- Page 1 SA-101-N Mini Android Digital Signage Player User’s Guide 2015 May 27. V1.0 IBASE Technology Inc.
-
Page 2: Quick Start Guide
SA-101 Quick Start Guide Product packing list: SA-101-N Mini Android Digital Signage Player series (Mini Android Digital Signage Player) HDMI Cable (Type-C to Type-A) Power Adapter Power Cable (USB Type-A to DC) Quick installation: Step 1: Plug the HDMI cable into Player, and plug another end of HDMI cable into HDMI port of your TV. -
Page 3: Table Of Contents
TABLE OF CONTENTS Quick Start Guide ........................2 Introduction ........................4 1.1. SA-101 Introduction ....................... 4 1.2. SA-101 Hardware Specifications ..................5 1.3. Optional Items ....................... 5 Power On ........................6 Default Function ......................6 3.1. Update new media files ....................6 3.2. -
Page 4: Introduction
1. Introduction 1.1. SA-101 Introduction SA-101 is a product code of IBASE SA-101-N Mini Android Digital Signage Player series. It is an Android system for general applications. It may contain some prebuilt APK for demonstration purpose. For any questions please contact... -
Page 5: Sa-101 Hardware Specifications
1.2. SA-101 Hardware Specifications Freescale ARM Cortex-A9, 1GHz, processor Supports -0°C~ 50°C environment Supports DC 4.75V~5.25V input voltage 1GB DDR3, 8GB eMMC on board Supports HDMI Display Supports USB 2.0 A-type and Supports MicroSD card Form Factor 85mm x 46mm x 15mm Freescale Cortex™-A9 i.MX6 Dual Lite 1GMHz / Quad 1GMHz,... -
Page 6: Power On
SA-101 2. Power On Step 1: Plug the HDMI cable into Player, and plug another end of HDMI cable into HDMI port of your TV. Step 2: For remote control, use any of your USB mouse/keyboard/wireless receiver etc. and connect to the USB port of Player. Step 3: Install your MicroSD/TF Card if you have. - Page 7 If you want to update/add media files in function, you need a USB dish or TF card, copy the videos and pictures into USB dish/TF card under folder “media”, then plug-in USB / insert TF card to SA-101-N Mini Android Digital Signage Player series. The device will detect new media files and update automatically after power up.
-
Page 8: Exit Function
SA-101 3.2. Exit Function If you want to exit this “AdPlayer” function, you can right click the mouse (or ESC for Keyboard) to have below control window. Input password and click OK (default password : IBASE) Then you will exit to below standard Android home screen. After existing to Android home screen, if there is no activity for 60 seconds system will return to “AdPlayer”... -
Page 9: Microsd/Tf Card & Usb Disk
4. MicroSD/TF Card & USB Disk You can read/write file in TF Card or USB Disk per following instruction. Click Menu icon (On Right Line) Click ES File Explore App Select Local and find extsd file (TF Card) and udisk0~2 （USB Disk）... -
Page 10: Wi-Fi/Bt Setting
SA-101 Now you can operate on your own. 5. Wi-Fi/BT Setting The device can connect to internet through Wi-Fi. First click settings and Wi-Fi. Open Wi-Fi, select the access point and input password. -
Page 12: Update Software
SA-101 When you see the Wi-Fi icon appearing in the upper right corner, the device is connected to the internet. 6. Update Software The device software can be updated with below method. Please contact IBASE for new software image. Copy the new software image to a USB disk or TF card and insert to the Player. - Page 13 Click Setting and select “About tablet” Then, Click first one “Additional system updates” Select Firmware from your USB disk or TF card...
- Page 14 SA-101 You can now select the software image to be updated. Above for example the update software image is ”mbd101-ota-20150505-172629.zip”. At last, click Update Firmware. Wait for the upgrade process to complete.
