000680-0x0000069F Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x00001800-0x000018FE Motherboard resources 0x0000164E-0x0000164F Motherboard resources 0x00000062-0x00000062 Microsoft ACPI-Compliant Embedded Controller SI-111-N User Manual...
  • Page 57 0x000004D0-0x000004D1 Programmable interrupt controller 0x00000000-0x00000CF7 PCI Express Root Complex 0x00000D00-0x0000FFFF PCI Express Root Complex 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer 0x00001854-0x00001857 Motherboard resources 0x0000FF00-0x0000FFFE Motherboard resources Mobile 6th/7th Generation Intel(R) Processor 0x0000F040-0x0000F05F Family I/O SMBUS - 9D23 SI-111-N User Manual...

  • Page 58: Interrupt Request Lines (Irq)

    Intel(R) Dual Band Wireless-AC 8265 IRQ 4294967291 Intel(R) Iris(R) Plus Graphics 650 Intel(R) Smart Sound Technology (Intel(R) SST) IRQ 4294967287 Audio Controller Intel(R) USB 3.0 eXtensible Host Controller - 1.0 IRQ 4294967292 (Microsoft) IRQ 4294967293 Realtek PCIE CardReader SI-111-N User Manual...

  • Page 59: Watchdog Timer

    81804 watch dog program\n"); SIO = Init_F81804(); if (SIO == 0) printf("Can not detect Fintek 81804, program abort.\n"); return(1); }//if (SIO == 0) if (argc != 2) printf(" Parameter incorrect!!\n"); return (1); bTime = strtol (argv[1], endptr, 10); SI-111-N User Manual...
  • Page 60 //--------------------------------------------------------------------------- void DisableWDT(void) unsigned char bBuf; Set_F81804_LD(0x07); //switch to logic device 7 bBuf = Get_F81804_Reg(0xFA); bBuf &= ~0x01; Set_F81804_Reg(0xFA, bBuf); //disable WDTO output bBuf = Get_F81804_Reg(0xF5); bBuf &= ~0x20; bBuf |= 0x40; Set_F81804_Reg(0xF5, bBuf); //disable WDT //--------------------------------------------------------------------------- SI-111-N User Manual...
  • Page 61 (ucDid == 0x07) //Fintek 81804 { goto Init_Finish; F81804_BASE = 0x00; result = F81804_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_F81804 (void) outportb(F81804_INDEX_PORT, F81804_UNLOCK); outportb(F81804_INDEX_PORT, F81804_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81804 (void) outportb(F81804_INDEX_PORT, F81804_LOCK); //--------------------------------------------------------------------------- void Set_F81804_LD( unsigned char LD) SI-111-N User Manual...
  • Page 62 LD); Lock_F81804(); //--------------------------------------------------------------------------- void Set_F81804_Reg( unsigned char REG, unsigned char DATA) Unlock_F81804(); outportb(F81804_INDEX_PORT, REG); outportb(F81804_DATA_PORT, DATA); Lock_F81804(); //--------------------------------------------------------------------------- unsigned char Get_F81804_Reg(unsigned char REG) unsigned char Result; Unlock_F81804(); outportb(F81804_INDEX_PORT, REG); Result = inportb(F81804_DATA_PORT); Lock_F81804(); return Result; //--------------------------------------------------------------------------- SI-111-N User Manual...
  • Page 63 #define F81804_DATA_PORT (F81804_BASE+1) //--------------------------------------------------------------------------- #define F81804_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81804_UNLOCK 0x87 #define F81804_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81804(void); void Set_F81804_LD( unsigned char); void Set_F81804_Reg( unsigned char, unsigned char); unsigned char Get_F81804_Reg( unsigned char); //--------------------------------------------------------------------------- #endif // F81804_H SI-111-N User Manual...
