3.2 Installation Tools and Information
Prepare the required engineering data and instructions.
Before installation please prepare the following tools
and instrumentation: A straight or a Phillips-head
screwdriver, multi-meter, scissors, needle nose pliers,
tape measure, pencil and so on.
3.3 Installation Method
1. Check the equipment whether it is damaged.
2. Mounting bracket or base.
① If the cement wall, install the expansion screws
(expansion screw holes need stand or base hole), and
then mount bracket or base.
② If the wooden wall, use self-tapping screws to mount.
6
3. Mounting the camera
a. Dome Camera
Adjust the lens position and make it aim at the monitoring
points and present a clear picture, manually fix lens
location and adjust the hemisphere cover. Re-examine
the screen whether the character meets the requirement.
Tighten the hemisphere cover.
b. Bullet Camera
Adjust the body so that the lens aims at the monitoring
points and presents a clear picture. Tighten the screws,
to ensure that it does not move.
Installation method above is for reference only, the
specific installation, please be kind.
Note:
The wall needs to bear at least 3X
weight
of
bracket
camera.
(base)
and
7
