  • Page 1 1008/1008-S UK - ASSEMBLY AND INSTRUCTIONS MANUAL SCAN 1008/1008-S ASSEMBLY AND INSTRUCTIONS MANUAL SCAN 1008...
  • Page 2 1008/1008-S CONGRATULATIONS ON YOUR NEW SCAN BUILT-IN STOVE You have purchased a product by one of Europe’s leading manufacturers of wood-burning stoves, and we are sure that you will have years of pleasure from your purchase. To make the best possible use of your built-in stove, it is important that you follow our advice and instructions.

  • Page 3: Table Of Contents

    CONTENTS ¬ ¬ TECHNICAL DATA Installation Dimensional drawing for Scan 1008-S Safety Type plate Technical data and dimensions Product registration number Dimensional drawing for Scan 1008 ¬ ¬ ASSEMBLY Tools for the mounting of the built-in stove Safety distance Loose parts...

  • Page 4: Technical Data

    Any changes made to the product by the dealer, fitter or user could result in the product and safety functions not functioning as intended. The same applies to the fitting of accessories or extra equipment not supplied by Scan A/S. This could also be the case if parts that are necessary for the operation and safety of the stove are dismantled or removed.

  • Page 5: Technical Data And Dimensions

    Recommended negative pressure die down until only the embers are left before refuelling. 17-20 in flue connecting piece Scan 1008/1008-S is produced in accordance with type Required combustion air supply approval for the product, which also covers the product’s Fuel Wood Assembly and Instruction Manual.

  • Page 6: Dimensional Drawing For Scan 1008

    DIMENSIONAL DRAWING FOR SCAN 1008 Centre to 90° curved elbow pipe 320 x320 mm Centre rear outlet Height to the beginning of flue Centre to 2 x 45° elbow pipe 245x245 mm connecting piece at top outlet Centre of fresh air intake All measures are in mm.

  • Page 7: Dimensional Drawing For Scan 1008-S

    DIMENSIONAL DRAWING FOR SCAN 1008-S Scan 1008-S Scan 1008-S - målskitse 90580067 NAVN: EMNE: TG.NR: 28-05-2018 MATERIALE: VÆGT: DATO: SIGN: DIMENSION: AREAL: Krog Iversen & Co A/S DK-5492 Vissenbjerg© C:\Working Folder\Designs\Scan 80\90580067.idw STI: can 1008-S - målskitse 90580067 TG.NR: 28-05-2018 DATO: VÆGT:...

  • Page 8: Type Plate

    PRODUCT REGISTRATION NUMBER All Scan built-in stoves are provided with a product registration number. Please make a note of this number at the rear page of this manual; you will always need to quote it when contacting your dealer or Scan A/S.

  • Page 9: Assembly

    Felt knobs ADDITIONAL ACCESSORIES ¬ Floor plates (see page 20) ¬ Cover plate for corner installation Scan 1008-S (See page 30) ¬ Convection grates (See page 31) DISPOSAL OF PACKAGING Your Scan built-in stove may come supplied with the following packaging:...

  • Page 10: Fresh Air Intake

    EXISTING CHIMNEY AND PRE-FABRICATED ELEMENT CHIMNEY If you intend to connect your stove to an existing chimney, it makes sense to contact an authorised Scan dealer, or a local chim- ney sweep, for advice. These experts will also let you know if your chimney needs renovating.

  • Page 11: Requirements For Chimney

    INTERNAL INSTALLATION IN NON-FLAMMABLE MATERIAL Scan 1008: There are no demands concerning the distance to non-flammable materials, but we recommend a distance of 25 mm in order to facilitate the cleaning of the stove, the flue pipes and the chimney and to prevent possible damages to the wall.

  • Page 12: Building Into Flammable Material With Fire Wall

    450 mm 25 mm Møbleringsafstand: 800 mm. Brandbart materiale Brandmur F.eks. 50 mm. Jøtul firewall Møbleringsafstand: 800 mm. Brandbart materiale Drawing Brandmur Opstillingsafstand, hjørne, Scan 1008 90580001 Name: Date: 10-03-2017 number: F.eks. 50 mm. Jøtul firewall Constructed/Changed by: Weight: Area: SCAN A/S DK-5492 Vissenbjerg©...
  • Page 13 The distance to fire wall (brick) depends on the use of an F.eks. 50 mm. Jø F.eks. 50 mm. Jøtul firewall insulated flue pipe with min. 30 mm insulation all the way down to the insert Drawing Opstillingsafstand, hjørne, Scan 1008 Opstillingsafstand, hjørne, Scan 1008 Stove: Scan 1008 Name: Date:...
  • Page 14 BUILDING INTO FLAMMABLE MATERIAL WITH FIRE WALL - SCAN 1008-S 45° corner installation Parallel installation 114 mm 313 mm 250 mm 450 mm Drawing Opstillingsafstand, hjørne, Scan 1008-S n 1008-S Name: Date: 17-04-2018 90580064 Drawing number: Opstillingsafstand, parallel, Scan 1008-S...

  • Page 15: Using The Lifting Fittings

    PLEASE NOTE: If the insert is to be moved, after it has been removed from the pallet, the door must be opened or dismounted! REMOVE PACKAGING Before installing the stove, check that it has no damages. NOTE: Do not touch the glass Scan 1008 - Brug af løftebeslag Scan 1008 90580073 NAVN: EMNE: TG.NR:...
  • Page 16 NOTE: The stove must be taken off the pallet by removing the screws. Do not knock off the pallet, as this can damage the stove. The built-in stove is mounted on the pallet with 6 screws (Scan 1008)/4 screws (Scan 1008-S). Please remove these. NOTE: it is important that the door is not opened after removing the screws, as the stove may easily tilt! Scan 1008 på...

  • Page 17: Fitting The Flue Connection Piece

    A ( 1 : 5 ) Connection piece 4 x unbraco M5 x 10 for external flue pipe A ( 1 : 5 ) Scan 1008 - montage røgstuds i topafgang NAVN: EMNE: TG.NR: 90580042 MATERIALE: VÆGT:...
  • Page 18 Fit the gasket and the cover in the Remove the gasket stove’s top outlet and tighten it. and the cover from the stove’s rear outlet. Reposition the top module. Scan 1008 - montage af røgstuds i bagafgang 90580054 EMNE: TG.NR: DATO: 17-01-2018 SIGN: VÆGT:...

  • Page 19: Door (Self-Closing)

    Connection piece for external flue pipe. D ( 1 : 5 ) Tighten the flue connection piece 4 x unbraco M5 x 10 with the delivered screws. Scan 1008 - montage af røgstuds i bagafgang Scan 1008 90580056 NAVN: EMNE: TG.NR:...

  • Page 20: Height Adjustment Of The Built-In Stove

    HEIGHT ADJUSTMENT OF THE BUILT-IN STOVE Scan 1008 is delivered on a small rack. If you want to install the stove in a higher position, the rack can be blocked up on a solid foundation of non-flammable material. The stove is equipped with eight adjustment screws, of which three Bagklap fjernes ved at løfte op og "vippe"...

  • Page 21: Fastening To The Rear Wall

    FASTENING TO THE REAR WALL The built-in stove has two adjustable fittings for the fastening of the stove to the rear wall. Fastening corner Parallel fastening Scan 1008 - beslag i bagvæg Scan 1008 90580059 NAVN: EMNE: TG.NR: 16-05-2018 MATERIALE: VÆGT:...

  • Page 22: Dismounting Of The Frame

    (2.5 mm). Loosen and remove the long screw with the spring D ( 1 : 5 ) D ( 1 : 5 ) The door can now be removed Scan 1008 - Afmontage af ramme Scan 1008 90580047 NAVN: EMNE: TG.NR:...
  • Page 23 Remove the screws holding A ( 1 : 5 ) the frame A ( 1 : 4 ) A ( 1 : 5 ) Remove the screw on the frame Scan 1008 - Afmontage af ramme 90580049 EMNE: TG.NR: 16-01-2018 VÆGT: DATO:...

  • Page 24: Building Around The Frame

    ATTENTION! This illustration is only to show the position of the fittings (only Scan 1008). For positioning of the fittings on Scan 1008-S, see page 26-27. Normally the surround will consist of more elements that are built up around the insert with these fittings mounted in advance.
  • Page 25 BUILDING AROUND THE FRAME PLEASE NOTE: The frame is adjusted from the factory so that you can max. use 50 mm material around the frame. Scan 1008 - indbygning i ramme Scan 1008 90580060 EMNE: TG.NR: 23-02-2018 ERIALE: VÆGT: DATO:...
  • Page 26 Make sure to follow the pattern as shown subsequently Scan 1008-S Scan 1008-S 90580071 NAVN: EMNE: TG.NR: 22-05-2018 MATERIALE: VÆGT: DATO: SIGN: Scan 1008-S - Montering af filtknopper Scan 1008-S 90580069 NAVN: EMNE: TG.NR: DIMENSION: AREAL: Krog Iversen & Co A/S 350 mm DK-5492 Vissenbjerg© C:\Working Folder\Designs\Scan 80\90580071.idw...
  • Page 27 BUILDING AROUND THE FRAME- SCAN 1008-S Push the front pieces together and glue them Important! When mounting the surround plates, the so that the bevels fit together rear side must fit closely against the head of the bolt Screw the front plates together with four screws...
  • Page 28 BUILDING AROUND THE FRAME - SCAN 1008-S Side piece Bottom piece Mount the side pieces on the bottom pieces It is important that the fittings are placed correctly! Hole for 90° curved elbow pipe 320x320 mm Hole for 2 x 45°...
  • Page 29 It is important that the surround does not "rest" Mount self-adhesive joint tape in the filling trace. on the frame! Then cut the corner strips in appropiate lengths with a large pair of scissors Scan 1008-S Scan 1008-S - snitbillede 90580068 NAVN: EMNE: TG.NR: MATERIALE: VÆGT:...
  • Page 30 BUILDING AROUND THE FRAME- SCAN 1008-S The corner strips can be mounted on all edges using glue or filler We recommend to dismount the frame. Alternatively it is important to cover the frame before filling. We recommend to fill twice, before the surround is ready to be painted and the convection grates are mounted.

  • Page 31: Mounting Of Convection Grate

    MOUNTING OF CONVECTION GRATE (ACCESSORY SCAN 1008) Scan 1008-S is delivered with cut-out holes in the surround and a convection grate in black. (If you want a white convection grate, this can be bought separately). Cut a hole in the wall according to...
  • Page 32 MOUNTING OF CONVECTION GRATE (ACCESSORY SCAN 1008) Put the four magnets on each corner of the metal frames. Then mount the convection grates. NOTE! It is important that the mag- nets are flush with the outer fire wall plate. Scan 1008...

  • Page 33: Instructions For Use

    INSTRUCTIONS FOR USE CB-TECHNOLOGY (CLEAN BURN) The stove is equipped with CB technology. In order to ensure optimal combustion of gases released during the combustion process, air passes through a specially developed system of channels. The heated air is conducted into the combustion chamber through the holes in the rear lining of the combustion chamber and at the baffle plates.

  • Page 34: Adjustment Of Primary- And Secondary Air

    Lift up the handle for the primary air damper and then pull it all the way to the right (4). See our video about correct firing and adjustment of primary- and secondary air on www.scan.dk or scan the QR-code on next page.

  • Page 35: Instructions For Heating

    LIGHTING We recommend the use of fire lighters, or similar products, which are available from your Scan dealer. Using fire lighters helps light the wood more quickly and keeps the combustion process clean. See our video about correct firing on www.scan.dk or scan the QR-code.

  • Page 36: Continuous Operation

    VERTICAL LIGHTING A vertical lighting also ensures an environmentally friendly lighting and helps to keep the glass optimally clean. For a vertical lighting, you need the following: ¬ 4 pieces of wood approx. 19-25 cm with a weight of approx. 0.4-0.5 kg per piece ¬...

  • Page 37: Firing In The Spring Or Autumn

    FIRING IN THE SPRING OR AUTUMN In the spring/autumn transition period, where there is less need for heating, we recommend you light the stove “top down” once, perhaps adding just two pieces of wood to ensure that the combustion chamber lining burns clean again. THE FUNCTION OF THE CHIMNEY The chimney is the wood-burning stove’s motor;...

  • Page 38: Selecting Wood/Fuel

    HANDLING OF THE FUEL SELECTING WOOD/FUEL You can use any type of wood as fuel. However harder woods, such as beech or ash, are generally better for heating, as they burn more evenly and create less ash. Other woods, such as maple, birch and spruce, are excellent alternatives. PREPARATION The best fuel is obtained where the tree has been felled and the wood sawn and split before May 1st.

  • Page 39: Sweeping The Chimney And Cleaning The Stove

    Clean your wood-burning stove by wiping it down with a dry, lint-free cloth. If the paint finish gets damaged, you can purchase repair paint in spray form from your Scan dealer. As slight differences in colour shade are possible, we recommend you spray a larger area to achieve a natural blend. For best results, apply repair spray when the stove is warm enough for you to just keep your hand on it, but no hotter.

  • Page 40: Cleaning The Glass

    Lift up the baffle unit a little and tip it slightly backwards until it is free of the hole (1). Then slowly pull out the unit, until it is free of the rear rails (2). Baffle plate Baffle unit Scan 1008 - røgvenderplade 90580044 EMNE: TG.NR: 21-12-2017 VÆGT:...
  • Page 41 TROUBLESHOOTING SMOKE ESCAPING ¬ Damp wood ¬ Chimney not drawing properly ¬ Chimney is not properly dimensioned for the built-in stove ¬ Check if the smoke gas pipe/chimney are blocked ¬ Is the chimney the right height for its surroundings? ¬...
  • Page 42 You must quote your stove‘s product registration number when you contact us or your authorised Scan dealer with a warranty claim. The warranty covers all parts which in the opinion of Scan A/S require repair or replacement due to manufacturing or construc- tion error The warranty applies to the original purchaser of the product only, and is not transferable (except on prior sale).
  • Page 43 MOUNTING THE UK - BLOCKING AND SCREW Scan 1008 and 1008-S have been recommented as suitable for use in smoke control areas when burning wood logs and when fitted with a mechanical stop to prevent that the secondary air valve cannot be closed lower than 868 mm NOTE: In order to a achieve this, the blocking piece and screw (M5 x 8) must be placed as shown in the pictures, to prevent that the secondary air valve can be closed completely.
  • Page 44 Product registration number Quote this number at all enquiries Edition: UK 90080500 SCAN A/S Glasvænget 3-9 DK-5492 Vissenbjerg www.scan.dk 14.08.2018...
